SPI 10G12 Operation Manual

Operating Environment:
Working temperature: 0~ +40℃.
Humidity: 80 %
Specifications:
Range
inch mm inch
0 to 6 0 to150
6 to 12 150 to 300
12 to 16 300 to 400
16 to 20 400 to 500
20 to 24 500 to 600 .001
24 to 28 600 to 700
28 to 32 700 to 800
32 to 36 800 to 900
36 to 40 900 to 1000
MECHANICAL INTERCHANGEABLE ANVIL MICROMETER
1
2
3
4
5
6
Resolution Accuracy +/-
mm inch mm
.0002 0.006
.0003 0.009
.0004 0.011
.0005 0.013
0.01 .0006 0.015
.0006 0.016
.0007 0.018
.0008 0.020
.0018 0.020
Anvil retainer nut 7 Thimble
Interchangeable Anvils 8 Ratchet Stop
Frame 9 Standard
Spindle Anvil 10 Wrench
Spindle lock 11 Anvil torque pressure control
Sleeve 12 Guide Rings
Method of reading:
.001inch Resolution
Reading from
Sleeve
Thimble
Total
.0001inch Resolution
Reading from
Sleeve
Thimble
Sleeve vernier
Total
MECHANICAL INTERCHANGEABLE
Reading Inch
0.175
0.005
0.180
Reading inch
The interchangeable anvils are
0.175
individually adjusted and calibrated to
0.005
the specific supplied micrometer
0.0002
frame with the set. Measurement
0.1802
errors will occur if they are used with
a micrometer frame from a different
set.
swissprec.com
ANVIL MICROMETER
OPERATION MANUAL
SPI 10G12
IMPORTANT NOTICE
