Please read this operation manual carefully. Do not use

the vehicle until you have a full understanding of its

performance.

Please keep the operation manual properly

DH-18(iDou)model

User Manual 2019 version

Need help?

Do you have a question about the iDou 2019 and is the answer not in the manual?

Questions and answers

Summary of Contents for Doohan iDou 2019

Page 1 Please read this operation manual carefully. Do not use the vehicle until you have a full understanding of its performance. Please keep the operation manual properly DH-18(iDou)model User Manual 2019 version...
Page 2 Thank you for choosing to buy the electric scooter. Our company and all staff sincerely welcome and thank you for your choice. Driving safely is the most important thing for Doohan. For the safety of you and others, please read this product manual carefully before use.
Page 3 1) remind users to abide by traffic regulations and pay attention to driving safety. Such as: A) electric motorcycles shall be driven in accordance with local regulations and the maximum speed shall not exceed 45km / h; B) caution: do not lend the electric motorcycle to the person who will not operate it, so as to avoid injury;...
Page 4 Such as: A) electric motorcycles shall not be parked in the building hall, evacuation stairs, walkways and emergency exits; B) electric motorcycles shall not be charged and parked in residential buildings, and shall be kept away from combustibles during charging, and the charging time shall not be too long;...
Page 5 safety line marks of handlebar risers and saddles (when applicable). 3) check before riding. If there is any abnormality, please repair it in time or find a professional one. Such as: A) power circuit, lighting circuit and other states; B) whether the front and rear gates can work normally; C) fastening status of handlebars and front and rear wheels;...
Page 6 C) main technical parameters in Appendix A of this standard. The driver should understand: ● master the operation of all parts of the electric motorcycle. ● pay attention to the warning and maintenance related information in the manual. ● some simple basic problems of electric motorcycles can be solved through the manual.
Page 7 manual. If you have any questions about this manual, please consult with the distributor of Yuha electric motorcycle. Warning: please read this manual carefully and do not operate your motorcycle until you have safe and proper riding technology. Please check and maintain the motorcycle regularly, and have good riding skills, which will ensure that you can operate the motorcycle safely.
Page 8 . Instructions for use  Under the condition that the front and rear tire pressures of the vehicle are normal  (see the main technical parameters for details), the maximum total mass of the...
Page 9 vehicle is 180kg (including the weight of sundries and goods carried by the vehicle and the weight of the driver and passengers themselves), and one person is limited. the vehicle's tool box, glove box, hook and other storage facilities can only place ...
Page 10 responsible for the loss caused. If you need to replace parts, you can consult with your electric vehicle dealer after sales. Be careful: When the front and rear wheels of the vehicle are on the ground, the rider is not sitting on the saddle and is not ready for riding, do not turn on the power and turn the handlebar to prevent the vehicle from suddenly rushing forward and causing safety accidents.
Page 11 vehicle first, so as to prevent accidents. ● this motorcycle only carries one driver. ● the user shall abide by the traffic regulations and pay attention to the driving safety. 1) the electric motorcycle shall be driven in the non motor vehicle lane with the maximum speed not exceeding 45km / h;...
Page 12 ● due to the small size of motorcycles, accidents often occur between motorcycles and automobiles due to the sight. Many of these accidents are caused by the fact that the driver didn't find the motorcycle. So drivers make motorcycles more conspicuous, which will reduce the probability of such accidents.
Page 13 Correct Wrong Wrong 2. Main Specification data Measurement...
Page 14 Long 1630mm Wide 715mm Height 1035mm Base 1210mm Main performance curb weight 57kg Designed Max speed 45km/h Rated Voltage Maximum nuclear load 180kg Passenger 1 person Frame Front Shock absorber Tube Rear Shock absorber Spring and oil damping type Front tire 70/90-12 Rear tire 90/70-12...
Page 15 Rr. Tire Pressure 225±10(Kpa) Fr. Wheel(alloy) 16×2.50 Rr. Motor wheel 2.15X12 Front brake Disk Rr. brake Disk Seat height 710mm Battery system Vehicle type Electric scooter Battery 18650 Ternary lithium battery Voltage Capacity 26AH Charging input voltage AC220V...
Page 16 Charging output voltage 58.1V Charging current Standard charging time Range 74km Battery weight Charging times 600 times Using temperature -20℃-60℃ 1 month: -20~60°C Battery storage 3 months: -20~45°C 1 year: -20~20°C Charging environment Temp. 0℃ to 45℃ Battery protection Over discharge protection, short...
