• BOWL LOCATING PLATES

If these plates wear out, the bowl will no longer be
securely attached to the motor base.
This makes it awkward to use since the bowl can
come loose during processing.
There is no risk to the user however, because the
safety system will automatically stop the machine.
It is advisable therefore to change these plates in
order to ensure maximum ease of use.
TECHNICAL
SPECIFICATIONS

• WEIGHT

Net
R 2 10 kg
• DIMENSIONS (in mm)

• WORKING HEIGHT

We recommend that you position the cutter device
on a stable worktop so that the upper edge of the
large feed hopper is at a height of between 1.20 m
and 1.30 m.
16

• NOISE LEVEL

The equivalent continuous sound level when the
cutter device is operating on no-load is less than
70 dB(A).

• ELECTRICAL DATA

single-phase machine
Motor
230 V / 50 Hz
115 V / 60 Hz
220 V / 50 Hz
- Power shown on data plate.
Gross
12 kg
The R 2 is fitted with an mechanical safety system.
As soon as you open the lid, the motor stops.
To restart the machine, simply close the lid and
press the green switch.
In order to avoid splash when processing liquid
preparation, we recommend you to stop the
machine before opening the lid.
The R 2 is fitted with a thermal cut-out which
automatically stops the motor if the machine is left
on for too long or overloaded.
If this happens, allow the machine to cool complete-
ly before restarting.
W A R N I N G
The blades are extremely sharp. Handle with
care.
Speed (Rpm) Intensity (Amp.)
1,500 5.0
1,800 10.0
1,800 5.0

SAFETY

R E M E N B E R
Never try to override the locking and safety
systems.
Never introduce any object into the container
where the food is being processed.
Never push the ingredients down with your
hand.
Do not overload the appliance.
Consult the declaration of compliance on page 2.

STANDARDS
