ZURN AquaSense AV ZEMS Series Installation, Operation, Maintenance And Parts Manual
Automatic systems sensor-operated aquavantage flushometer
Hide thumbs
Also See for AquaSense AV ZEMS Series:
Advertisement
Quick Links
Sensor-Operated Exposed Systems
ZEMS6000AV
ZEMS6000AV-2
ZEMS6000AV-3
ZEMS6001AV
ZEMS6003AV
LIMITED WARRANTY
All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of five years from the date of
purchase. Decorative finishes warranted for one year. We will replace at no costs goods that prove defective provided we are notified in writing
of such defect and the goods are returned to us prepaid at Sanford, NC, with evidence that they have been properly maintained and used in
accordance with instructions. We shall not be responsible for any labor charges or any loss, injury or damages whatsoever, including incidental
or consequential damages. The sole and exclusive remedy shall be limited to the replacement of the defective goods. Before installation and
use, the purchaser shall determine the suitability of the product for his intended use and the purchaser assumes all risk and liability whatever
in connection therewith. Where permitted by law, the implied warranty of merchantability is expressly excluded. If the products sold hereunder
are "consumer products," the implied warranty of merchantability is limited to a period of three years and shall be limited solely to the
replacement of the defective goods. All weights stated in our catalogs and lists are approximate and are not guaranteed.
AquaSense AV
ZEMS Series
Automatic Systems Sensor-Operated
AquaVantage Flushometer
Installation, Operation, Maintenance
and Parts Manual
Patented and Patents Pending
Sensor-Operated Concealed Systems
ZEMS6140AV
ZEMS6142AV
ZEMS6152AV
ZEMS6190AV
ZEMS6195AV
ZEMS6197AV
TM
Advertisement
Related Manuals for ZURN AquaSense AV ZEMS Series
Summary of Contents for ZURN AquaSense AV ZEMS Series
- Page 1 AquaSense AV ZEMS Series Automatic Systems Sensor-Operated AquaVantage Flushometer Installation, Operation, Maintenance and Parts Manual Patented and Patents Pending Sensor-Operated Concealed Systems Sensor-Operated Exposed Systems ZEMS6140AV ZEMS6000AV ZEMS6142AV ZEMS6000AV-2 ZEMS6152AV ZEMS6000AV-3 ZEMS6190AV ZEMS6001AV ZEMS6195AV ZEMS6003AV ZEMS6197AV LIMITED WARRANTY All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of five years from the date of purchase.
- Page 2 Valve Rough-In Model ZEMS6000 Models ZEMS6000-2 and ZEMS6000-3 FINISHED WALL [121] SENSOR BOX 1" I.P.S. SUPPLY [108] MAX. [57] MIN. [533] MOTOR ACTUATOR [292] TOP OF FIXTURE Model ZEMS6140 Model ZEMS6142 [273] MAX. [95] MIN. AS SPECIFIED [121] 21[533] [368] Model ZEMS6152 Models ZEMS6001 and ZEMS6003 FV38 Rev.
-
Page 3: Prior To Installation
• Electrical wiring to the power converter outlet (120 VAC, 35 watts service required for each power converter used). • Closet fixture. • Zurn carrier system, Z1200 series or equal. IMPORTANT: • All electrical wiring is to be installed in accordance with National/Local codes and regulations. - Page 4 AC/DC Power Supply Install hardwired power supply or receptacle for the Zurn Power Converter in a convenient location. An optional mini junction box (P6000-MJ) is recommended to distribute power to each sensor location. It is also recommended that brown wire be used for the DC positive (+) of the supply and blue wire be used for the DC negative (-) of the supply.
-
Page 5: Sensor Installation
STEP 2 – Mount Automatic Sensor (Figure 3) Install the Zurn Automatic Sensor into the 2-gang electrical box using two (2) long screws provided. Ensure that wires from sensor case point up for closet installs and point to the right for urinal installs. The rubber push caps will be on the left side of the sensor for closet and at the top for urinal (See Figures 4 and 4A). - Page 6 Mechanical The AquaVantage ® design is optimized to operate between 25 and 80 psi (172 to 552 kPa) of water pressure (running). The minimum pressure required for the valve to work properly is determined by the fixture selected. Please consult fixture manufacurer for water pressure requirements.
- Page 7 Install Vacuum Breaker Flush Connection Models ZEMS6140, ZEMS6142, ZEMS6152, ZEMS6190, Models ZEMS6000, ZEMS6000-2, ZEMS6000-3, ZEMS6001, ZEMS6195 and ZEMS6197 (Figure 9) and ZEMS6003 NOTE: When cutting scored pipe, leave a minimum of 1-1/4" Slide the tube nut (H), spud nut (G), slip gasket, rubber gasket of scoring to ensure engagement with compression coupling.
-
Page 8: Care And Cleaning Instructions
Do not exceed this or sensor will be damaged. Zurn Automatic Sensors are preset at the factory and provide Stand in front of the Zurn Automatic Sensor at the desired the user with selectable options as follows: distance;... -
Page 9: Troubleshooting
Phone: 1-800-997-3876 ♦ ♦ ♦ ♦ ♦ Fax: 919-775-3541 ♦ ♦ ♦ ♦ ♦ World Wide Web: www.zurn.com In Canada: ZURN INDUSTRIES LIMITED ♦ ♦ ♦ ♦ ♦ 3544 Nashua Drive ♦ ♦ ♦ ♦ ♦ Mississauga, Ontario L4V1L2 ♦ ♦ ♦ ♦ ♦ Phone: 905-405-8272 Fax: 905-405-1292 FV38 Rev. - Page 10 ZEMS6000AV AquaVantage Valve ZEMS6142 ZEMS6152 ZEMS6140 Install with ZEMS6000 flange against ZEMS6000-1 spud. ZEMS6000-2 ZEMS6000-3 ZEMS6001 ZEMS6003 ZEMS6197 ZEMS6195 ZEMS6190 16A-C FV38 Rev. D 2/27/12 Page 10...
- Page 11 Breaker Assembly P6000-YBYC Cast Wall Escutcheon & Solder Kit 15C. P6003-A-AA-CP Chrome Plated 3/4” X 8 1/2” Vacuum P6000-D-SD Stop Assembly Breaker Assembly P6000-D-WH Stop Assembly for Wheel Handle 15D. P6000-1-A-AA-RB Rough Brass 1-1/2” X 12 1/2” Vacuum P6000-VC Vandal-Resistant Control Stop Cover Breaker Assembly P6000-YBA Sweat Solder Adapter...
- Page 12 Phone: 1-800-997-3876 ♦ ♦ ♦ ♦ ♦ Fax: 919-775-3541 ♦ ♦ ♦ ♦ ♦ World Wide Web: www.zurn.com In Canada: ZURN INDUSTRIES LIMITED ♦ ♦ ♦ ♦ ♦ 3544 Nashua Drive ♦ ♦ ♦ ♦ ♦ Mississauga, Ontario L4V1L2 ♦ ♦ ♦ ♦ ♦ Phone: 905-405-8272 Fax: 905-405-1292 FV38 Rev.