Page 17 circuit protection, temperature protection, over charge protection, over current protection, battery balance protection others Instrument Fr. Head light 12V LED Fr. Location light 12V LED Fr. Turning signal 12V LED Rr. Turning signal 12V LED Rr. light 12V LED...
Page 18 License plate light 12V LED...
Page 19 3. Main parts...
Page 21 4. Remote control, one button start and APP UNLOCK ① when you press the unlocking key, there is a prompt sound "didi" (2) press one key to start, then you can drive the vehicle. LOCK when you finish driving, press one key to start, the vehicle locks successfully, and the car automatically enters the primary level.
Page 22 5. Use of steering lock...
Page 23 6. Instrument cluster and combination switch 启停状态显示故障图标显示区...
Page 24 Instrument icon Description： The remaining battery capacity is displayed, each cell represents 10% The battery capacity percentage shows that when the battery capacity is lower than 30%, the left battery symbol flashes. Current real-time speed display, supporting public mile switching Display of accumulated mileage of the whole vehicle, supporting public mile switching...
Page 25 High beam display Driving light display Lock status display (only applicable to high configuration models) Fault code prompt On / Off switch locking prompt...
Page 26 Left turn signal display Right turn signal display Vehicle ready for power on display The whole vehicle belongs to cruise status prompt (optional) Normal display of network permission (only applicable to high configuration models) Normal display of Bluetooth connection (only for high configuration models)
Page 27 Normal display of GPS positioning (only for high configuration models) Motor fault notice Brake status notice Controller fault Notice...
Page 28 Turning handle fault Notice Fault prompt of side support...
Page 29 Left combination switch:： dimmer switch ： Press " " button, high beam Press " " button, low beam turn signal switch： When you dial " " the right turn light is on When dialing to " ", the left turn light is on When the middle position is pressed, the signal light goes out.
Page 30 horn button: When the switch button is pressed, the horn will sound. Alert other vehicles Right combination switch: start button: Press this switch button once, the vehicle will change from static state to dynamic state, and then press reset to return to standby state.
Page 31 7. Battery usage battery indicator 1 、 In the charging state, the indicator light flashes to display the current power; charging After full, all indicator lights will be on and no longer flash. 2、 In the non charging state, press the power display key: ●...
Page 32 ● one green indicator light: indicating 20% of electricity < RSOC < 50% ● two green indicator lights: indicating 50% of electricity < RSOC < 80% ● three green indicating lights: indicating 80% of electricity < RSOC < 95% ● all indicator lights are on: indicating power 95% ＜ RSOC ●If all indicator lights are not on, it means the battery is faulty.
Page 33 Charging mode ： Charging mode 1: Take out the battery box, place the charger stably, insert the charger output plug into the charging socket of the battery box, and then insert the charger input plug into the household 220V standard socket. Charging mode 2: Please turn off the power and remove the key.
Page 34 Attention: It is forbidden to charge the battery box when it is inverted, otherwise the battery life will be seriously affected. 电池充电环境  Please charge the battery within the ambient temperature of O ℃ ~ 35 ℃.  the charging time shall not exceed 10 hours, and overcharge will shorten the service life of the battery.
Page 35  Attention:  ① the battery is not a user serviceable part. In case of failure or the battery is not fully charged for more than 10 hours, please stop charging and consult the dealer.  ② the charging function is turned off when the ambient temperature is below 0 ℃, please charge the battery in the environment above 0 ℃.
Page 36 extent. The specific reference degree is that the usable capacity at - 10 ℃ is 70%, the usable capacity at O ℃ is 85%, and the usable capacity at 25 ℃ is 100%.  ⑥ the most suitable storage capacity of the battery is 30% - 50%. If the storage capacity is less than 10% for a long time, it will cause irreversible capacity degradation of the battery.
Page 37 heat, smoke, fire or explosion. Warning: Disassembling the battery without permission may cause leakage, heat, smoke, fire or explosion of the battery!!!
Page 38 8. Troubleshooting Refer to handling methods for common faults Troubleshoo Causes Elimination methods ting Turn on the power, 1. battery plug is not inserted. 1. Charge the battery whole vehicle 2. Battery is dead 2. Replace the battery has no power 3.
