Hardware Manual
for the PCD1.M0160E0
Document 27-622 | Version ENG02 | 2018-08-20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCD1.M0160E0 and is the answer not in the manual?

Questions and answers

Related Manuals for SBC PCD1.M0160E0

Summary of Contents for SBC PCD1.M0160E0

  • Page 1 Hardware Manual for the PCD1.M0160E0 Document 27-622 | Version ENG02 | 2018-08-20...

  • Page 2: Table Of Contents

    Mounting on a Flat Surface ..............2-8 Battery ....................2-9 Earthing Concept and Power Supply ............ 2-10 CPU / Processor Unit Propertys of cpu PCD1.M0160E0 ............3-1 General Technical Details ..............3-2 Hardware version number ..............3-3 Firmware Version for the PCD1.M0_ (COSinus update) ....... 3-4 System memory structure ..............
  • Page 3 General Information ................7-1 Battery Replacement for the PCD1 ............7-1 Annex Icons ...................... A-1 A.2 Definition of Serial Interfaces ..............A-2 A.2.1 RS-232 ....................A-2 A.2.2 RS-485/422 ................... A-3 Glossary ....................A-4 Contact ....................A-6 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 4: Document History

    Saia PCD is a registered trademark of Saia-Burgess Controls AG. ® Technical changes are subject to the state of technology. Saia-Burgess Controls AG, 2018. © All rights reserved. Published in Switzerland Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 5: Graphical Overview

    Operation LEDs 3.6.1 USB/PGU Selection of the connection 5.1 analog input range 4.1.7 Ethernet connection Terminals for (2 port switch) 5.2 integrated inputs Slot A connection and outputs terminal 5.4 4.1.1 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 6: Orientation

    System catalogue 26-215_ENG Programming tools Saia PG5 26-732_ENG ® Programming 26-733_ENG Ethernet TCP/IP 26-776_ENG RS-485 Network 26-740_ENG A wealth of information is available on the support homepage. Support: www.saia-support.com PCD-Homepage: www.saia-pcd.com Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 7: Introduction

    PCD controllers include simple, built-in protection features. However, secure operation on the internet is only ensured if external routers are used with a firewall and encrypted VPN connections. For more information, please refer to our support site: www.sbc-support.com/security Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 8: Wiring

    ● Lines installed outdoors must have shielding with a suitable power line capacity and be earthed at both ends. ● Surge conductors should be installed at the control cabinet inlet. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 9: Io Addressing

    ® als. Watchdog relay address “O 255” The address O 255 is reserved for the watchdog relay. The closing relay contact connection is located at connector X3. You can find additional details in Chapter 3.8 Hardware watchdog. Please read this information. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 10: Installation

    0 °C and 55 °C is permissible. Vertical mounting should be preferred. All other positions are less favourable to air circulation, so their ambient temperature should not exceed 40°C. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 11: Installation On Din Rails

    Installation Instructions and Recommendations Installation in Power Distribution Unit The PCD1.M0160E0 measures 142 × 142 × 61 mm, excluding terminals and con- nections. For proper installation, a distance of 55 mm above the DIN rail and 75 mm below is recommended.

  • Page 12: Removal From Top-Hat Rails

    2. Next rotate the PCD1 until one of its two housing sides is in view. 3. Holding the bottom edge of the housing cover with the fingertips of one hand and the I/O connections in the fingers of the other hand, carefully pull on both parts (housing cover and lower part of PCD1) to separate them. PCD1 is mounted Pull off the cover with your finger tips beginning from the upper end hooked under the cover edge. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 13: Mounting On A Flat Surface

    PCD to hang on them. 3. Hang the PCD on the four screws. 4. Fully tighten the top two screws. The bottom two screws are provided as guides and are not tightened. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 14: Battery

    CPU attempts to start the XOB2. If this is not included in the program, the ERROR LED (yellow) begins to blink with a frequency of 500 ms. The battery is included and must be fitted during commissioning. For instructions, see chapter 7 Maintenance. Battery replacement See chapter 7 Maintenance Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 15: Earthing Concept And Power Supply

    1.5 mm 0 V +24 V Supply 1.5 mm / max. 25 cm earthing bar 2-10 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 16: Cpu / Processor Unit

