R400A Menu Options

SetUpRx
The SetUpRx menu accesses the screens used to set up the receiver. These
screens include: Freq, Level, Tuning, Compat, Tone, PilotBP, Phase, TxBatt
and SmartNR.
Freq
The Freq setup screen displays the TV channel, the associated transmitter
Frequency Select Switch settings and the selected operating frequency for the
R400A. To change the operating frequency, rotate the MENU control. Exit this
setup screen by pressing the PREV MENU button. The receiver will retain its
tuning even when the power is off.
Note: Remember to set the transmitter to match.
Level-B
The Level-B setup screen displays the audio output level of the receiver in
dBu at the balanced XLR jack.
Level-U
The Level-U setup screen displays the audio output level of the receiver in
dBu at the unbalanced 1/4-inch jack.
Tuning
The R400A offers 7 tuning modes: Normal mode (default), 4 factory set
frequency groups (Fact Grp A thru D), and 2 user programmable frequency
groups (User Grp U and V). For more information on tuning groups, see
owner's manual. In normal tuning mode, all 256 channels are available.
Compat
The Compat setup screen is used to select the compatibility mode, allowing
the R400A to operate with a variety of transmitters. The available compatibility
modes are:
NU Hybrid - This mode works with Lectrosonics Digital Hybrid transmit-
ters using ETSI compliant Nu Digital Hybrid compatibility mode.
100 Series - This mode works with all Lectrosonics 100 Series compat-
ible transmitters.
200 Series - This mode works with all Lectrosonics 200 Series compat-
ible transmitters.
NA Hybrid - is the best mode to use when both transmitter and receiver
are North American Digital Hybrid Wireless models (not Euro/E01 vari-
ants).
IFB - This mode works with all Lectrosonics IFB compatible transmitters.
MODE 3 and MODE 6* - These modes work with a number of non-Lec-
trosonics analog transmitters. Contact the company for a list of compat-
ible transmitters for each mode.
*Mode 6 available on units with Serial Number 236 and up
