GV-600B, GV-650B, GV-800B
There are two types of GV-600B / GV-650B / GV-800B Card: PCI and PCI-E. Both types of
the GV-600B / GV-650B / GV-800B Card provide up to 16 video channels and 4 audio
channels. The GV-600B, GV-650B and GV-800B Cards have the same appearances and
similar system requirements so that we introduce the three cards together in this installation
guide. However, you may choose among the three according to your need for recording rate.
Minimum System Requirements
32-bit
OS
64-bit
CPU
RAM
HDD
VGA
DirectX
October 14, 2016
Windows 7 / 8 / 8.1 / 10 / Server 2008
Windows 7 / 8 / 8.1 / 10 / Server 2008 R2 / Server 2012
GV-600B
GV-600B x 2
GV-650B
GV-650B x 2
GV-800B
GV-800B x 2
GV-600B / 650B / 800B
GV-600B x 2 / 650B x 2
/ 800B x 2
GV-600B / 650B / 800B
GV-600B x 2 / 650B x 2 /
800B x 2
GV-600B / 650B / 800B
GV-600B x 2 / 650B x 2
GV-800B x 2
9.0c
Pentium 4, 2.0 GHz
Pentium 4, 2.6 GHz with Hyper Threading
Pentium 4, 2.4 GHz
Pentium 4, 2.8 GHz with Hyper Threading
Pentium 4, 3.0 GHz with Hyper-Threading
Pentium 4, 3.0 GHz Dual Core
2 x 1 GB Dual Channels
2 x 1 GB Dual Channels
80 GB
160 GB
ATI Radeon X600 / NVIDIA 6200
ATI Radeon X1300 PCI-E / NVIDIA GeForce
7300 PCI-E