    S-Driver). With a USB 2.0 hub the download takes place twice as fast. It can also be used as a serial data port, for example, in order to connect a terminal; however, this impedes the commis- sioning and troubleshooting with the Debugger. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 17: General Technical Details

    - (2 kV CM and 1 kV DM for AC I/O unshielded) Radiofrequency Interference According to EN61000-4-6: 10 V 150 kHz…80 MHz (conducted) Noise emissions According to EN61000-6-4: for industrial areas Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 18: Hardware Version Number

    Based on this number, the user can check whether a function is provided depending on the hardware. This can be viewed with the Saia PG5 Online Configurator under ˶Hardware Info˝ or on the label on ® the back side of the PCD1. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 19: Firmware Version For The Pcd1.M0_ (Cosinus Update)

    2 minutes. (CPLD programming sequence). Otherwise, there is the risk that the CPU locking, in which case it must be sent back to the manufacturer. The download process is concluded with the restarting of the PCD. The firmware of the PCD1.M0_ is secured on a flash memory on the mother- board. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 20: System Memory Structure

    Flash memory extensions Extension modules Working 256 kByte 128 kByte memory μSD-Flash- 8 MB memory Filesystem Permanent Extension device flash memory (max 1) extensions Memory structure of a PCD1.M0160E0 with additional memory cards Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 21: Flash Memory Structure On Pcd1.M0

    3.5.2 Flash Memory Structure on PCD1.M0_ File system for the user Primarily used for BacNet PLC file system only for FW. The end user cannot access this partition Used for linked web projects (web builder) 3.5.3 On-Board Memory for the File System To use the on-board flash memory, select «PCD Memory»  «Internal» The internal flash memory has the following name: INTFLASH. The absolute path for access to the file is as follows: INTFLASH:/MYFOLDER/MYFILE.TXT Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 22: Flash Memory Module Pcd7.R5Xx For File System

    PCD7.R5xx Flash card status LED (yellow) switches on when the permanent flash memory extensions. The flash card is inserted directly into the main circuit board. A screw in the cover secures the flash card in place. The mechanical cover is designed so that the flash card cannot loosen from the slot due to vibrations. Memory Modules for PCD1.M0_ CPU PCD7.R550M04 Flash memory module with file system Enables the saving of files, such as those for the webserver. The PCD can access the files directly through the FTP or HTTP server and write all PC-readable files (*.csv) directly to the mod- ule. PCD7.R560 BACnet firmware module for slot M1 PCD7.R562 BACnet firmware module for slot M1 with 128 MB for program storage and file system PCD7.R580 Lon over IP firmware module for slot M1 PCD7.R582* Lon over IP firmware module for slot M1 with 128 MByte for program storage and file system Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 23: System Resources

    (.. 999) FB ... PB ... Sub- and function programblocs FB 0 PB 0 SB 31 (95) SB ... SB 0 Sequential programblocs Step 0..2000 (..6000) Transition 0 ..2000 (..6000) Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 24: Data Types / Value Ranges

    Constants without media code user-defined -2’147’483’648 to Can only be loaded to a register +2’147’483’647 with an LD command and cannot be used in instructions instead of registers. To avoid unnecessary load on the CPU, no more timers should be configured than required. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 25: Led Behavior

    - No communications mode on the S-bus PGU or Gateway Master Port System diagnostics Battery fault Flashes at interval of 500 ms Reset The RESET status has the following causes: - Supply voltage too low - Firmware not started 3-10 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 26: Run/Stop Button

    If the button is pressed in Run mode for longer than ½ second and less than 3 seconds, the controller switches to Stop mode and vice versa. If the button is pressed for longer than 3 seconds, the last saved user program is loaded from the flash memory. 3-11 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 27: Watchdog (Hardware Relay)

    If this happens, it can mean the following:  The CPU has stopped (no longer in RUN mode)  Program execution too long (AWL program loops, program too large) 3-12 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 28 RUN. Since address 255 falls it outside the normal I/O range of a PCD1.M0_, there are no limitations on permissible I/O modules. 3-13 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 29: Watchdog (Software)

    “XOB 0” calls are entered in the PCD History as follows: «XOB 0 WDOG START» if XOB 0 was triggered by the watchdog software «XOB 0 START EXEC» if XOB 0 was triggered by a power supply error 3-14 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 30: Program Download And Backup

