88 5050 89
Modern Craftsman
Bar Stool
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Seat
1 pc.
G.
Front Frame
1 pc.
Hardware List
Small
Hex Wrench
1 pc.
Tools required for assembly : Phillips screwdriver
C.
Side Piece
1 pc.
E.
Stretcher
1 pc.
Hex Wrench
Head Cap Bolt
12 Pcs. (+1 extra)
1 pc.
D.
Side Piece
1 pc.
F.
Stretcher
1 pc.
Spring Washer
Flat Washer
12 Pcs. (+1 extra)
12 Pcs. (+1 extra)
B.
Back Frame
1 pc.
Wood Screw
4 Pcs. (+1 extra)

Advertisement

loading
Need help?

Need help?

Do you have a question about the Modern Craftsman Bar Stool and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Home Styles Modern Craftsman Bar Stool

  • Page 1 88 5050 89 Modern Craftsman Bar Stool IMPORTANT NOTE Carefully remove all the parts from the carton and put them individually on a soft cloth to prevent scratches or other damages occuring to the wood parts. We have taken great care in the design of this product and request that you carefully and strictly follow our assembly instructions to ensure a completed product as it was designed.
  • Page 2 Assembly Instruction 2/2 IMPORTANT * Please keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future. * Do not tighten up all the screws until each part is properly assembled. * Use a soft cloth between these parts and the fl...
