Technical Data

Parameter
Dimensions, W × H × D
Sealing
Frame material
Weight
CPU
Serial ports
Ethernet LAN A
Ethernet LAN B
USB
External storage
media
Flash memory
(application
memory)
Memory RAM
NVRAM
Real time clock
Battery
Power consumption
at rated voltage
Fuse
Power supply
Operating
temperature
Storage temperature
Relative humidity in
operation
Vibration
Mechanical shock
Approvals and
certifications
Beijer Electronics, MAEN275
128 × 101 × 39 mm
IP 20
Powder-coated aluminum
0.4 kg
i.MX 6DualLite
Dual ARM Cortex-A9 Core
1.0 GHz
512 kB L2 cache
Standard D-sub (9 Pin, female)
COM1: RS-232 with RTS/CTS
COM2: RS-422/RS-485
COM3: RS-485
10/100 Mbit Base-T (shielded RJ45 with LEDs)
10/100 Mbit Base-T (shielded RJ45 with LEDs)
1 × USB Host 2.0, max output current 500 mA
Supports up to USB 2.0 High Speed
1 × SD card
1.5 GB SSD (eMMC)
1 GB DDR3
128 kB
Yes
BR 2032 lithium battery,
replaceable
5 W
Internal DC fuse, 3.14 AT, 5 × 20 mm
+24 V DC (18–32 V DC)
CE: The power supply must conform with the requirements
according to EN/IEC 60950 and EN/IEC 61558-2-4.
UL and cUL: The power supply must conform with the
requirements for class 2 power supplies.
-10°C to +60°C
-20°C to +70°C
5% – 85% non-condensation
1g, according to EN/IEC 60068-2-6, Test Fc
15g, half-sine, 11ms according to EN/IEC60068-2-27
CE / FCC / KC
Information is available on
BoX2 pro
www.beijerelectronics.com
