ZURN ZEMS6000AV Installation, Operation, Maintenance And Parts Manual
Aquasense zems g2 series, automatic systems sensor-operated flushometer, sensor-operated exposed systems, sensor-operated concealed systems
Hide thumbs
Also See for ZEMS6000AV:
Advertisement
Quick Links
Sensor-Operated Exposed Systems
ZEMS6000AV
ZEMS6200AV
ZEMS6000AV-2
ZEMS6200AV-2
ZEMS6000AV-3
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov
AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov
LIMITED WARRANTY
All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of five years from the date
of purchase. Decorative finishes warranted for one year. We will replace at no costs goods that prove defective provided we are notified in
writing of such defect and the goods are returned to us prepaid at Sanford, NC, with evidence that they have been properly maintained and
used in accordance with instructions. We shall not be responsible for any labor charges or any loss, injury or damages whatsoever, includ-
ing incidental or consequential damages. The sole and exclusive remedy shall be limited to the replacement of the defective goods. Before
installation and use, the purchaser shall determine the suitability of the product for his intended use and the purchaser assumes all risk
and liability whatever in connection therewith. Where permitted by law, the implied warranty of merchantability is expressly excluded. If the
products sold hereunder are "consumer products," the implied warranty of merchantability is limited to a period of three years and shall be
limited solely to the replacement of the defective goods. All weights stated in our catalogs and lists are approximate and are not guaranteed.
ZEMS6200AV-3
ZEMS6001AV
ZEMS6201AV
ZEMS6003AV
ZEMS6203AV
AquaSense
ZEMS G2 Series
Automatic Systems Sensor-Operated
Flushometer
Installation, Operation, Maintenance
and Parts Manual
Patented and Patents Pending
Sensor-Operated Concealed Systems
ZEMS6140AV
ZEMS6240AV
ZEMS6152AV
ZEMS6252AV
ZEMS6153AV
ZEMS6253AV
®
ZEMS6190AV
ZEMS6290AV
ZEMS6195AV
ZEMS6295AV
ZEMS6197AV
ZEMS6297AV
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ZURN ZEMS6000AV
Summary of Contents for ZURN ZEMS6000AV
- Page 1 AquaSense ® ZEMS G2 Series Automatic Systems Sensor-Operated Flushometer Installation, Operation, Maintenance and Parts Manual Patented and Patents Pending Sensor-Operated Exposed Systems Sensor-Operated Concealed Systems ZEMS6000AV ZEMS6200AV-3 ZEMS6140AV ZEMS6190AV ZEMS6200AV ZEMS6001AV ZEMS6240AV ZEMS6290AV ZEMS6000AV-2 ZEMS6201AV ZEMS6152AV ZEMS6195AV ZEMS6200AV-2 ZEMS6003AV ZEMS6252AV...
- Page 2 Valve Rough-In Models Models ZEMS6000-2, ZEMS6000-3 ZEMS6000 and ZEMS6200 ZEMS6200-2, ZEMS6200-3 FINISHED WALL [108] MAX. [121] [121] SENSOR BOX 1" I.P.S. 1" I.P.S. [57] MIN. SUPPLY SUPPLY MOTOR [108] MAX. ZEMS6000-2 ACTUATOR 24[610] [57] MIN. SENSOR BOX ZEMS6000-3 27[686] [533] ZEMS6000-2 MOTOR 15[381]...
-
Page 3: Prior To Installation
FROM EACH OTHER OR IN CLOSE PROXIMITY TO HIGHLY • Closet fixture. REFLECTIVE SURFACES. • Zurn carrier system, Z1200 series or equal. • CONTROL STOP SHOULD NEVER BE OPENED TO ALLOW FLOW GREATER THAN FIXTURE IS CAPABLE OF EVACUATING. - Page 4 Electrical AC/DC Power Supply Install hardwired power supply (P6000-HW6) or receptacle for the Zurn Power Converter (P6900-ACA-BA) in a convenient location. An optional mini junction box (P6000-MJ) is recommended to distribute power to each sensor location. NOTE: One Zurn P6000-HW6 can operate up to eight automatic sensor equipped flushometers, and the optional P6000-ACA-BA Power Converter can handle up to six flushometers and is supplied with a six-foot cord.
