ID Qty Description
5 1 IPMI port (for out-of-band management (BMC))
6 1 VGA port
7 1 Serial port (DB-9)
8 1 System ID LED
Blinks blue when ID button is pressed from the front of the unit
as an aid in identifying the unit needing servicing
9 1 BMC reset button
10 1 Power and BMC heartbeat LED
On/Off – BMC is not ready
Blinking – BMC is ready

NETWORK PORTS

The following figure highlights the available network ports and their purpose.
ID Connectivity
1 BMC (remote
management and
monitoring)
Motherboard
2
RJ45
3 ConnectX-5 (LP)
Ethernet mode
DGX-2 System User Guide
Uses
Number of
Ports
Out-of-band 1
management
In-band
1
management,
administration
Storage (NFS) 2
System (Left):
enp134s0f0
communication
Introduction to the NVIDIA DGX-2 System
Port Type Cable Type
100/1000
Ethernet
RJ45
Cat5E/6 Ethernet
100/1000
Ethernet
RJ45
Cat5E/6 Ethernet
100 GbE (QSFP28)
QSFP28
10/25/40 GbE
