Models:
ZGEN6203EV-ULF
ZGEN6203EV-QRT
ZGEN6203EV-EWS
ZGEN6203EV-WS1
ZGEN6200EV
ZGEN6200EV-WS1
HydroGenerator
Sensor-Operated Flush Valve
All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of five years from the
date of purchase. Decorative finishes warranted for one year. We will replace at no costs goods that prove defective provided we are
notified in writing of such defect and the goods are returned to us prepaid at Sanford, NC, with evidence that they have been properly
maintained and used in accordance with instructions. We shall not be responsible for any labor charges or any loss, injury or damages
whatsoever, including incidental or consequential damages. The sole and exclusive remedy shall be limited to the replacement of the
defective goods. Before installation and use, the purchaser shall determine the suitability of the product for his intended use and the
purchaser assumes all risk and liability whatever in connection therewith. Where permitted by law, the implied warranty of merchantability
is expressly excluded. If the products sold hereunder are "consumer products," the implied warranty of merchantability is limited to a
period of three years and shall be limited solely to the replacement of the defective goods. All weights stated in our catalogs and lists are
approximate and are not guaranteed.
Customer service Phone Number: 1-800-997-3876
HydroVantage
ZGEN Series
Automatic Sensor-Operated,
HydroGenerator Flushometer
Installation, Operation, Maintenance, and
Parts Manual
Patented and Patents Pending
0.125 gpf
0.25 gpf
0.5 gpf
1.0 gpf
1.28 gpf
1.6 gpf
LIMITED WARRANTY
TM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ZURN ZGEN6203EV-ULF
Summary of Contents for ZURN ZGEN6203EV-ULF
- Page 1 HydroVantage ZGEN Series Automatic Sensor-Operated, HydroGenerator Flushometer Installation, Operation, Maintenance, and Parts Manual Patented and Patents Pending Models: ZGEN6203EV-ULF 0.125 gpf ZGEN6203EV-QRT 0.25 gpf ZGEN6203EV-EWS 0.5 gpf ZGEN6203EV-WS1 1.0 gpf ZGEN6200EV 1.28 gpf ZGEN6200EV-WS1 1.6 gpf HydroGenerator Sensor-Operated Flush Valve...
-
Page 2: Prior To Installation
IMPORTANT: PRIOR TO INSTALLATION • All Plumbing is to be installed in accordance with applicable Prior to installing the HydroVantage flushometer valve, codes and regulations. install the items listed below: • Water supply lines must be sized to provide an adequate •... - Page 3 4.) Insert the flush valve tailpiece (B) into the stop valve (A) and 5.) Determine the length of vacuum breaker tube (F) required hand tighten the lock nut (D) to the stop valve. Plumb the to join the flush valve and fixture spud. Cut the vacuum entire unit.
-
Page 4: Automatic Lighting
Important: Step 8 Valve Activation should only be conducted after all partitions, paper dispensers, hand rails and other accessories are in place. IMPORTANT: READ THOROUGHLY BEFORE REMOVING STICKER. 8) Valve is ready for activation and calibration. 8a) OPEN CONTROL STOP - If the water begins to flow through the valve when the control stop is opened it is likely that the solenoid opened during shipment. - Page 5 The tailpiece length for the HydroVantage Valve to fit a given rough in dimension differs from other Zurn products. The chart below sho ws the various tailpiece lengths available and the corresp onding rough in dimensions. Ro ugh In...
- Page 6 Service/Disassembly Notes: To change a valve from a Right Hand to a Left Hand installation: 1. Remove 2 security screws from either side of valve cap with provided security Allen wrench. 2. Gently pull up on the cap to separate the valve cap from the rest of the valve body.
- Page 7 Phone: 1-800-997-3876 Fax: 919-775-3541 World Wide Web: www.zurn.com In Canada: ZURN INDUSTRIES LIMITED 3544 Nashua Drive Mississauga, Ontario L4V1L2 Phone: 905-405-8272 Fax: 905-405-1292 FV520 Rev.
- Page 8 WARNING! Replacement parts must be matched to the original flow volume of the valve. The flow volume of the valve is designated on the label located on the underside of the tailpiece (connection to control stop). Mismatching of components will cause SEVERE PERMANENT DAMAGE to the valve and will void the warranty Hydro Generator Replacement Kit (1.6 and 1.28 GPF) Items 17-21 &...
- Page 9 Phone: 1-800-997-3876 Fax: 919-775-3541 World Wide Web: www.zurn.com In Canada: ZURN INDUSTRIES LIMITED 3544 Nashua Drive Mississauga, Ontario L4V1L2 Phone: 905-405-8272 Fax: 905-405-1292 FV520 Rev.
-
Page 10: Troubleshooting Guide
Sensor assembly or electronics Perform sensor verification If there is no LED activity malfunction process from Page 5 - Check connection between sensor assembly and main circuit board - Call Zurn Customer Revice for further troubleshooting FV520 Rev. C 6/27/11 Page 10... - Page 11 Valve flushes on its own Trap seal/courtesy flush occurs This feature is to help keep valve This feature can be turned off 24 hours after last activation charged and for sanitary purposes with the Field Adjustment Software Incorrect door position during Valve flushes without an occupant Adjust sensor range or calibration...
- Page 12 Phone: 1-800-997-3876 Fax: 919-775-3541 World Wide Web: www.zurn.com In Canada: ZURN INDUSTRIES LIMITED 3544 Nashua Drive Mississauga, Ontario L4V1L2 Phone: 905-405-8272 Fax: 905-405-1292 FV520 Rev.
