Technical MANUAL
19 Inch Color LCD
Resistive - Touch
MODEL NO. 1926A-1AN
Confirmity according to the Council Directive 93/42/EEC concerning
Medical Devices.
Use this product only after carefully reading this manual and
understanding the contents.
Keep this manual close to the display.

Advertisement

Table of Contents
loading

Summary of Contents for GE 1926A-1AN

  • Page 1 Technical MANUAL 19 Inch Color LCD Resistive - Touch MODEL NO. 1926A-1AN Confirmity according to the Council Directive 93/42/EEC concerning Medical Devices. Use this product only after carefully reading this manual and understanding the contents. Keep this manual close to the display.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Revision History • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 2.
  • Page 3: Revision History

    Revision History The revision changes with related comments each time the document is updated. Revision Comment Initial release of this document RMF NO.: DOC1765836...
  • Page 4: Equipment Symbols

    Equipment Symbols Electrical and electronic equipment symbols Alternating current. Atmospheric pressure limitations. Date of manufacture. This symbol indicates the date of manufacture of this device. The first four digits identify the year, the following two digits identify the month, and the last two digits identify the day. European Union Declaration of Conformity.
  • Page 5 Device hardware version. Every device has a unique marking for identification. The UDI marking appears on the device label Catalogue or orderable part number. Recycled materials or may be recycled. Device serial number. Stacking limit by number. Temperature limitations. Underwriters Laboratories product certification mark. This way up.
  • Page 6 This symbol indicates that the waste of electrical and electronic equipment must not be disposed as unsorted municipal waste and must be collected separately. Please contact an authorized representative of the manufacturer for information concerning the decommissioning of your equipment The LCD display complies with the China Compulsory Certification (GB4943.1-2001, GB9254-2008, GB17625 1-2012).
  • Page 7 Follow instructions for use. ON. Power connection to the mains. Standby or power indicator. Power OFF. ATTENTION: Consult accompanying documents. Equipotentiality. Connect device to a potential equalization conductor.
  • Page 8: Safety Precautions

    Safety Precautions ● Make sure to carefully read the User Manual that accompanies the patient display prior to using this display to ensure proper operation of the devices. ● Note that, excluding those cases where a responsibility for legal compensation is recognized, the manufacturer shall bear absolutely no responsibility for damage to this product by a customer or a third party that results in improper use from the ignoring of the contents entered in this Technical Manual.
  • Page 9 Devices which are not connected to the same circuit must be electrically isolated when operated. ● GE is responsible for the effects on safety, readability, and performance of the equipment only if: - Assembly operations, extensions, readjustments, modifications, servicing, or repairs are carried out by authorized service personnel.
  • Page 10 I CLASSIFICATION Class I : No applied parts Protection against harmful ingress of water is IPX1 Not suitable for use in the presence of flammable anesthetics or oxygen. Mode of operation: Continuous. II External Equipment External equipment intended for connection to signal input / output or other connectors, shall comply with IEC 60601-1 for medical electrical equipment.
  • Page 11: Emc Table

    EMC Table EMC Table Guidance and manufacturer’s declaration-electromagnetic immunity for all EQUIPMENT AND SYSTEMS Guidance and manufacturer’s declaration-electromagnetic emissions The LCD display for Healthcare Applications is intended for use in the electromagnetic environment specified below. The customer or the user of the LCD display for Healthcare Applications should assure that it is used in such an environment.
  • Page 12 Guidance and manufacturer’s declaration-electromagnetic immunity for all EQUIPMENT AND SYSTEMS Guidance and manufacturer’s declaration-electromagnetic immunity The LCD display for Healthcare Applications is intended for use in the electromagnetic environment specified below. The customer, or the user of the LCD display for Healthcare Applications, should assure that it is used in such an environment.
  • Page 13 (30% dip in UT) (30% dip in UT) recommended that the LCD for 25 cycles for 25 cycles display for Healthcare <5% UT <5% UT Applications be powered from an (>95% dip in UT) (>95% dip in UT) uninterruptible power supply or a for 250 cycles for 250 cycles battery.
  • Page 14 Guidance and manufacturer’s declaration-electromagnetic immunity for all EQUIPMENT AND SYSTEMS that are not LIFE-SUPPORTING The LCD display for Healthcare Applications is intended for use in the electromagnetic environment specified below. The user of the LCD display for Healthcare Applications should assure that it is used in such an environment.
  • Page 15 * 1: At 80 MHz and 800 MHz, the higher frequency range applies. * 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. 1.Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.
  • Page 16 Recommended separation distances between portable and mobile RF communications equipment and the LCD display for Healthcare Applications for all EQUIPTMENT AND SYSTEMS that are not LIFE-SUPPORTING The LCD display for Healthcare Applications is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the LCD display for Healthcare Applications can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications (equipment) and the LCD display for Healthcare Applications as recommended below...
  • Page 17: Connection Method