Page 39 control knob, 3. Vehicle not started when starting the motor 4. The accelerating handle is not reset 3. Start the vehicle does not 4. Reset the handle start. 1. Low battery 1. Charging or charger is 2. Insufficient tire pressure damaged.
Page 40 cannot contact with the battery plug is loose. charged. socket. 2. Replace charger 2. Charger damaged 3. Plug in and charge 3. The charging wire is not again according connected in the right order. charging mode sequence Stop during battery is dead charge the battery riding...
Page 41 9. Maintenance and repair In order to extend the service life of the locomotive and make it run safely and comfortably, please check and maintain the vehicle regularly. If the vehicle is stopped for a long time, regular inspection shall also be carried out. Daily inspection and adjustment Before driving every day, the vehicle shall be checked regularly, and the importance of these checks shall not be ignored.
Page 42 check whether the chain works normally Check parts key points (1) is stable; (2) it can rotate flexibly; (3) there The steering handle is no axial movement and looseness. the brake handle shall have a stroke of 10-20mm Brake system (1) normal tire pressure (2) degree of wear (3) no Tire cracks or cuts...
Page 43 operate all lights: check whether the high beam, low Lights beam, brake and turn lights are normal. check whether the horn works normally Horn check whether the chain works normally, The moving Chain distance is 10-15 mm. 1：Brake 1) free travel of brake handle The brake handle shall have proper clearance.
Page 44 The distance to the tight position. 2) brake fluid inspection: (1) put the handlebar upright and check the brake fluid in the oil reservoir. Must be maintained between the upper and lower limit markers. (2) when the liquid level drops to the lower limit position mark, check the wear condition of the brake pad.
Page 45 ※Note: when the brake system needs to be maintained or repaired, the dealer of the company shall be responsible for the maintenance. When parts need to be replaced, the original parts of our company must be selected. 2: tire (1) the tire pressure shall be checked and adjusted regularly. (2) check the tire pressure when the tire is cold.
Page 46 If any damage is found, the maintenance department should be contacted Check. (5) when the tread pattern is worn to the sharp corner of the tread wear mark "▽". You should replace the tire immediately. ※ Warning: (1) if the tire pressure is too high, the tire may blow out during driving, resulting in traffic accidents;...
Page 47 Check whether the left and right turn lights and rear tail lights work normally. If not, replace them in time. 4: horn Check whether the horn sounds normally. If not, adjust or replace it in time. 5: speed control knob Whether the speed regulating handle is effective, accelerated evenly, and can return to the position automatically.
Page 48 part cycle Steering 1 year grease (calcium base grease) column Front and rear 1 year grease (calcium base grease) axle central shaft 1 year grease (calcium base grease) Pedal shaft 1 year grease (calcium base grease) Sprocket 1 week lubricating oil Chain 1 week Inside of...
Page 49 Regular maintenance Please carry out the first maintenance one month after purchasing or driving 500km, and then go to the special maintenance department of our company every six months or 3000km for comprehensive inspection and maintenance, so as to keep your car in the best safe condition and ensure the safety of riders and vehicles.
Page 50 parts Fuse battery Tire Main cable Main part Structural Lubricating Controlling system check Attention: ① if it is often used under full load, heavy load, high-speed driving, bumpy road, up and down slope, please shorten the maintenance period; ② the original parts are made of good materials and have been rigorously verified.
Page 51 parts during maintenance to ensure that the vehicle is in the best condition, driving safety and normal warranty service. during daily maintenance, if any abnormality is found during inspection and maintenance, it shall be cleaned, repaired or replaced in time. Please refer to the simple maintenance method or send the smart electric vehicle to the dealer for repair.
Page 52 4) when the battery is stored for a long time and reused, please fully charge the battery; 5) when the vehicles equipped with batteries are stored in safe places such as indoor, exhibition hall and warehouse, or when the freight vehicles are used for short distance transportation, please close and pull out the key, and then pull out the battery plug, so as to eliminate the hidden trouble of electrical appliances.
Page 53 2) for long-term storage, please charge and discharge the battery once every two months, and store the battery when the battery is charged to 30% - 50% to ensure the service life of the battery; 3) when the battery is stored for a long time and reused, please fully charge the battery;...
Page 54 11. 电气原理图：...
