JYE Tech DSO 096 Quick Use Manual

DSO 096 Oscilloscope
Quick Use Guide
Applicable Model: 09601, 09602
Panel & Connectors
Vertical Sensitivity
Vertica l Sensitivity
Switch 1
Switch 2
Test
Signal
Output
(1K Hz 5Vpp )
Couple Select
Switch
Control Buttons
Signal
Input
Connector
HOLD s tate
Battery Indicator
Couple
Vertical
Sensitivity
Vertical
Time Base
Position
Vertical & Horizontal
Indicator
Position Adjus tment
Trigger Mode
Trigger Slope
Horizontal Trig Point
Trigger
Position Indicator
Level
Indicator
Indicator
Mode Navigating
Hold [MODE]
for 3 seconds
Oscilloscope
Frequency Meter
Mode (default) Mode
For detailed documents please
Rev. 02
www.jyetech.com
visit
Power
Switch
(V/Div)
(Sec/Div)
Trigger Level
Adjustment
LCD
Battery
Contrast
Connector
Adjustment
Mode Select Menu
Scroll highlight bar to functin wanted
and press [OK] button
Press [MODE]
Press [MODE]
FFT
Mode
Please note that button functions are mode and state dependent. The following
chartslist button functions under various modes and states.
1. Oscilloscope Mode
Button & SW
[VPOS]
[HPOS]
[SEC/DIV]
[MODE]
Power
[SLOPE]
Switch
[LEVEL]
[+]
[-]
[OK]
[VPOS] hold
USB Connector
[MODE] hold
[SLOPE] hold
[LEVEL] hold
[OK] hold
V.Sen 1 & V.Sen 2
Couple
2. Frequency Meter Mode
Button & SW
[MODE]
V.Sen 1 & V.Sen 2
Couple
Programming
Header
1. Powering ON/OFF the Unit
1 ) If battery is connected and external power supply ( USB) is not used setting power switch to "BATT" position
will turn the oscilloscope on. Settin g the switch to "USB" position will turn the unit off.
2 ) If USB is connected ALWAYS keep the power switch at "USB" position and use plugg ing/unplugging to
powe r on/off the unit.
3 ) If you un-intentionally placed the switch a t "BATT" position while USB is conn ected you may find the unit can
not be power on no matter by the switch or by plugging in USB cable . In th is case unplug USB cable and set the
switch to " USB" position. Wait for 10 - 30 seconds or longer the n turn it on by s witch or plugging in USB cable.
[Note: This situation won't happe n if the bulit-in battery charger was disconnected. For how to dis connect
battery charger please s ee explanation below]
2. Setting Parameters
1 ) Vertical -
Ø Use the top two slide switches to set sensitiv ity
Ø Use [VPOS] and [ + ] [ - ] buttons to change waveform vertical position
Ø Use the bottom slide switches to s elect coupling
2 ) Horizontal -
Ø Use [ Sec/Div] and [ + ] [ - ] buttons to set timebase
Ø Use [HPOS] and [ + ] [ - ] to change waveform horizontal po sition
3 ) Trigger -
Ø Use [MODE] and [ + ] [ - ] buttons to select trigger mode
Ø Use [SLOPE] and [ + ] [ - ] buttons to select trigger slope
Ø Use [LEVEL] an d [ + ] [ - ] buttons to change tr igger level
Button Function Summary
RUN State
Functions
Select VPOS
Select HPOS
Select TIME-BASE
Button & SW
Select trigger mode
[VPOS]
Select trigger slope
[HPOS]
Select trigger level
[SEC/DIV]
Adjust the selected param.
[MODE]
Adjust the selected param.
[SLOPE]
Enter HOLD state
[LEVEL]
VPOS alignment
[+]
Enter Function Select menu
[-]
Turn LCD backlight on/off
[OK]
Enter Setting Select menu
Turn off device
Change vertical sensitivity
Change couple method
3. FFT Mode
Button & SW
[MODE]
Functions [+] or [-]
Enter Function Select menu [HPOS]
Change sensitivity
V.Sen 1 & V.Sen 2
Change couple method
Couple
Basic Operations
Sensitivity Position , , and Coupling
Timebase and Position
Mode Slope , , and Level
HOLD State
Functions
Select VPOS
Select HPOS
Save waveform to buffer
Select trigger mode
Display buffer
Send screen
Adjust the selected param.
Adjust the selected param.
Exit HOLD state
Functions
Enter Function Select menu
Change sampling rate
Change FFT size
Change sensitivity
Change couple method