    Connection Method Connect the AC power cord provided into the display's power input. Then, connect the plug into an outlet. Note When connecting the AC power cable, do not forget to install the cable supplied in the accessory box. Main Power Supply Switch To power outlet Power cord...
  • Page 18 .Connect the signal cable (for SYSTEM input). Connect the DVI-I connector of the display and the digital output of the system with the provided DVI-D to DVI-D cable. Do not forget to tighten the screws of the cable. The display is shipped with the default input selected to DVI-D.
  • Page 19 Connect USB Cable. Connect the system's USB TYPE A port and the displays USB TYPE B port with the provided USB cable. Downstream ports shall be used for accessories such as a mouse, keyboard, barcode scanner or a remote input device. Such accessories are permitted to be connected directly to the USB downstream port of this display.
  • Page 20 (ceiling) due to an improper attachment through the use of wrong length screws. Refer to GE manuals CARESCAPE monitors' user's manual and supplemental information manual and to the CARESCAPE Modular Monitors Mounting Solutions for more information on approved mounting solutions and hazards associated with improper mounting.
  • Page 21: Adjustment Method

    Adjustment Method 1.0 Names and Function of Each Section Power Switch Button (Power ON/OFF) • Pressing the power button for more than one second, and then releasing, turns on the color LCD display. Pressing the same button again turns the display off. The display shall recall the On/Off status even if the external power source is removed.
  • Page 22: Power Indicator

    • When the OSD is displayed, execution of selected items and display of submenus can be performed. • Control dial functions are as follows: Rotate clockwise or counterclockwise: up-and-down movement / left-and-right movement / increasing and decreasing etc. Press the control dial inward briefly and then release to: execute / select items / save data.
  • Page 23: Osd Adjustments

    2.0 OSD Adjustments This section shows how to make adjustments to the LCD screen that is displaying a valid video input. Operating the control dial on the back of the display enables the user to make settings and adjustments for the selected items. See Drawing on page 19 item number (2) for location of the OSD Control dial.
  • Page 24: How To Operate

    2.2 How to Operate MAIN M E N U Exit Auto Setup Adjustment examples from the main menu below. Brightness e.g.,"Brightness" adjustment Contrast Adjustment 1...from the main menu Display 1.Press the control dial and display the OSD menu (See Fig.1). Clock / Phase Management 2.Rotate the dial to select "Brightness"...
  • Page 25 2.3 OSD Source Select Menu During power up after first configuring your display, the display may show the NO SYNC message ( See figure 1). This may be due to the wrong source input "saved" in the display. The display does not auto-select source inputs. figure 1 To change the display's source input see below.
  • Page 26 2.4 OSD adjustment function The OSD hierarchy and functions are outlined below. OSD adjustment function ● Main menu display • Auto Setup Auto Setup..Automatic screen size/position/freq./phase adjustment (Analog only). • Brightness Brightness..Adjust the brightness of the full screen within the range of 0 to 100. •...
  • Page 27 2.5 Details of Adjustment Items The adjustment functions are described as follows. Exit Close the OSD main menu. Auto setup Automatically adjusts the size, position and contrast of the screen. When first using this color display or inputting new timings, perform this adjustment. Brightness Adjusts brightness of the screen.
  • Page 28 Clock (clock adjustment) Make "Clock" adjustments whenever the "Auto-adjustment" does not adequately center the screen. Rotating the control dial will adjust the position of the video display with respect to the Horizontal Sync signal. Adjustment is within the range of 0 to 100. As the value gets larger, the screen moves to the right, and vice versa.
  • Page 29 2.6 Brightness Only Control Display Window The brightness only control is available whenever the other menus are not on the display. View the brightness scale by rotating the OSD control dial. See the drawing on page 22 item number (2). 2.7 OSD Error Messages The OSD shall automatically display "Error Messages"...
  • Page 30: Compatible Signals

