With EMI Shield Removed
ID
Qty
Description
1
2
NVIDIA NVLink™ plane card
1.2.8
Motherboard Tray Ports and Controls
ID
Qty
Description
1
1
(Optional) High profile PCI card slot (for network storage)
2
2
(Default) QSFP28 network ports (for network storage)
Left side port designation: enp134s0f0
Right side port designation: enp134s0f1
3
1
RJ45 network port (for in-band management)
4
2
USB 3.0 ports
DGX-2 System User Guide
Introduction to the NVIDIA DGX-2 System
10
