Summary of Contents for turbofan E85 Prover
- Page 1 INSTALLATION / OPERATION MANUAL E85 PROVER F21804-8...
- Page 2 MANUFACTURED BY Moffat Limited PO Box 10001 Christchurch New Zealand (03) 389 1007 Fax: (03) 389 1276 WORLD-WIDE BRANCHES UNITED KINGDOM Blue Seal Units 6-7, Mount Street Business Park Mount Street, Nechells Birmingham B7 5QU (121) 327 5575 Fax: (121) 327 9711 UNITED STATES Moffat Inc 3765 Champion Blvd...
-
Page 3: Table Of Contents
Description of Controls Condensation Channel Operating the Prover Bake-Off Problem Solving Hints Cleaning and Maintenance................13 Trouble Shooting .....................14 Spare Parts .......................15 Circuit Schematics...................16 E85 Prover (Manual Fill) E85A Prover (Auto Fill) Date Purchased..............Serial No ............Dealer................................Service Agent .............................. -
Page 4: Introduction
Introduction We are confident that you will be delighted with your E85 PROVER, and it will become a most valued appliance in your commercial kitchen. A new oven can seem very complex and confusing at first glance. To ensure you receive the utmost benefit from your new Prover, there are two important things you can do. -
Page 5: Installation
• Turn on water supply to check for leaks. Rack Width • The E85 prover has been designed to accept either 18” or 16” wide trays. • The prover comes factory set for 18” trays, to change to 16” trays: For 18”... -
Page 6: Stacking Instructions
Note: When stacking on an E85 prover, the legs on an E35 Turbofan oven should not be fitted. 1) For 26” oven only, Remove rear spacer panel (A) from stacking kit by removing four screws (B). -
Page 7: Specifications
Specifications E85-8 Prover WATER ENTRY ELECTRICAL ENTRY Side Front Plan Electrical Connection 220-240 Volts A.C, 50 Hz, 1P+N+E, 1.65 kW, 7.2 A Cold Water Connection ¾” B.S.P. or ID hose (550kPa / 80psi maximum pressure) (Auto Fill Models Only) - Page 8 Specifications E85-12 Prover WATER ENTRY ELECTRICAL ENTRY Side Front Plan Electrical Connection 220-240 Volts A.C, 50 Hz, 1P+N+E, 1.65 kW, 7.2 A Cold Water Connection ¾” B.S.P. or ID hose (550kPa / 80psi maximum pressure) (Auto Fill Models Only)
- Page 9 Specifications E85-8 Prover / E35 Oven 980 (30" Ovens) 880 (26" Ovens) WATER ENTRY ELECTRICAL ENTRY ELECTRICAL ENTRY Side Front Plan...
- Page 10 Specifications E85-12 Prover / E35 Oven 980 (30" Ovens) 880 (26" Ovens) WATER ENTRY ELECTRICAL ENTRY ELECTRICAL ENTRY Side Front Plan...
-
Page 11: Operation
Operation Operation Guide Description of Controls Power Turn to switch power on or off (on horizontal, off vertical). Indicator illuminates when power is on. Thermostat Temperature range 25-40°C (75 - 105°F). Indicator illuminates when the elements are cycling ON to maintain set temperature. (Controls the prover air temperature) Humidity Control LO - Humidity setting for butter based pastries... -
Page 12: Operating The Prover
Operation Operating the Prover Ensure that power is supplied to the unit and the water trough is filled It is recommended that the prover operates empty before loading with product - Warm days up to 10 minutes - Cool days up to 30 minutes 1. -
Page 13: Bake-Off
Place thawed products directly from the refrigerator into the pre-heated prover. Prove for 30-60 minutes dependant on product and food proving recommendations. 4. Bake Place proved product directly from the prover into the pre-heated oven. We recommend the E35 Turbofan Oven. -
Page 14: Problem Solving
Operation Problem Solving Product collapses When using frozen dough which collapses or shrinks in the oven after proving, this is caused by too much proving. Reduce the proving time for the next batch. Dry product The dough piece in the prover should never be dry to the touch. A moist, firm and silky membrane should cover the dough piece during proving. -
Page 15: Cleaning And Maintenance
Cleaning Cleaning Guidelines Caution: ALWAYS TURN OFF THE POWER SUPPLY BEFORE CLEANING. THIS UNIT IS NOT WATER PROOF. DO NOT USE WATER JET SPRAY TO CLEAN INTERIOR OR EXTERIOR OF THIS UNIT. Cabinet Clean with a good quality stainless steel cleaning compound. Harsh abrasive cleaners may damage the surface. -
Page 16: Trouble Shooting
Trouble-shooting Fault Possible Cause Remedy The prover does not operate / The mains isolating switch on the Turn on. start. wall, circuit breaker or fuses are “off” at the power board. The power switch on the prover is Rotate switch. Indicator will off. -
Page 17: Spare Parts
Spare parts Replacement Part List Controls 020822 Switch - Power 020823 Knob - Power 014233 Thermostat (Temperature) 015485 Thermostat (Humidity) 020823 Knob - Temperature Thermostat 021472 Knob - Humidity Thermostat 020849 Neon Indicator Auto Fill Option 020851 Solenoid Valve 021534 Relay 022250 Float Switch... -
Page 18: Circuit Schematics
Circuit schematic E85 Prover - Manual Fill... -
Page 19: E85A Prover (Auto Fill)
Circuit Schematic E85A Prover - Auto Fill...