    Including all media for media mapping. Don´t Clear Outputs Physical outputs with or without media mapping save their values while the new program is transmitted to the execution memory. 3-15 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 31 Including all media for media mapping. Backup to Flash Card Save to flash card Delete old backups Deletes old saved from All Flash Cards programs from all flash cards 3-16 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 32 Once the download has been successfully completed, start the PCD: After the system restart, the user program and ROM DB/text are transferred into the execution memory. This is a write-protected memory, which does not need to be backed up; all data is stored in the PCD file system. 3-17 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 33: Backup And Restore User Program

    PCD_BACKUP *.sbak BACKUP folder must be created. RAM DB/text data is stored in the internal PCD_Backup folder. This allows the backup files to be accessed via the FTP server and then uploaded to a PC. 3-18 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 34 If they are, the restore function will no longer work correctly in this case! The following window will appear. Click OK to start the backup process. 3-19 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 35 ATTENTION: If the button is pressed for longer than 10 seconds, there is the risk of resetting the system and/or deleting the memory. The CPU searches memory locations for backup files in the following order: 1. M1 Flash 2. INTFLASH 3. PLC_SYS 3-20 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 36: Inputs And Outputs

    This chapter describes the inputs and outputs of the PCD1.M2_ in terms of their function and pin assignment. Three possible locations for inputs and outputs are described. Optional extension can be use external RIOs. 4.1 On-Board On-board means mounted “on the CPU mother-board” Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 37: Connection Overview

    /Rx-/Tx “IN“ PGND PGND PGND PGND PGND PGND /RTS SGND* /CTS * SGND is signal return for Rx-Tx-/Rx-/Tx signals and is isolated from PGND +24 VDC 0 VDC Watchdog relay or Output 9 Watchdog relay PGND RS-485 up to 115.2 kbit/s Profi-S bus up to 187.5 kbit/s Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 38: Digital Inputs (Terminal Block X1)

    The terminals No. 15 and No. 16 can be used as an input or as an interrupt (see Section 4.1.7). Int1 24 V interrupt inputs Input signals (always source operation): H = 15...30 V L = - 30...+ 5 V or unconnected Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 39: Digital Outputs (Terminal Block X0)

    Max. 0.5 A Output delay typ. 50 µs, max 100 µs at ohmic load Contact protection Transistors LEDs Connections Plug-in screw terminal block Uext Out0 current Limit 24 VDC Digital outputs Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 40: Digital Inputs And Outputs (Terminal Block X0)

    O 0, ... 3 and I/O 4 ... 7 via the built-in output transistor of the I/Os diode fed back and would feed the device con- nected to the output load. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 41: Pwm Output (Pulse Width Modulation) (Terminal Block X0)

    1 Hz, 4 Hz, 15 Hz, 30 Hz, 61 Hz, 122 Hz, 244 Hz, 488 Hz, 975 Hz, 1950 Hz Duty cycle range 0-100 % Terminal: Plug-in screw terminal block Maximum operating frequency is 2 kHz (rise and fall times are 20 μs). Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 42 Saia-Burgess Controls AG Inputs/Outputs (I/O) On-board │ PWM Output Uext PWM / Out8 current Limit 24 VDC Output Frequency = 1/T PWM Output Duty Cycle = t/T time Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 43: Interrupt Inputs (Terminal Block X1)

    I segnali di ingresso H = 15...30 V (sempre logica positiva): L = - 30...+ 5 V o non collegato Interrupt assignment Terminal Caption Interrupt Called XOB Int0 XOB 20 Int1 XOB 21 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 44 (max. input frequency 1 kHz, whereas the pulse/pause ratio is 1:1, maximum sum of the two frequencies is 1 kHz). Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 45: Analogue Inputs (Terminal Block X1)

    As shown in the following illustration, the analogue input range is selected with configuration switches. C T C T 1 2 3 4 AI1 AI0 SW1 3 OFF4 3 ON4 3 OFF4 SW1 1 OFF2 1 ON2 1 OFF2 4-10 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 46 Current input (-20...+20 mA) Xx / yy 102 % Each time the min./max. values are reached, the min./max. status flag is set. min. value max. value value under over range range 100% The status flag remains set until the status has been read. With media mapping the status flag is read at the end of each COB. This means that the status flag is reset at the end of each COB. With direct access, the status flag is reset as soon as the user program reads the status flag. 4-11 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 47 Resistance -10...+10 V 0...20 mA Connection concept for two-wire transmitters υ 0...20 mA δ 4...20 mA* 24 VDC * 4..20 mA through the user program or in the Saia PG5  Device Configurator  Media Mapping ® 4-12 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 48: Plug-In I/O Module For Slot A

