Inserting The Bmk Closure Chain Guide; Inserting The Closure Reel - HellermannTyton Autotool System 3080 Assembly Instructions Manual

f Connect Power pack 3080
the power supply à "Interface overview, Power pack
3080" on page 15.
f Connect compressed air connection
compressed air supply system.
f Make sure that all the wiring is free of kinks.
f Check that compressed air connection
leak-tight.
f Make sure that there is nothing to obstruct accessibility
to ATS3080 , Power pack 3080
2
and reel holders .
5

5 .1 .5 Inserting the BMK closure chain guide

1
3
f Pull out locking pin
.
2
f Insert holder of closure chain guide
1
f Allow locking pin to lock firmly into place.
2
Assembly instructions Bench mount kit, horizontal, 3080 • 03-2017 • v02 • 102-01011
to the ATS3080 and to
1 2
to the
4
is secure and
4
, control boxes
1 3
2
.
3

5 .1 .6 Inserting the closure reel

1
8
7
6
f Remove closure reel from its packaging and remove
1
the protective mesh.
f Push in sleeve of articulated shaft
2
inward.
f Insert closure reel onto reel mount
1
position in this process.
; The closure reel uncoils clockwise.
1
; The collar of the bearing
Bench mount kit horizontal 3080.
f Introduce closure chain
into closure chain guide
f Feed closure chain through closure chain guide
7
ATS3080 .
5
f Make sure that the closure chain
7
9
f Open cover of ATS3080
9
f Insert closure chain
into the ATS3080
7
of first engagement.
; The red LED in the display goes out.
