1.3 Main components

1.3.1 Controls and connectors

Figure 3
Module key
Zero P8
Connector
CCO
P8
D25 connector
1.3.2

E-PiCCO module

The E-PiCCO module has a measurement board and a PI input board. The PI input board has
been attached to the front chassis with the CCO and the invasive pressure connectors.

1.3.3 Measurement board

The measurement board consists of the following functional sections:
•
Processor
•
Cardiac output measurement
•
Invasive blood pressure measurement
Front panel of Continuous Cardiac Output Module, E-PiCCO, and the
back of the module.
Module
E-PiCCO
Module
E-PiCCO
E-PiCCO
E-PiCCO
Continuous Cardiac Output Module, E-PiCCO
Description
Key for pressure zeroing
Description
Connector for continuous
cardiac output measurement
Connector for invasive blood
pressure measurement
Module bus connector
3 - 3
2062973-004
