Summary of Contents for Mobeye CM-Guard TwinLog CML2055
- Page 1 PORTAL USER MANUAL Mobeye CM-Guard TwinLog CML2055 SW version 4.n...
- Page 2 • Do not let it fall from height. • Do not use in an environment where any inflammable gases, vapors or dust are present or could be present. • Repair of the device may only be carried out by people, trained for Mobeye ® repair.
-
Page 3: Table Of Contents
CONTENT 1. General description 2. Getting started Sign up in the Mobeye Internet Portal Register the Mobeye SIM card Insert the Mobeye SIM card Connect a sensor or device to the input Insert the batteries Connect external power supply (option) - Page 4 5.18 Log interval 5.19 Transfer interval 5.20 System reset 6. Status feedback...
-
Page 5: General Description
1. GENERAL DESCRIPTION The Mobeye CML2055 is a GSM module used to monitor the inputs and send alerts in the event of an alarm situation. The unit can run battery-powered. When powered externally, the power supply will be monitored too. -
Page 6: Getting Started
2. GETTING STARTED To get started with the Mobeye CML2055, at least the following steps need to be taken in the following order: 1. Sign up in the Mobeye Internet Portal 2. Activate the SIM card 3. Insert the Mobeye SIM card 4. -
Page 7: Insert The Mobeye Sim Card
2.3 INSERT THE MOBEYE SIM CARD Open the enclosure by removing the 4 screws and insert the Mobeye SIM card into the module. Push the black cover slightly outward to open the holder and close it afterwards. Make sure the SIM card is inserted before the batteries. -
Page 8: Insert The Batteries
If one of the set values is reached, the Mobeye CML2055 sends a message via Mobeye Internet Portal and calls the alarm telephone numbers. The alarm message contains the input number and measured value. The inputs can also be set as Normally Closed or Normally Open, for sensors with floating contacts. -
Page 9: Enter The Program Mode
LED starts flashing 1 sec. on/1 sec. off (or stays on continuously in case the first telephone number has been configured). The Mobeye CML2055 returns to the program mode by pressing the on/off button for 5 seconds, until the LED starts flashing red/green. Once it has GSM connection it will be flashing again (or stays on continuously). -
Page 10: Configuration And Synchronisation
(max. and min.) temperature limits. In this way you prepare the settings, to be picked up by the device: since the Mobeye device is leading in the communication between the portal and the device, the data synchronisation is done after: 1) any message to the portal (e.g. -
Page 11: Switching On/Off
Please see 2.9 for more information about the synchronisation. 2.11 SWITCHING ON/OFF After the previous steps, the Mobeye CML2055 is ready for use and switched on automatically. It can be switched on and off by the user-defined time schemes or the... -
Page 12: Confirmation Of The Alarm Message
When the system is triggered it will send alarm notifications. First a message is sent to the Mobeye Internet Portal, which will be forwarded to the alarm contacts. Next the device will directly call the alarm telephone numbers. When you pick up the phone, you will hear beeps. -
Page 13: Use Of The Output
3. USE OF THE OUTPUT 3.1 CONNECT A DEVICE TO THE OUTPUT The Mobeye CML2055 has an open collector output, which switches after receiving a correct SMS. The output can switch permanently, or just switch for a pulse time after which the output automatically switches back (see 5.13). -
Page 14: Possible Settings
5.2 ALARM PHONE NUMBERS The Mobeye CML2055 is able to directly call to up to 5 phone numbers. These may be different numbers than the (unlimited number of) contacts who will receive SMS text messages and/or e-mails. -
Page 15: Call On/Off
Even if the alarm telephone numbers are set in the options, the calling process can be suppressed. By turning off the CALL, the unit will only send the notification via the Mobeye Internet Portal. The default value is set to ON. 5.6 INPUT TYPE The input type defines the character of the inputs IN1 and IN2. -
Page 16: Alarm Repeat Time
4 hours. 5.11 POWER FAILURE DELAY TIME If the Mobeye CML2055 is powered externally and the power fails it can notify the contact person(s). The power failure delay time defines the time between the initial power failure and the alarm notification. -
Page 17: Automatic Arming / Disarming
5.14 AUTOMATIC ARMING / DISARMING The Mobeye CML2055 only works if the unit is armed, which is done via the on/off button. It is possible to automatically arm and disarm the unit, based on an arming and/or disarming time scheme. Two schemes can be entered, which can be assigned to the days in the week (e.g. -
Page 18: Test Message
Internet Portal, to ensure the proper functioning of the unit. The test message will also be sent if the unit is disarmed. The Mobeye Internet Portal expects the test message and checks the timely receipt. The monitoring of the test messages follow the ‘management by exception’... -
Page 19: System Reset
The security code is back to factory settings as well. 2. To delete the Mobeye CML2055 from the Mobeye Internet Portal Delete the device from the Mobeye Internet Portal. The SIM card could be then reused for another Mobeye device, or the same device can be connected again. - Page 20 6. STATUS FEEDBACK The outside LED gives information of the status. LED pattern Status Required action Blinking green, 1 second Module not configured Configure at least one on / 1 second off telephone number. 1 green flash every 3 Module is switched on, No action required.
- Page 21 Publisher. Reprinting, even in summary, is prohibited. This user manual meets the technical requirements at the moment of printing. Changes in technology and equipment are reserved. © Copyright 2018 by Mobeye, version CML2055PORTALEN180401...
