GeoVision GV-600B User Manual

GV-600B, GV-650B, GV-800B
The GV-600B / GV-650B / GV-800B Card provide up to 16 video channels and 4 audio
channels. The GV-600B, GV-650B and GV-800B Cards have the same appearances and
similar system requirements so that we introduce the three cards together in this installation
guide. However, you may choose among the three according to your need for recording rate.
Minimum System Requirements
32-bit Windows XP / Windows Vista / Windows 7 / Windows Server 2008
OS
64-bit Windows 7 / Windows Server 2008
GV-600B
GV-600B x 2
GV-650B
CPU
GV-650B x 2
GV-800B
GV-800B x 2
GV-600B / 650B / 800B
RAM
GV-600B x 2 / 650B x 2
/ 800B x 2
GV-600B / 650B / 800B
HDD
GV-600B x 2 / 650B x 2 /
800B x 2
Graphic
AGP or PCI-Express, 800 x 600 (1280 x 1024 recommended), 32-bit color
Card
DirectX 9.0c
February 3, 2012
Pentium 4, 2.0 GHz
Pentium 4, 2.6 GHz with Hyper Threading
Pentium 4, 2.4 GHz
Pentium 4, 2.8 GHz with Hyper Threading
Pentium 4, 3.0 GHz with Hyper Threading
Pentium 4, 3.0 GHz Dual Core
Windows XP 2 x 512 MB Dual Channels
Windows Vista / 7
2 x 1 GB Dual Channels
/ Server 2008
2 x 1 GB Dual Channels
80 GB
160 GB
1
Packing List
1. GV-600B, GV-650B or GV-800B Card x 1
2. 1-16 Cams with 4-Port Audio DVI-Type Cable
x 1 / 1-8 Cams with 4-Port Audio DVI-Type
Cable x 1 / 1-4 Cams with 4-Port Audio DVI-
Type Cable x 1
Note: The 1-16 Cams with 4-Port Audio DVI-Type cable is supplied with GV-600B /
GV-650B / GV-800B card with 16 video inputs, the 1-8 Cams with 4-Port Audio DVI-Type
cable is supplied with GV-600B / GV-650B / GV-800B card with 8 video inputs, while the
1-4 Cams with 4-Port Audio DVI-Type cable is supplied with GV-600B / GV-650B /
GV-800B card with 4 video inputs.
3. Hardware Watchdog Jumper Wire x 1
4. Software DVD x 1
5. Surveillance System Quick Start
Guide x 1