    Compatible Signals 1.0 Timing of Compatible Signals The display may not work properly if the timings are other than those below. Recommended timing Not Supported — Display Mode H-Frequency V-Frequency Pixel Frequency Anaiog input Digital input 31.47kHz 60.00Hz 25.175MHz 37.50kHz 75.00Hz 31.50MHz —...
  • Page 31 2.0 Arrangement of Connector Pins Pin Number Signal Name T.M.D.S Data2- T.M.D.S Data2+ T.M.D.S Data2/4 Shield DDC Clock DDC Data Analog Vertical sync T.M.D.S Data1- T.M.D.S Data1+ T.M.D.S Data1/3 Shield +5V Power Ground Hot Plug Detect T.M.D.S Data0- T.M.D.S Data0+ T.M.D.S Data0/5 Shield T.M.D.S Clock Shield T.M.D.S Clock+...
  • Page 32 3. 4 pin USB-A TYPE Downstream Connector Pin Number Signal Name VBUS...
  • Page 33: Specifications

    Specifications Items Specifications LCD display device 19 inch Color TFT Normally Black Pixel pitch Horizontal 0.294mm x Vertical 0.294mm Display area Horizontal 376.32mm x Vertical 301.06mm Pixel 1280 x 1024 pixels Display gradation 16.7 M colors (True) Conditions Horizontal (Right) Standard viewing CR=10 (Left) angle...
  • Page 34: Cleaning Instruction

    Cleaning Instruction Using a spray applicator, apply any of the approved cleaning agents from the list below and use a soft lint free cloth to clean the screen. ● Cloth dampen with water ● Cloth dampen with mild soap ● Cloth dampen with Ethanol (max. 99.7% by volume) ●...
  • Page 35: Fcc Information

