- Page 1 Installation and Service Instructions Roof-Mounted Air Conditioner KK2000 E ID No. 98278C...
-
Page 2: Table Of Contents
3.2 Compressor..........................15 3.3 Circuit Diagram ........................16 INSTALLATION INSTRUCTIONS .....................18 4.1 Installation Diagrams for Cabins without Roof Gaps ...............18 4.2 Checklist for the Installation of the KK2000 E with Heater Unit..........19 INITIALIZATION.........................20 5.1 Safety Information ........................20 5.2 Operator Information ........................20 5.3 Operating, Control, and Safety Switch..................21 5.4 Operating the Air Conditioning System..................21... -
Page 3: Introduction
Operating Manual for the Air Top 3500 (776,246): Safety Information and Requirements The roof-mounted air conditioner KK2000 E is constructed according to the latest technology and is safe for operation when mounted and used correctly according to the information in these installation and service instructions. - Page 4 By not following the installation instructions and the information contained therein you release Webasto from all liability. This also applies for non-specialist repairs or when original spare parts are not used. This can result in loss of the vehicle’s general operating permit (ABE).
-
Page 5: General Description
A relay ensures that both units cannot be operated simultaneously. The compressor has a hydraulic drive. The air conditioning and the heater unit are designed for operation with circulating air. Option: The KK2000 E can also be delivered without a heater unit. Figure 2.1 Page 5 / 30... -
Page 6: Roof-Mounted Air Conditioner
Roof-Mounted Air Conditioner KK2000 E Roof-Mounted Air Conditioner The roof-mounted air conditioner is shown in figure 2.2. It contains: – The cover (1) with openings as well as protective screens for the condenser air intake and exhaust, this is the outer contour section. - Page 7 Roof-Mounted Air Conditioner KK2000 E Figure 2.2 Page 7 / 30...
-
Page 8: Air Manifold Plate
Figure 2.3. Electrics The circuit diagrams for the KK2000 E are shown in figure 3.1. The connection must use a battery discharge protection switch with a fuse. This way the system can only be operated when the vehicle engine is running. - Page 9 Roof-Mounted Air Conditioner KK2000 E 2.4.2 Cooling Adjust the blower switch as described in section 2.4.1. The thermostat switch must be switched on for the compressor to work. Turn to the right until you reach the desired air temperature. The lowest temperature is when it is turned all the way to the right.
- Page 10 Roof-Mounted Air Conditioner KK2000 E Figure 2.4. Page 10 / 30...
- Page 11 Roof-Mounted Air Conditioner KK2000 E Coolant lifecycle (figure 2.4) When the air conditioner is switched on, the compressor (18) links up using the magnetic coupling and is run by the vehicle’s engine drive belts. It compresses the coolant gas and transports it to a condenser (3) where it is condensed by heat exhaust.
-
Page 12: Design, Task, And Function Of The Components
Roof-Mounted Air Conditioner KK2000 E Design, Task, and Function of the Components (figure 2.4) Condenser The condenser (3) consists of a continuous helical tube and blades that are connected together to a large heat exchange surface. It cools down the hot coolant gas until it liquefies and is undercooled, and it transfers the condensation heat over the blades to the outside air that flows through them. - Page 13 Roof-Mounted Air Conditioner KK2000 E Axial blower The axial blower (4) consists of a direct current motor and fan wheel. Once the air conditioner is switched on, it will constantly be run with board voltage and supply the condenser with the required external air.
-
Page 14: Technical Data
Roof-Mounted Air Conditioner KK2000 E TECHNICAL DATA Air Conditioning Description Type KK2000 E Dimensions, roof-mounted air conditioner − Length x Width x Height 1301 mm X 814 mm X 284 mm Weight (body) with AT 3500 approx. 95 kg Weight (body) without AT 3500 approx. -
Page 15: Compressor
Roof-Mounted Air Conditioner KK2000 E Compressor Description Type Seltec TM15 HD Dimensions (length x width x height) 235 mm X 124 mm X 136 mm Weight (body): 4.5 kg Rotational direction left/right Piston displacement/rotation 131 cm Refrigerator oil (type/amount) PAG ZXL 100 PG / 150 + 20 cm Coolant connections –... -
Page 16: Circuit Diagram
Roof-Mounted Air Conditioner KK2000 E Circuit Diagram Figure 3.1. Page 16 / 30... - Page 17 Roof-Mounted Air Conditioner KK2000 E Key to circuit diagram: 1 Switch mounted in the vehicle console. 1x set value indicator, 2x switch 2 Hydro line 3 Take appropriate steps to ensure that there cannot be feedback to the board power and the air conditioner.
