Doohan iTango Service Manual page 19

Ass,Pull rod of ball head, Steering knuckle axletree assy
Sequence
of
Operation
Disassemble the ball head rod assy
M10,Hexagonal flange iron self-locking
1 nut
2 Pull rod of ball head, assy
3
4
5 Spacer assy,bracket plate of steering
knuckle.
Spare parts name
M10×60,Hexagonal flange bolt
Steering knuckle axle assy
Quantities
2 Disassemble parts in order
1
2 Attention
Both sides is symmetrical, Don't
1
1 need to remove both sides when one
side need to service.
Parts assembling with the reverse order
of disassembling.
Remarks