    FCC Information FCC (U.S.Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 36 CE Certi cation This device complies with the requirements of the EEC directive 93/42/EEC with regard to “Medical Device”. 1926A-1AN GE p/n: 2091761-001 DIVA p/n: 3MD163PR010...
  • Page 37 技术手册 19 英寸彩色 LCD 电阻式触摸屏 型号1926A-1AN 符合欧洲理事会指令 93/42/EEC 关于医疗设备的规定。 只有仔细阅读本手册并理解其内容后,方可使用本产品。 本手册应存放于显示器附近。...
  • Page 38 目录 1. 修订记录 2. 设备符号 3. 安全预防措施 4. EMC 表 5. 连接方式 6. 调节方式 7. 兼容信号 8. 规格 9. 清洁说明 10. FCC 信息...
  • Page 39 修订记录 文档每次更新时的修订内容及相关注释。 修订 注释 本文档首次发布 RMF 编号:DOC1765836...
  • Page 40 设备符号 电气和电子设备符号 交流电。 气压限制。 制造日期。此符号指示本产品的制造日期。前四位数字代表年,后两位 数字代表月,最后两位数字代表日。 欧盟符合性声明。 FCC。仅限美国。符合适用的美国政府(联邦通信委员会)射频干扰规 范。 易碎。小心搬运。 表示正面。 湿度限制。 保持干燥。避免淋雨。 仅限欧亚经济联盟国家/地区。欧亚符合性标志。符合关税同盟的适用 技术规范。...
  • Page 41 设备硬件版本。 每一设备具有一个唯一身份标记。UDI 标记印于设备铭牌上。 目录或可订购部件号。 回收材料或可以回收。 设备序列号。 通过数字标明堆放限制。 温度限制。 美国保险商实验室 (UL) 产品认证标志。 此面朝上。...
  • Page 42 此符号表明电气和电子设备废弃物不得作为未分类城市垃圾处置,必须 另外收集。有关弃用本设备的信息,请联系制造商的授权代表。 本 LCD 显示器符合中国强制性认证 (GB4943.1-2001、GB9254-2008、 GB17625 1-2012) 的要求。CCC 认证仅在中国有效。 注:下列符号(仅中国法律要求)代表您可能在设备上看到的。符号 中的数字表示 EFUP 期限的年数,如下文所述。请检查设备上的符号, 以了解其 EFUP 期限。此符号表示产品包含的有害物质超过了中国标准 (2016 年 1 月)规定的限值,即GB/T 26572 电子信息产品中有毒有害 物质的限量要求。符号中的数字为环保使用期限 (EFUP),它表示电子 信息产品中包含的有毒有害物质或元素在正常工作条件下不会泄漏或突 变的期限,在这一期限中使用此类电子信息产品不会造成严重的环境 污染、人身伤害或财产损失。期限的单位是“年”。为了保持所声明的 EFUP,本产品应当按照产品手册中规定的说明和环境条件进行正常操 作,并且严格遵循产品维护程序中的规定进行定期维护。耗材或特定部 件可能有自己的标签,其 EFUP 值可能低于本产品。应遵循产品维护程 序定期更换这些耗材或部件,从而保持所声明的 EFUP 期限。本产品不 得按照未分类城市生活垃圾处置,弃用时必须单独收集并妥善处置。...
  • Page 43 遵循使用说明。 开。电源连接至主电网。 待机或通电指示灯。 关机。 注意:请参考随附文档。 等位性。将设备连接至电位均衡导线。...