-
Page 18: Installation Instructions
Roof-Mounted Air Conditioner KK2000 E INSTALLATION INSTRUCTIONS Installation Diagrams for Cabins without Roof Gaps Figure 4.1. Page 18 / 30... -
Page 19: Checklist For The Installation Of The Kk2000 E With Heater Unit
• Make sure the complete fuel guide to the heater unit is filled before the first initialization. • Fasten the fuel line for the heater unit in the KK2000 E with the clamp provided on the base plate in the system so that the fuel line cannot be damaged by the hot exhaust pipe. -
Page 20: Initialization
Roof-Mounted Air Conditioner KK2000 E INITIALIZATION Safety Information Observe the safety information in chapter 1.4. Operator Information WARNING – Only start the air conditioning system when the vehicle engine is running otherwise the battery will be drained. – To prevent leaks in the shaft seals or the compressor,... -
Page 21: Operating, Control, And Safety Switch
Roof-Mounted Air Conditioner KK2000 E Operating, Control, and Safety Switch 5.3.1 The system is operated with the rotary switch and indicator on the operating panel. 5.3.2 The blower switch is the main switch for the air conditioner. This can also be used to vary the speed of the vaporizer blowers and the corresponding air flow. -
Page 22: Maintenance
Roof-Mounted Air Conditioner KK2000 E MAINTENANCE Safety Information Observe the safety information and regulations in chapter 1.4. General Only trained personnel in authorized repair depots may perform any work on the coolant system. As with all parts of a vehicle, the air conditioner is also subjected to constant stress. -
Page 23: Checklist For Care And Maintenance
Roof-Mounted Air Conditioner KK2000 E WARNING The coolant may never be released into the air (§ 8, CFC chlorofluorocarbon prohibition from May 06, 1991). Checklist for Care and Maintenance System component Maintenance work Occurrence m 6m Coolant system Check condition and sealing (leak search device) –... -
Page 24: Checks Before Initialization
Roof-Mounted Air Conditioner KK2000 E Steps in the event of malfunctions in the electrical system Systematically check individual circuits using the circuit diagram (see figure 3.1) and localize any errors. Place special emphasis on the function of plug connections, switches, relays, etc. -
Page 25: Maintenance Work
Roof-Mounted Air Conditioner KK2000 E Condition of the air manifold plate – Mounting points/screws are tight – Ventilation switches in perfect condition. – Ventilation inlet /outlet screens not damaged, clean Maintenance Work WARNING Coolant may never be released into the air (§ 8, CFC chlorofluorocarbon prohibition from May 06, 1991). - Page 26 Roof-Mounted Air Conditioner KK2000 E Evacuation Switch on the vacuum pump and vacuum the system for 30 minutes. The absolute pressure must be at least 0.005 bar. During the evacuation with the pump running again close all valves on the test device and check the manometer display.
-
Page 27: Visual Check
Roof-Mounted Air Conditioner KK2000 E Refilling coolant Coolant in a gaseous state can only be refilled when the compressor is running and only on the vacuum side of the system. The coolant bottle must be vertical to fill the system with the valve on top. The check boards are used for filling. -
Page 28: Spare Parts
Roof-Mounted Air Conditioner KK2000 E SPARE PARTS Item Part name Ident. No.: Cover, complete 65653A Cable harness, KK2000 E (not illustrated) 9013192A Heater unit AT 3500 65441D Metering pump 26590B Protective rubber sleeve, exhaust 89509A Vaporizer complete, KK2000 9002502A Thermal expansion valve... - Page 29 Roof-Mounted Air Conditioner KK2000 E Item Part name Ident. No.: Compressor TM-15HD 80739B Coolant hose NW 13 KK2000 67780B Coolant hose NW 10 KK2000 67779B Page 29 / 30...
- Page 30 Roof-Mounted Air Conditioner KK2000 E Item Part name Ident. No.: Operating control for thermostat module 67638A Thermostat module 66784A Air manifold plate construction 9013676A Dischargers, round 49932A Combination operating control 85340C Discharger, long 45374A Fan switch, 3 level, procurement through Plasser&Theurer Air conditioner switch ON / OFF (green), procurement through Plasser&Theurer...
