Summarization of Contents
Water and Drain Connections
Water Pressure
Specifies water pressure requirements for the oven's vaporizer, between 200-500 kPa.
Water Connection to the Vaporizer
Details water supply for the vaporizer, requiring cold/softened or hot water, with R 3/4" connection.
Water Specifications
Outlines water quality parameters (hardness, pH, chlorides) to prevent corrosion and scaling.
Drain
Mandates a drain cup for a 25mm air gap and prohibits direct connection.
Dismantling and Disposal
Disposal
Equipment must be collected separately at end-of-life due to hazardous substances.
Removing the Control Panel (Version D)
Removing the Control Panel
Step-by-step guide to remove the oven's control panel for maintenance.
Replacing the Control Board Keypad
Instructions for disconnecting and replacing the control board keypad assembly.
Replacing the Glass Panel
Steps to remove and replace the oven's glass panel and associated components.