  • Page 44 •若本设备已经过改装,必须进行适当的检查和测试后,才能确保持续安全使用设备。 •操作员不得同时触摸外壳和患者。 •请勿连接到多个电源插座。 •为避免触电风险,本设备必须仅连接到具有接地保护的电源。 •如果您的 LCD 显示器使用 AC/DC 适配器:仅可使用本设备附带的适配器。使用其他 AC/ DC 适配器可能会造成故障或导致触电或火灾危险。 •如果您的 LCD 显示器运行不正常,尤其是,如果它发出任何异常声音或气味,请立即拔 下 AC 线缆,并联系制造商或授权服务中心。 •电源。本设备仅可连接到安装妥当且具有接地线的电源插座。如果对接地线导体的完整性 存有疑虑,请将 LCD 显示器从电源上拔下,并将它搭配电池选件(若有)使用。如果安装 中不提供接地线导体,请将 LCD 显示器从电源上拔下。系统中的所有设备必须连接到同一 供电电路。未连接到同一电路的设备在运行时必须在电气上隔离。 •只有满足以下条件时,GE 才对设备的安全性、可靠性和性能的影响负责: -组装操作、扩展、调节、改装、服务或维修由授权维修人员执行。 -相关房间的电气安装符合相应规范的要求。 -设备的使用遵循患者显示器使用说明及本技术手册。 •只有在设备连接至标有“仅医院”或“医院级”的等同插座时方可实现接地可靠性。 •LCD 显示器的位置摆放不可妨碍操作和连接/断开 AC 电源线。 •在连接或断开线缆时,请勿同时触碰患者。 •安装和 OSD 调节应当仅由制造商培训和授权的人员执行。...
  • Page 45 I 分类 普通医疗型医用设备在电击、火灾和机械危害方面必须遵循 UL60601-1 ANDCAN/CSAC22.2NO.601.1-M90、ANSI/AAMIES60601- 1(2005)+A1(2012) 及 CAN/CSA-C22.2 NO.60601-1(2014) 的规定 I 类: 无应用部件 有害液体浸入保护为 IPX1 不适合在易燃麻醉剂或氧气周围使用。 运行模式:持续。 II 外置设备 用于连接至信号输入/输出或其他接口的外置设备应符合 IEC 60601-1 针对医疗电气设备的相 关规定。此外,所有此类组合系统应符合 IEC 60601-1-1 标准中有关医疗电气系统的安全性 要求。根据系统标准的定义,不符合 IEC 60601-1 规定的设备应置于患者环境之外。 III 设计用途 本设备的设计用途是作为医疗患者监控系统的组件,由专业医师用于婴幼儿或成人。本显示 器应归类为“非生命支持”。 IV 工作原理 单一设备输出模拟信号通过 ADC 元件(模拟数字转换)转换变为数字信号,其视频信号透 过视频解码器转换。变成相同的数字信号,这些信号在放大或缩小操作及数字图像处理时...
  • Page 46 EMC 表 EMC 表 使用指南和制造商声明-所有设备及系统 电磁抗扰度 使用指南和制造商声明-电磁辐射 医用型 LCD 显示器旨在用于以下指定的电磁环境中。医用型 LCD 显示器的客户或用户应确 保在此类环境中使用设备。 辐射检测 合规性 电磁环境准则 RF 辐射 Group 1 医用型 LCD 显示器仅在执行内部功能时使用 RF 能量。因 CISPR 11 此,其 RF 辐射非常低,不太可能对附近的电子设备产生 干扰。 RF 辐射 Class A 医用型 LCD 显示器适用于所有设施,但家用设施以及直接 CISPR 11 连接到公共低电压电源网络(为住宅用建筑供电)的设施...
  • Page 47 使用指南和制造商声明-所有设备及系统 电磁抗扰度 使用指南和制造商声明-电磁抗扰度 医用型 LCD 显示器旨在用于以下 指定的电磁环境中。医用型 LCD 显示器的客户或用户 应确保在此类环境中使用设备。 抗扰度检测水平 IEC 60601 符合水平 电磁环境准则 静电放电 (ESD) ± 8 kV 接触 ± 8 kV 接触 地面应为木地板、混凝 IEC 61000-4-2 ± 15 kV 空气 ± 15 kV 空气 土或瓷砖。如果地面覆 盖有合成材料,则相对 湿度不得小于 30%。 电气快速...
  • Page 48 使用指南和制造商声明-所有非生命支持设备 及系统电磁抗扰度 医用型 LCD 显示器旨在用于以下指定的电磁环境中。医用型 LCD 显示器的用户应确保在此 类环境中使用设备。 抗扰度检测 IEC 60601 测试水平 符合级别 电磁环境准则 传导 RF 3 Vrms 3 Vrms 在此类环境中使用时,便携式和 辐射 RF 3 V/m 3 Vrms 移动 RF 通信设备与医用型 LCD IEC 61000-4-3 80 MHz 至 2.5 显示器任何部分(包括电缆)的 距离应确保不小于根据发送器频 率适用的公式计算出的建议间隔 距离。建议间隔距离...
