3 .3 Bench mount kit horizontal 3080

12
11
10
9
1 Brake block
2 Holder for strap reel
3 Deflection roller
4 Column
5 Control boxes
6 Compressed air filter
7 Mounting angle bracket
8 Tool holder
9 ATS3080
10 Reset button
11 BMK closure chain guide
12 Holder for closure reel
The Bench mount kit horizontal 3080 enables the
ATS3080 to be held in a horizontal position, turned
sideways. The Bench mount kit horizontal 3080 is bolted
to the base by mounting angle bracket
This bundling is carried out vertically by the ATS3080
An automatic binding is triggered by the control unit
à "Control unit" on page 13.
Assembly instructions Bench mount kit, horizontal, 3080 • 03-2017 • v02 • 102-01011

4 Transport, scope of supply and storage

1

4 .1 Transporting the device

Always use the supplied box to transport the Bench
mount kit horizontal 3080.
The components of the Bench mount kit horizontal 3080
are packaged for transport.
NOTE
Components not correctly packed are subject to a risk of
damage in transit.
f Do not unpack components until just before they are
2

4 .2 Scope of supply

3
Name
Assembly Instructions
Power pack 3080 24 V
4
Push button switch
Deflection roller (x3)
Spring for deflection roller
Foot pedal cable 2m [X1]*
Plug connector for PLC, with cable 2m [X2]*
Plug connector for PLC, with cable 2m [X3]*
5
Limiting block 30/50
6 Limiting block 80
BMK 3080 closure chain guide
*) X1 ... X3: à "Connection plan" on page 18

4 .3 Disposal

The operating company is under obligation to ensure
7
that at the end of its useful life, the ATS3080 and the
components including the accessories are disposed of in
accordance with the applicable local regulations. End-of-
8
life (EOL) disposal of the ATS3080 and individual
subassemblies and the disposal of consumables and
auxiliaries are subject in part to statutory regulations.
The appropriate local authorities will provide detailed
information on request.
f Always dispose of packaging materials in accordance
f Always take materials, production waste and
f Contact the manufacturer for advice if there is any lack
.
7
.
9
Transport, scope of supply and storage
going to be installed.
with the currently valid materials-disposal and
environmental protection regulations.
consumables for disposal to certified collection points.
of clarity regarding disposal.
Article number
102-01011
102-00142
123-90055
102-73026
102-74006
123-90061
102-00214
102-00215
102-10063
102-10064
102-00325
7