    Floating or grounded (the minus of the outputs is internally con- nected with the PCD ground) Short-circuit protection YES permanent Accuracy @25°C ±0.2 % of the full scale (10 V) Temperature coefficient ±100 ppm/K of the full scale (10 V) 4-13 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 49 Each channel will be updated after the last COB. The status register is updated before the first COB is executed. When using media mapping, it is not possible to detect which channel has not been updated in case of error in the status register. 4-14 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 50 Write command. Status Description if a communication error has been detected (between PCD and module)This bit is automatically cleared when the status register is read 4-15 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 51 If the module has been correctly plugged, the status value is a positive num- ber and all device information can be read. If the module has not been correctly plugged or simply not plugged, the returned value is negative. 4-16 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 52: Rio

    A detailed description is found in Section 4 of the PCD3 manual 26-789. PCD3.C110 Ethernet PCD3.T66x Ethernet RIO PCD3.C110 PCD3.T76x Expansion of the PCD1.M0160E0 is possible with PCD3.T66x and PCD3.T76x RIO modules. 4-17 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 53: Pcd1.M0160E0 Communications Interfaces

    The word “port” will be used for the remainder of this manual instead of “communications interface” for the purpose of simplification. Using the SBC S-Bus SBC S-Bus stands for the proprietary communications protocol of Saia PCD ® The SBC S-Bus is basically designed for communications using the engineering and debugging tools, as well as for connection to management levels/process control systems. It is not suitable or approved for connecting the field devices of...

  • Page 54: On-Board

    USB driver. To connect the PCD via USB, the following setting is required in the PG5 project folder for the device concerned under “Online settings”: Activating the “PGU option” ensures that the PCD connected to the PC can be reached directly, independently of the configured S-Bus address. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 55: Ethernet (Port #9)

    Ethernet connections. Both sockets can be used independently of one another. ETH1 ETH2 Function: 2 port switch Jack type: 2 RJ45s vertically positioned, metal housing, 2 LEDs each Meaning of the LEDs per jack: Orange LED Link (connection) and activity Green LED Speed Off = 10Mbits / On = 100 Mbits Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 56: Rs-485 (Port #0, Not Electrically Isolated)

    150 Ohm RX - TX Pull down 330 Ohm Segment length max. 1200 m max. 32 stations For more details see in the manual 26-740, Installation components for RS-485 Networks. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 57: Slot A (Port #1)

    PCD7.F1xxS PCD7.F1xxS PCD7.F1xx not with housing, previous design compatible with 2012 or later PCD1.M2_ Important: PCD7.F1xxS devices with hardware version A are not compatible with earlier PCDs (PCD1.M1xx/PCD2.M1xx/PCD2.M48x/PCS1) from NT- based PCD systems. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 58 The hardware version can be seen on the white label of a PCD7.F1xxS module in the middle text line. Solution Only use PCD7.F1xxS interface modules PCD7.F1xxS with hardware version B or newer. These are suitable for all PCD generations. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 59: Pcd7.F110S Serial Interface Module Rs-485/Rs-422

    Terminal Block Bus cable (DTE) PGND PGND PGND PGND /RTS /RTS /CTS /CTS Strands twisted and shielded For more details see in the manual 26-740, Installation components for RS-485 Networks. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 60: Pcd7.F121S Serial Interface Module Rs-232

    PCD1.M0_ peripheral 9 pole 25 pole Terminal Block Bus cable PGND PGND PGND PGND Cabling for Modem connection: PCD1.M0_ RS-232 Modem Terminal Block Bus cable PGND PGND PGND PGND Reserve Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 61: Pcd7.F150S Serial Interface Module Rs-485

    PGND PGND SGND With the use of this module, the permissible ambient temperature is reduced by 5°C. For more details see in the Manual 26-740, Installation components for RS-485 Networks. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 62: Pcd7.F180S Serial Interface Module Belimo Mp-Bus