  • Page 49 便携式和移动 RF 通信设备与供所有非生命支持设备及系统使用的医用型 LCD 显示器之间 的建议间隔距离 医用型 LCD 显示器设计用于辐射 RF 干扰受控的电磁环境中。通过维持便携式和移动 RF 通 信设备与医用型 LCD 显示器之间的最小距离(建议如下),医用型 LCD 显示器的客户或用 户可帮助防止电磁干扰,该距离根据通信设备的最大输出功率而定。 发 送 器 的 额 定 最 大 基于发送器频率的间隔距离 输出功率 (W) 150 kHz 到 80 MHz 80 MHz 到 800 MHz 800 MHz 到...
  • Page 50 连接方式 1. 将随附的 AC 电源线连接到显示器的电源输入口。然后,将插头插入电源插座。 注意 在连接 AC 电源线时,请勿忘 记安装配件盒中提供的线缆。 主电源 开关 至电源 插座 电源线 (配件)...
  • Page 51 2. 连接信号线(系统输入)。 通过随附的 DVI-D 至 DVI-D 连接线,将显示器的 DVI-I 接口与系统的数字输出口连接。不 要忘记拧紧线缆的螺丝。显示器在出厂时默认输入选定为 DVI-D。用户也可根据需要选择 DVI-A 选项。如果显示“不同步 (NO SYNC)”消息,这表示输入信号选择错误。请检查视频 输入并更改输入源。如需详细信息,请参见第 21 页(OSD 输入源选择菜单)。 OSD 拨盘 系统的数字输出 系统的模拟输出 使用显示器的 DVI-I 接口进行此连接。不要忘记拧紧线缆的螺丝。如需详细信息,请参见第 21 页(OSD 输入源选择菜单)。...
  • Page 52 3. 连接 USB 线缆。 通过随附的 USB 线缆,将系统的 USB TYPE A 端口与显示器的 USB TYPE B 端口连接。 下游端口用于鼠标、键盘、条形码扫描器或远程输入设备等配件。此类配件允许直接连接至 本显示器的 USB 下游端口。 至 USB 下游端口 (TYPE A) 至 USB 上游端口 (TYPE B) 注意: 在连接 USB 线缆时,请勿忘记安装配件盒中提供的 USB 线缆支架。...
  • Page 53 5. 壁挂(吊顶)VESA 安装显示器。 若要将显示器安装于墙壁(天花板),强烈建议您仅使用 UL 核准壁挂(吊顶)安装套件 (配有承重大于显示器重量的 M4*12 毫米螺丝),并确保其安装牢固且安全。(VESA 安装 为 75 毫米 x 75 毫米和 100 毫米 x 100 毫米) 如果使用非 UL 核准壁挂(吊顶)安装套件,可能会因为使用长度错误的螺丝而导致安装不 当,存在显示器从墙壁(天花板)掉落的安全隐患。请参见 GE 手册(CARESCAPE 显示器用 户手册和补充信息手册)以及 CARESCAPE 模块化显示器安装解决方案,了解关于核准安装 解决方案及安装不当相关危害的更多信息。 注意 :所有设备在出厂时均预装有 75 毫米 x 75 毫米 VESA 板。...
  • Page 54 调节方式 1.0 每一部分的名称和功能 电源开关按钮(开机/关机) •按住电源按钮一秒以上再松开,可打开 LCD 彩色显示器。再次按下同一按钮可关闭显示 器。即使断开外部电源连接后,显示器也可记住开/关状态。 屏幕显示 (OSD) 控件 •在显示器开机后,如果按下 OSD 控制拨盘,屏幕上将出现 OSD 显示窗口。 •OSD 代表屏幕显示。其功能是显示用于配置显示器的信息。显示器显示错误消息(如“不 同步 (NO SYNC)”)时,OSD 显示窗口无法激活。用户必须等待消息消失。错误消息由显示 器自动生成,指示无效的视频输入状况。...
  • Page 55 •显示 OSD 时,可以进行执行所选项目和显示子菜单等操作。 •控制拨盘功能如下: 顺时针或逆时针转动:上下运动/左右运动/增大和减小等。 向内按一下控制拨盘再松开:执行/选择项目或保存数据等。 电源指示灯 •电源正常开启时指示灯亮绿色光。 •关闭电源时指示灯熄灭 AC 主电源开关 AC 主电源开关可中断显示器的 AC 电源输入。连接有 AC 输入时,将开关置于 ON ( | ) 位置 可打开显示器电源。由 AC 输入供电时,将开关置于 OFF ( O ) 位置可关闭显示器电源。...
