- Page 1 30MSERIES E 3 0 M 3 ( M a n u a l O p e r a t i o n ) I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l 238760-3...
- Page 2 MANUFACTURED BY Moffat Limited Rolleston 7675 New Zealand INTERNATIONAL CONTACTS AUSTRALIA Moffat Pty Limited E.Mail: vsales@moffat.com.au Main Office: (tel): +61 (03) 9518 3888 (fax): +61 (03 9518 3833 Service: (tel): 1800 622 216 Spares: (tel): 1800 337 963 Customer Service: (tel): 1800 335 315 (fax): 1800 350 281 CANADA...
-
Page 3: Table Of Contents
Contents List E30 Turbofan Convection Oven. Model Numbers Covered in this Manual E30M3 - Turbofan Oven - 3 Tray Convection Oven. Introduction......................2 Safety Information Specifications......................3 Installation ......................4 Installation Requirements Unpacking Location Clearances Stand Mounted Ovens Electrical Connection... -
Page 4: Introduction
If you are unsure of any aspect of the installation, Dealer: instructions or performance of your oven, contact your TURBOFAN dealer promptly. In many cases a phone call could answer your question. Service Provider: Should you contact your TURBOFAN dealer on any matter concerning this oven, please have the information provided opposite, readily available. -
Page 5: Specifications
Specifications E30M3 Oven Tray Details Oven Power Ratings Tray Capacity Tray Spacing 3 x GN 1/1 Pan 230-240V, 1P+N+E, 50/60HZ, 9.5A, 2.3 kW 100mm 3 x US ½ Pan... -
Page 6: Installation
It is most important that this oven is installed correctly and that oven operation is correct before use. If you have any questions regarding the proper installation and / or operation of this oven, please contact your local Turbofan distributor. Clearances Unpacking To ensure correct ventilation for the motor and controls, 1. -
Page 7: Electrical Connection
Installation Electrical Connection Warning This oven must be earthed / grounded. If the supply cord is damaged, it must be replaced by a suitably qualified person in order to avoid a hazard. Each oven should be connected to an adequately protected power supply and an isolation switch mounted adjacent to, but not behind the oven and must be readily accessible to the operator. -
Page 8: Operation
Turbofan Ovens have been designed to provide simple operation. This oven is intended for use in a commercial kitchen and must only be put to the use for which it was intended, i.e. -
Page 9: Using The Oven
Operation Using the Oven Caution Do Not cover the bottom of the oven with aluminium foil or similar material as this may cause damage to the oven liner and oven components and will also reduce the efficiency of the oven. Caution Some parts of this oven will become VERY HOT during use and could cause burns if... -
Page 10: Cleaning And Maintenance
Cleaning and Maintenance Cleaning Guidelines c. Pull side racks forward to disengage the location pins at the rear of rack from the rear wall of the oven and remove the racks from the oven. Caution d. Clean all racks with a mild anti bacterial detergent Always turn electrical... -
Page 11: Periodic Maintenance
Cleaning and Maintenance Door Seal Door Glass Cleaning a. To remove door seal, pull the 1 piece seal forward Ensure that the oven door is cool before cleaning until it pulls out of the location groove around the the oven door glass. oven. -
Page 12: Fault Finding
Fault Finding This section provides a reference to the more common problems You may encounter a problem not covered in this section, please that may occur during the operation of your oven. This fault contact your service provider who will require the following finding guide is intended to help you correct and accurately information:- diagnose problems with your oven. -
Page 13: Electrical Schematics
Electrical Schematics Electrical Schematic E30M3 Turbofan Oven... -
Page 14: Replacement Parts List
For further information and servicing instructions, contact your nearest authorized service provider or Turbofan Dealer. When ordering replacement parts, please quote the part number and the description as listed below. If the part required is not listed below, request the part by description and quote model number and serial number which is shown on the Technical Data Plate. -
Page 15: Appendix 1 - Reversing The Oven Door
Appendix 1 - Oven Door Reversal Reversing the Oven Door 11. Remove inner glass latching studs and fit to opposite Refit all screw fasteners using a low-mid strength side of door using Loctite thread locking adhesive unless otherwise stated. 243 to secure. - Page 16 Appendix 1 - Oven Door Reversal 18. Remove Blanking Screw and Door Catch from front of Adjust Door for Correct Alignment. oven and swap around (refer ‘Adjusting Door Catch’). Check alignment and operation of the door. Ensure that the door is correctly aligned horizontally and vertically. Door Catch Blanking Screw 1.