    - MFT(2) valve drives - MFT fire protection flap drives - VAV compact controller NMV-D2M 22 “MFT“ MFT programming device (MP bus internal) 23 “IN“ MFT programming device recognition (input 10 kΩ, Z5V1) 25 PGND Earth connection, MFT programming unit 5-10 Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 63: Configuration

    For the PCD1.M0_, I/O handling is always enabled via direct access. There is no “bit” access instruction: the minimum access range is “byte”. You are therefore ad- vised to use media mapping to read and write all I/O channels. For further details, see the online help of the Device Configurator Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 64: Running The Device Configurator

    Saia-Burgess Controls AG Configuration (Device Configurator) Requirement / General Information 6.3 Running the Device Configurator Um HW-Konfiguration, Protokolleinrichtung und E/A-Behandlung einzurichten ist der De- vice- bzw. Gerätekonfigurator zu verwenden. The Device Configurator is started by double- clicking on the “Device Configurator” symbol in the project directory tree. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 65 Saia-Burgess Controls AG Configuration (Device Configurator) Device Configurator Help Help for the Device Configurator can be found under “Help Topics” in the “Help” menu: Click on one of the “Help topics”: Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 66: Media Mapping For Digital Inputs On-Board

    Configuration (Device Configurator) I/O Media Mapping 6.4 Media Mapping for Digital Inputs on-board The media mapping of digital inputs uses 16 flags Mapping table for digital inputs 6.5 Media Mapping for Digital Outputs on-board The media mapping of digital outputs uses 16 flags Mapping table for digital outputs Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 67: Special Functions

    Select whether the watchdog channel should be used as a watchdog output or standard relay output Select whether the interrupt channels should be used as interrupts or standard digital inputs Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 68: Analogue Inputs

    Saia-Burgess Controls AG Configuration (Device Configurator) Special functions | analogue inputs 6.7 Analogue inputs Properties Mapping setup for values and status or diagnosis Channel setup and scaling information Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 69 Saia-Burgess Controls AG Configuration (Device Configurator) Special functions | analogue inputs Mapping table for analogue inputs Mapping table for status of analogue inputs Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 70: Maintenance

    (battery voltage less than 2.4V) the triangular yellow LED blinks and XOB 2 is called. In order to prevent data loss, we recommend changing the batteries while the PCD1 is still connected to the power supply. See next page for battery replacement procedure. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 71 The + symbol can also be seen on the circuit board. Fit the housing cover. Check the battery display (red LED dark) Battery o.k. = yellow, triangular LED dark Batteryfailer = yellow, triangular LED blinking Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 72: A Annex

    This sign accompanies instructions that must always be followed. Explanations beside this sign are valid only for the SBC PCD Classic series. Explanations beside this sign are valid only for the SBC PCD xx7 series. Hardware Manual PCD1.M0160E0 │ Document 27-622...

  • Page 73: Definition Of Serial Interfaces

    +7 V 1 (character) -15 V to -3 V -7 V Control/message signal 0 (off) -15 V to -3 V -7 V 1 (on) +3 V to +15 V +7 V Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 74: A.2.2 Rs-485/422

    In order to ensure fault-free operation of an RS-485 network, the network should be closed at both ends. Cables and terminators should be selected according to Manual 26-740 “Installation Components for RS-485 Networks”. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 75: Glossary

    Inputs/outputs on the CPU (on-board) or connected through the I/O bus on the CPU. Slot Slot for plug-in Saia PCD Project Manager, main program of the Saia ® package ® Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...
  • Page 76 Reflections at the line ends are prevented through line termination. PCD2.M2xxx x in the product designation stands for a number 0..9. In this case it is a three-digit number, such as PCD2.M2110. Hardware Manual PCD1.M0160E0 │ Document 27-622 Version ENG04 │ 2018-08-20...

  • Page 77: Contact

    Addresses Contact Saia-Burgess Controls AG Bahnhofstrasse 18 3280 Murten, Switzerland Phone central ......+41 26 580 30 00 Phone SBC Support ....+41 26 580 31 00 Fax .......... +41 26 580 34 99 Email support: ......support@saia-pcd.com upportsite: ......www.sbc-support.com SBC site: ........
