Extended Display Accessories ED10
The Extended Display Accessories ED10 helps you display the video
image captured from the camera (both near site and far site) on the
external monitor during a video call.
This quick installation guide provides step-by-step instructions for using
ED10 to connect your phone to an external monitor. It is only available
for the SIP VP-T49G IP phones.
The ED10 is not included with your IP phone, contact your reseller to
purchase it separately.
Packaging Contents
The following items are included in your package. If you find anything missing,
contact your system administrator.
HDMI Cable
Note: The external monitor not included in your package is also required for ED10
Installation, you should purchase it separately.
We recommend that you use the accessories provided or approved by Yealink.
The use of unapproved third-party accessories may result in reduced performance.
www.yealink.com
3M Dual Lock x2
Quick Installation Guide(V1.0)
USB3.0 Cable
Quick Installation Guide
Advertisement
Table of Contents
Related Manuals for Yealink ED10
Summary of Contents for Yealink ED10
- Page 1 USB3.0 Cable Quick Installation Guide 3M Dual Lock x2 Note: The external monitor not included in your package is also required for ED10 installation, you should purchase it separately. We recommend that you use the accessories provided or approved by Yealink.
- Page 2 Installation To connect your phone to an external monitor: Step Remove one piece of the fastener’s liner. Take the gap of the camera as the touchline and attach the fastener to the camera from the top. Connect one end of the USB3.0 cable to the camera. Step Remove the other piece of the fastener’s liner.