  • Page 56 2.0 OSD 调节 此部分说明如何在显示有效视频输入时调节 LCD 屏幕。通过操作显示器背面的控制拨盘, 用户可以对选定项目进行设置和调节。如需了解 OSD 控制拨盘的位置,请参见第 17 页上 (2) 号插图。 注意 可调节项目和设置值显示于屏幕 中。OSD 代表屏幕显示。其功能 是显示用于配置显示器的信息。 此 OSD 通常显示在屏幕的中央, 但可以移动其确切位置。不过, 无法更改 OSD 显示的大小。 OSD 显示 2.1 OSD 显示 OSD 菜单中显示有图标、调节项和设置值,如下图所示。下图显示的是主菜单。 调节项图标 可调节项目的图标 光标显示 转动 OSD 控制拨盘可将光标在 项目列表中滚动,并将它显示为 “高亮”状态。 消息窗口...
  • Page 57 2.2 如何操作 下方为主菜单调节示例。 示例:“亮度 (Brightness)”调节 调节 1... 从主菜单 1. 按控制拨盘并显示 OSD 菜单(见图 1)。 2. 转动拨盘以显示“亮度 (Brightness)”,再 按一下拨盘(见图 2)。(此时将显示“亮度 (Brightness)”画面)(见图 3)。 图 1:主菜单 3. 转动拨盘进行亮度调节(见图 4)。可调节 范围为 0 到 100。 4. 按一下拨盘以完成调节(返回到图 1)。 5. 转动拨盘以显示“退出 (Exit)”。按一下控 制拨盘以关闭 OSD 主菜单。 图 2:选择“亮度 (Brightness)” 图...
  • Page 58 2.3 OSD 输入源选择菜单 在第一次配置显示器后开机时,屏幕中可能会 显示“不同步 (NO SYNC)”消息(见图 1)。 其原因可能是显示器中“保存”了错误的输入 源。显示器不会自动选择输入源。要更改显示 器输入源,请见下方说明。 图 1 按一下 OSD 控制拨盘。OSD 将显示输入源选 择菜单。见图 2。 图 2 转动 OSD 控制拨盘来选择所需的输入源。图 3 所示为选择了 DVI-I 数字输入。然后,按一 下 OSD 控制拨盘来保存并执行您的选择。 图 3...
  • Page 59 2.4 OSD 调节功能 下方概述了 OSD 层次结构和功能。 •OSD 调节功能 主菜单显示 •自动设置 (Auto Setup) 自动设置 (Auto Setup)..自动调节屏幕尺寸/位置/频率/相位(仅模拟输入)。 •亮度 (Brightness) 亮度 (Brightness)..调节整个屏幕的亮度,范围为 0 到 100。 •对比度 (Contrast) 对比度 (Contrast)..调节整个屏幕的对比度,范围为 0 到 100。 •显示 (Display) 水平位置 (H.Position)... 调节图像的水平位置(仅模拟输入)。 垂直位置 (V.Position)... 调节图像的垂直位置(仅模拟输入)。 •时钟/相位...
  • Page 60 2.5 调节项详细信息 下面介绍各个调节功能。 退出 (Exit) 关闭 OSD 主菜单。 自动设置 (Auto Setup) 自动调节屏幕的尺寸、位置和对比度。第一次使用此彩色显示器或输入新的时序时,请执行 此调节。 亮度 (Brightness) 调节屏幕的亮度。增大此值可提高屏幕的亮度。 调节范围为 0 到 100。 对比度 (Contrast) 调节屏幕的对比度。增大此值可提高屏幕的对比度。 调节范围为 0 到 100。 显示 (Display) 水平位置 (H.Position) 调节显示图像的水平位置。调节范围为 0 到 100(模拟输入)。 垂直位置 (V.Position) 调节显示图像的垂直位置。调节范围为 0 到 100(模拟输入)。 时钟/相位...
  • Page 61 管理 (Management) OSD 显示 (OSD Display) •OSD 水平位置 (OSD H. Pos)..调节 OSD 的水平位置 •OSD 水平位置 (OSD H. Pos)..调节整个屏幕的 OSD 水平位置,范围为 0 到 100 •OSD 垂直位置 (OSD V. Pos)..调节 OSD 的垂直位置 •OSD 垂直位置 (OSD V. Pos)..调节整个屏幕的 OSD 垂直位置,范围为 0 到 100 语言...
