Inter-fab X-stream Assembly And Instruction Manual page 6

Important! Flumes are labeled AB or CD in
small letters on flanges. For Left Hand Slides,
Flume AB is upper flume, and CD is the lower
flume, in that order; for a Right Hand Slide, CD
is the Upper Flume and AB is the Lower.
A-B flume C-D flume
Bottom Section Top section Leg foot (2) Step Support Foot
Step Support Assembly Long leg Short leg
(shown with foot installed)
Handrail (2) Hardware Sets (5)
Fig. B: Parts Required
- 6 - 6
