R400A Menu Options

The R400A Menu functions can be divided into four main areas: setting up the
receiver, automatic clear channel selection, locking the receiver and scanning
for clear frequencies.

SetUpRx

The SetUpRx menu accesses the screens used to set up the receiver. These
screens include: Freq, Level, Tuning, Compat, Tone, PilotBP, Phase, TxBatt
and SmartNR.

Freq

The Freq setup screen displays the TV channel, the associated transmitter
Frequency Select Switch settings and the selected operating frequency for
the R400A. To change the operating frequency, rotate the MENU control. Exit
this setup screen by pressing the PREV MENU button. The receiver will retain
its tuning even when the power is off.
Note: If the operating frequency is changed, ensure that the Frequency
Select Switch settings of the associated transmitter match the settings
shown in the upper right hand corner of this screen.

Level-B

The Level-B setup screen displays the audio output level of the receiver in
dBu at the balanced XLR jack.

Level-U

The Level-U setup screen displays the audio output level of the receiver in
dBu at the unbalanced 1/4-inch jack.

Tuning

The R400A offers 7 tuning modes: Normal mode (default), 4 factory set
frequency groups (Fact Grp A thru D), and 2 user programmable frequency
groups (User Grp U and V). For more information on tuning groups, see
owner's manual. In normal tuning mode, all 256 channels are available.

Compat

The Compat setup screen is used to select the compatibility mode, allowing
the R400A to operate with a variety of transmitters. The available compatibility
modes are:
400 - This is the factory default setting and works with all Lectrosonics
400 Series Digital Hybrid Wireless™ transmitters. This mode
offers the best audio quality.
IFB - This mode works with all Lectrosonics IFB compatible transmitters.
100 - This mode works with Lectrosonics 100 Series compatible transmitters.
200 - This mode works with Lectrosonics 200 Series compatible transmitters.