-
Page 5: Sensor Installation
STEP 2 – Mount Automatic Sensor (Figure 3) Install the Zurn Automatic Sensor into the lower half of the 2-gang electrical box using two (2) screws provided. Connect the 2-wire power cable and 3-wire actuator cable to sensor. Connectors are keyed to insure correct polarity. Ensure that the sensor is mounted in the orientation shown (with lens angled downward, see Figure 4). - Page 6 Mechanical The AquaVantage design is optimized to operate between 25 and 80 psi (172 to 552 kPa) of water pressure (running). The minimum ® pressure required for the valve to work properly is determined by the fixture selected. Please consult fixture manufacurer for water pressure requirements.
- Page 7 Install Vacuum Breaker Flush Connection Models ZEMS6000, ZEMS6000-2, ZEMS6000-3, ZEMS6001, Models ZEMS6140, ZEMS6152, ZEMS6153, ZEMS6190, ZEMS6003, ZEMS6200, ZEMS6200-2, ZEMS6200-3, ZEMS6201, ZEMS6195, ZEMS6197, ZEMS6240, ZEMS6252, ZEMS6253, and ZEMS6203 ZEMS6290, ZEMS6295 and ZEMS6297 (Figure 9) Slide the tube nut (H), spud nut (G), slip gasket, rubber gasket and NOTE: When cutting scored pipe, leave a minimum of 1-1/4”...
- Page 8 1. The plumbing fixture is cleansed after each flush without splashing water out from the lip. 2. A quiet flushing cycle is achieved. After adjustment: Replace the Zurn stop cap screw cover. Care and Cleaning Instrustructions Do not use abrasive or chemical cleaners to clean Flushometers, sensor, and actuators as they may degrade the sensor lens, dull the luster, and attack the chrome or special decorative finishes.
- Page 9 2) Power supply output is out of 2) DC voltage must be between 7.4-9 volts. Check for randomly with no user tolerance. power fault or malfunction in a unit or replace with a Zurn present. power converter. 3) Sensor is viewing stall door.
- Page 10 ZEMS G2 Valves Parts List Optional ZEMS6140 ZEMS6152 ZEMS6153 ZEMS6240 ZEMS6252 ZEMS6253 ZEMS6000 ZEMS6200 ZEMS6000-1 ZEMS6200-1 ZEMS6000-2 ZEMS6200-2 ZEMS6000-3 ZEMS6200-3 ZEMS6001 ZEMS6201 ZEMS6003 ZEMS6203 I n s t a l l w i t h flange against spud. ZEMS6190 ZEMS6195 ZEMS6197 ZEMS6290 ZEMS6295...
- Page 11 ZEMS G2 Valve Parts List (Continues) P6000-YBYC Closet Cast Wall Escutcheon & Solder Kit 12A. P6000-A-AA-CP Chrome Plated 1-1/2” X 8 1/2” Vacuum P6003-YBYC Urinal Cast Wall Escutcheon & Solder Kit Breaker Assembly P6000-C-SD-CP Chrome Plated Closet Stop Assembly P6000-2-A-AA-CP Chrome Plated 1-1/2”...
- Page 12 42. P6000-D42 Stop Seat ZURN INDUSTRIES, LLC 5900 Elwin Buchanan Drive, Sanford, NC U.S.A. 27330, Ph. 1-800-997-3876, Fax 919-775-3541 In Canada: ZURN INDUSTRIES LIMITED 7900 Goreway Drive, Unit 10, Brampton, Ontario L6T 5W6, Ph. 905-405-8272, Fax 905-405-1292 Rev. B Date: 7/19/2018 C.N.
