Victron energy MPPT Control Manual page 3

The topics are listed in the table below. Only topics marked with a * are visible in case of 2 day history.
Settings
By pressing SETUP for 2 seconds in the status menu, the settings menu is entered. Here, the settings of the MPPT and MPPT Control
can be viewed and changed. First the topic is shown and when SELECT is pressed, the corresponding value is shown. When SELECT
TO EDIT is OFF, the value is shown before it can be changed by pressing SELECT again. When SELECT TO EDIT is ON, the current
value is shown and a new value can immediately be selected. When LOCK SETUP is ON, settings only be changed after setting LOCK
SETUP to off.
Victron Energy B.V. | De Paal 35 | 1351 JG Almere | The Netherlands
General phone: +31 (0)36 535 97 00 | Fax: +31 (0)36 535 97 40
E-mail: sales@victronenergy.com | www.victronenergy.com
Overall topics
TOTAL YIELD*
MAX PANEL VOLTAGE
MAX BATTERY VOLTAGE
MIN BATTERY VOLTAGE
LAST ERRORS
Daily topics
YIELD*
MAX POWER*
MAX PANEL VOLTAGE
MAX BATTERY CURRENT
MAX BATTERY VOLTAGE
MIN BATTERY VOLTAGE
BULK TIME
ABSORPTION TIME
FLOAT TIME
LAST ERROR
The cumulative yield since the last history reset
The maximum panel voltage since the last history reset
The maximum battery voltage since the last history reset
The minimum battery voltage since the last history reset.
(Only available for MPPT software version >= 1.17)
The last 4 errors since the last history reset.
The number of blocks in the lower right of the screens determines
which error is currently shown with 1 block being the latest and 4
blocks being the oldest.
The daily yield
The maximum power per day
The maximum panel voltage per day
The maximum battery current per day
The maximum battery voltage per day
The minimum battery voltage per day
The time spend in bulk per day
The time spend in absorption per day
The time spend in float per day
The last 4 errors per day
The number of blocks in the lower right of the screens determines
which error is currently shown.