  • Page 62 2.6 仅亮度控制显示窗口 只要显示中没有其他菜单,即可使用仅亮度控制。转动 OSD 控制拨盘即可查看亮度标尺。 请参见第 20 页上 (2) 号插图。 2.7 OSD 错误消息 显示器检测到与视频输入相关的错误时,OSD 将自动显示错误消息。具体消息如下文所述。 不同步 (NO SYNC) 没有视频信号,或者显示器中“保存”了错误的输入源(见第 2.3 节)。 不支持 (No Support) 输入视频信号的垂直刷新频率低于或高于“兼容信号”中指定的值。 超出范围 (Out of Range) 水平刷新频率低于或高于“兼容信号”中指定的值。...
  • Page 63 兼容信号 1.0 兼容信号时序 如果时序与下方所示不同,显示器可能无法正常工作。 ○ 建议时序 — 不支持 显示模式 H-频率 V-频率 像素频率 模拟输入 数字输入 31.47 kHz 60.00 Hz 25.175 MHz ○ ○ 37.50 kHz 75.00 Hz 31.50 MHz ○ — 640 x 480 37.86 kHz 72.00 Hz 31.50 MHz ○ —...
  • Page 64 2.0 接口针脚布局 针脚编号 信号名称 29 针 DVI-I 接口(母口) T.M.D.S Data2- T.M.D.S Data2+ T.M.D.S Data2/4 屏蔽 DDC 时钟 DDC 数据 数字信号接口 模拟垂直同步 T.M.D.S Data1- T.M.D.S Data1+ T.M.D.S Data1/3 屏蔽 +5 V 电源 4 针 USB-B TYPE 上游接口 接地 热插拔检测 T.M.D.S Data0- T.M.D.S Data0+ T.M.D.S Data0/5 屏蔽...
  • Page 65 规格 项目 规格 LCD 显示设备 19 英寸彩色 TFT(普通黑色) 像素间距 水平 0.294 毫米 x 垂直 0.294 毫米 显示区域 水平 376.32 毫米 x 垂直 301.06 毫米 像素 1280 x 1024 像素 显示等级 1670 万色(全彩) 视角 条件 最小 最大 水平(右) CR=10(左) 垂直(上) CR=10(下) 输入信号...
  • Page 66 清洁说明 使用喷雾器和下列任何核准清洁溶液,以及无绒软布清洁屏幕。 •蘸有清水的布块 •蘸有温和皂液的布块 •蘸有酒精(体积浓度最高 99.7%)的布块 •蘸有酒精(体积浓度最高 70%)的布块 •蘸有异丙醇(质量浓度最高 60%)的布块 •蘸有氯胺(体积浓度最高 5%)的布块 •蘸有戊二醛(体积浓度最高 2%)的布块 •蘸有苯酚(体积浓度最高 2%)的布块 •系统暴露面(触控屏幕除外)可以使用蘸有次氯酸钠溶液(体积浓度 5.25%,与 H2O 按 1:10 混合)的布块擦拭 •蘸有酒石酸溶液(75 毫克/100 毫升)的布块...
  • Page 67 FCC 信息 FCC(美国联邦通信委员会) 本设备已根据 FCC 规则第 15 部分进行了测试,符合 B 类数字设备的限制。这些限 制旨在为室内安装提供合理保护,防止有害干扰。本设备会产生、使用并能够辐射 射频能量,如果未遵照说明进行安装和使用,可能会对无线电通信造成有害干扰。 但是,不保证在特定的安装中不会发生干扰。如果本设备确对无线电或电视信号的 接收产生不可接受的干扰(通过关闭再打开本设备即可确定),则建议用户采取以 下一项或多项措施来纠正干扰: •调整接收天线的方向或位置。 •增加设备和接收器之间的距离。 •将本设备与接收器连接到不同电路的插座上。 •咨询经销商或有经验的无线电或电视技术人员以获取帮助。 FCC 警告: 为确保始终符合 FCC 规范,用户必须使用接地电源线,以及设备随附的带有粘结铁 氧体磁心的屏蔽式视频接口线缆。此外,未经授权对本显示器进行的任何变动或改 装都将使用户丧失操作本设备的权利。 FCC 规范符合性责任方 钰纬科技开发股份有限公司 (235) 台湾新北市中和区中山路二段 351 号 9 楼 电话:+886-2-22268631 传真:+886-2-22262423...
