Whittier Wood 3456AFCAF Assembly Instructions Manual

Stayton cocktail table

Advertisement

Quick Links

Model #
3456AFCAF
Stayton Cocktail Table
AFCAF = Caffè finish
Congratulations!
This fine piece of furniture will make a gorgeous addition to
your home. For the best results, read the Assembly
Instructions before you begin your project.
Service Policy: We will replace any part that is defective,
missing or damaged during assembly. For a replacement
part, directly contact Whittier Wood Products customer
service department by phone, fax, mail or email.
Hours: Our friendly customer service staff can be reached
Monday-Friday 7:00 a.m. to 5:00 p.m. (Pacific Time). You
may leave a message 24 hours a day, seven days a week.
800-653-3336 • Outside the U.S. or Canada: 541-687-0213 • Fax: 541-687-2060
CALL US FIRST! Do not return this item to the store
www.whittierwood.com • P.O. Box 2827 • Eugene, Oregon 97402, U.S.A.
P.O. Box 2827
Eugene, OR 97402 USA
IMPORTANT NOTES:
For normal household use only. Not recommended for
commercial use.
Do not climb, sit or stand on this piece of furniture.
Unload items before you move this unit.
Do not overload the drawer or shelf.
Before you load or move this unit, tighten all screws and
supports.
Before you begin your project, completely read the
Assembly Instructions.
Store this item: 1- in its box; 2- in a dry place; 3- in
temperatures that range from 40°F to 90°F (not on a cold
and possibly damp cement floor).
Periodically inspect your furniture for any loose glue
joints, screws or any other problem that might affect the
stability of your furniture. Tighten or repair as needed.
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
To Order: Provide the finish and furniture model number
(upper portion of this page), the part letter, production
code, quantity needed, reason for replacement and your
full name, address and telephone number.
Parts ship from our Eugene, Oregon factory within one or
two business days from the time we receive your request.
Please allow five to ten business days for delivery.
Production Code:
VN
04/13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3456AFCAF and is the answer not in the manual?

Questions and answers

Summary of Contents for Whittier Wood 3456AFCAF

  • Page 1 For a replacement (upper portion of this page), the part letter, production part, directly contact Whittier Wood Products customer code, quantity needed, reason for replacement and your service department by phone, fax, mail or email.
  • Page 2 5/16" Flat Washer 3/8" x 1" Insert Nut (inserted) 3/8" x 2-1/2" Hex Bolt 4 x 10mm Insert Nut (inserted) Pull (installed) Wood Dowel (inserted) #8 x 20mm Pan Head Screw (inserted) Adjustable Angle Bracket (attached) 3456AFCAF — Page 2 — 04/13...
  • Page 3 Corner Blocks. It is important the sides of the legs exposing the wheel face the drawer opening of the unit. Attach with 5/16" Flat Washers (P) and 3/8" x 2-1/2" Hex Bolts (R). See Figures 2 and 2a. Fig. 2a Fig. 2 3456AFCAF — Page 3 — 04/13...
  • Page 4 Front/Left Back Leg (C) in the remaining two corners making sure the drilled corners of the Legs face toward the Corner Blocks. It is important the side of the leg exposing the wheel face toward the back of the unit. See Figure 4. Fig. 4a Fig. 4 3456AFCAF — Page 4 — 04/13...
  • Page 5 Turn the unit onto its top and using the pocket holes as guides, secure the Shelf Assembly (D) to the Legs (B and C) with four #8 x 1-1/4" Pan Head Screws (M). See Figures 6 and 6a. Fig. 6a Fig. 6 3456AFCAF — Page 5 — 04/13...
  • Page 6 3456AFCAF Stayton Cocktail Table Assembly Instructions Turn the table upright and insert the Drawer. See Figure 7. Fig. 7 The wheels allow the table to easily move away from or toward your seating. Fig. 8 Fig. 8a 3456AFCAF — Page 6 — 04/13...
