RECOMMENDED PORTS TO USE FOR EXTERNAL
STORAGE
For clarity, the following figure reiterates the recommended ports to use for external
storage. In most configurations, the storage ports (ID 1 below) should be used for
connecting to high-speed NAS storage, while the cluster ports (ID 2 below) should be
used for communication between nodes.
ID Connectivity
1 ConnectX-5 (LP)
2 ConnectX-5
InfiniBand mode
Ethernet mode
DGX-2 System User Guide
Uses Number of
Ports
(Right):
enp134s0f1
Clustering 8
Storage
Uses Number of
Ports
Storage (NFS) 2
(Left):
enp134s0f0
(Right):
enp134s0f1
Cluster 8
Introduction to the NVIDIA DGX-2 System
Port Type Cable Type
(QSFP28 to SFP28
or SFP+)
InfiniBand EDR
100
QSFP28
Ethernet 100GbE
Port Cable Type
Type
QSFP28 1/10/25/40/100 GbE
EDR InfiniBand or 100
GbE
QSFP28
