Skill Level 3: Average Skills Needed
The Midge is a two-stage payload altitude rocket
designed specifically for NAR competitions. Use it in
single stage configuration in the A-altitude competition,
or two-stage in the "B-altitude" event (because two A-
size engines added together is equivalent to the power
of a "B" rocket motor).
The dual-diameter rocket is sized to carry the NAR
Standard Payload and an altimeter that fit into an
18mm payload tube. With its custom vacuum-formed
transition section the Midge then reduces down to a
13mm motor at the bottom to decrease the weight and
lower the drag. This rocket also comes with a cardstock
fin alignment guide to assure that the fins are perfectly
straight and evenly spaced around the rocket. This low-
ers the drag, and allows the rocket to fly to new record-
setting altitudes.
p/n 31013
Midge
(A Two-Stage Payload Altitude Rocket)
P/N
Description
Parts List
13000
Coupler 18mm X 0.35" (Red)
10055
Engine Mount Tube AT-13/8.0"
10082
Payload Tube AT-18/5.0"
12350
CBD-18mm Sheet
12999
Coupler AC-18C (Brown NAR Payload)
13012
Coupler AC-13
13020
CR 10/13 (green) Engine Block
13029
CR 13/18 (blue) Centering Ring
13051
1/8" Launch Lug 1" Long
15552
Midge Fins 1/16" X 3" X 3"
19012
13-to-18mm Ogive Transition (VF)
19207
Vac Form Nose Cone VFNC-18
29519
100# Kevlar X 6 ft
29111
8" Hexagon Orange Plastic Parachute (1/pk) 1
31013
Midge Instruction Sheet A
31014
Midge Instruction Sheet B
35535
13mm 3-Fin Alignment Guide
47122
Clear Plastic Bag 6x14x2mil
Other Tools and Materials Needed
Pencil
Hobby knife
Wood glue
Super glue (thick viscosity)
Plastic packaging tape
Paint supplies (spray paint, brushes, etc.)
Wood sealer
Sandpaper (220 and 400 grit)
Wood dowel for spreading glue inside tubes
Sand (28 grams - not included)
M
IDGE
Shock Cord Anchor Pattern
The Midge rocket is another fine product from:
Colorado Springs, Colorado USA
web site: www.ApogeeRockets.com
Kit #05045
Qty
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
