ELECTRONIC AUTOFOLDER
Specifications
Functional
Paper Weight . . . . . . .16# to 28# Bond Stock (60g-105g)
Form Width . . . . . . . . . . . . . . . . . . .3.5" min. to 8.5" max.
Form Length . . . . . . . . . . . . . . . . . . . .5" min. to 14" max.
Feed Table Capacity . . . . . . . . . . . . . .150 Sheets of 20#
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . and Brochure
Stapled Documents . . . . . . . .5 20# sheets max, hand fed
Physical
Dimensions . . . . . . . .20.6"Wide X 15.3"Deep X 17.5"High
Machine Weight . . . . . . . . . . . . . . . . . . . . . . . . . . .39 lbs.
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . . . . .44 lbs.
Electrical
Power . . .115 V.A.C., 1.3 Amp, Thermal Overload Protected
Introduction
Thank you for selecting the Martin Yale Model 1701 Autofolder. We recommend that you familiar-
ize yourself with the Model 1701 Autofolder by carefully reading these instructions. Thorough
understanding of the information contained within this instruction manual will help to eliminate most
operator-associated errors and ensure years of trouble-free performance.
WARNING! Never connect power to the machine until you are ready to set up and operate
the folder. During set up, operation, and maintenance keep hands, hair, loose clothing, and
jewelry away from all moving parts. Serious bodily injury could result. Service or disas-
sembly of the folder should only be attempted with the power disconnected and locked out.
R
MODEL 1701
Serial No.

Table of Contents

1.0 Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . Page 2
2.0 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . Page 2
2.1 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . Page 2
2.2 Feed Table . . . . . . . . . . . . . . . . . . . . . . . . . . Page 2
2.3 Paper Guide Adjustment. . . . . . . . . . . . . . . . Page 3
2.4 Exit Ramp Set-up. . . . . . . . . . . . . . . . . . . . . Page 3
2.5 Stacking Wheel Set-up . . . . . . . . . . . . . . . . . Page 3
3.0 Display and Fold Set-up. . . . . . . . . . . . . . . . Page 4
3.1 Fold Styles . . . . . . . . . . . . . . . . . . . . . . . . . . Page 4
3.2 Selecting Pre-set Folds . . . . . . . . . . . . . . . . . Page 5
3.3 Selecting Custom Folds . . . . . . . . . . . . . . . . Page 5
4.0 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5
4.1 Automatic Feed Operation . . . . . . . . . . . . . . Page 5
4.3 Folding Stapled Multiple Sets . . . . . . . . . . . . . . . Page 6
5.0 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . Page 6
5.2 Clearing Paper Jams . . . . . . . . . . . . . . . . . . Page 7
5.3 Feed Wheel Cleaning. . . . . . . . . . . . . . . . . . Page 7
5.4 Bushings and Folding Rollers . . . . . . . . . . . . Page 7
6.0 Troubleshooting Guide . . . . . . . . . . . . . . . . Page 8
6.1 Machine will not run . . . . . . . . . . . . . . . . . . . Page 8
6.2 Paper will not feed . . . . . . . . . . . . . . . . . . . . Page 8
6.3 Crooked folds. . . . . . . . . . . . . . . . . . . . . . . . Page 8
6.4 Ink smudges on paper . . . . . . . . . . . . . . . . . Page 8
6.5 Wrinkled paper. . . . . . . . . . . . . . . . . . . . . . . Page 8
