- Page 1 Installation manual Mobeye MS100EK Measure, Control and Alarm module SW version 7.n...
-
Page 3: Table Of Contents
Table of Content Introduction To get ready in seven steps Place the SIM Card Connect a sensor Insert the batteries Fout! Bladwijzer niet gedefinieerd. Connect the power supply Program the phone numbers Check the settings Switching on Operation Switching on and off Alarm message confirmation Controlling the outputs Sensors and devices... - Page 5 • Do not let it fall from height. • Do not use in an environment where any inflammable gases, vapours or dust are present or could be present. • Repair of the device may only be carried out by people, trained for Mobeye ® repair.
-
Page 6: Introduction
The Mobeye MS100EK has following features: • In case one of the inputs is activated by a sensor, the Mobeye MS100EK sends an alarm SMS text message and calls the phone numbers as programmed. The SMS message contains the text ‘Mobeye alarm 1’ or ‘Mobeye alarm 2’. -
Page 7: To Get Ready In Seven Steps
5.11). 2.3 CONNECT THE POWER SUPPLY The Mobeye MS100EK is designed to run on an external power supply (9-32VDC). The module will always be in connection with the GSM network. This gives following features: possibility to receive power failure messages (using a back-up battery) and the possibility to perform remote actions, such as arm/disarm, switch the outputs, ask status reports and to program it via SMS- commands. -
Page 8: Program The Phone Numbers
• Press “OK” • Enter the phone number (e.g. 0712345678 or 0044712345678) • Press “OK” The light turns green and a confirmation melody is played. The Mobeye MS100EK is ready to use. 2.6 CHECK THE SETTINGS The settings can be sent to the programmed telephone number as SMS text message. In this way you also check the correct working of the SIM card. -
Page 9: Operation
• Press “OK” The light turns red shortly and an indication tone is started for a few seconds. If the code is entered incorrectly 3 times, the indicator turns red and the Mobeye MS100EK will be blocked for 10 minutes. -
Page 10: Sensors And Devices
3. SENSORS AND DEVICES Several external sensors can be connected to the two inputs. The Mobeye MS100EK can also switch external devices connected to it via the outputs after receiving an SMS command. The Mobeye MS100EK has a 9-32V power input for connection to an external power source. -
Page 11: Configuration Method
4. CONFIGURATION METHOD The Mobeye MS100EK settings can be changed via the keypad or via SMS commands. First the method of programming is discussed, in next chapter the settings are described. 4.1 CONFIGURATION VIA KEYPAD To configure the settings via the keypad, follow these instructions: •... - Page 12 To set the SMS to OFF (just call): Example: 1111 CALLALARM:OFF Or: both commands in one message: Example: 1111 TEL2:+4934578692#CALLALARM:OFF...
-
Page 13: Configuration Possibilities
5.3 TELEPHONE NUMBERS Up to five telephone numbers can be programmed in to the Mobeye MS100EK. In the event of an alarm the Mobeye MS100EK first sends an SMS text message to all numbers, next they are called. -
Page 14: Automatic Time-Based Arm/Disarm
It is possible to add a standard identification text (NAME) to all messages sent out by the Mobeye MS100EK. The alarm messages are a combination of the name and the alarm text. A user defined identification has a length of maximum 20 characters. The default identification text is ‘Mobeye’. -
Page 15: Authorisations And Remote Control
5.16 UNAUTHORISED SWITCHING OF OUTPUTS Although the Mobeye MS100EK is designed to only switch the outputs by an incoming SMS (or call, see chapter 6) from an authorized phone, there is also an option to let them be switched by any incoming call/SMS, without being authorised. -
Page 16: Action Rules
6. ACTION RULES The alarm message and behaviour of the outputs of the Mobeye MS100EK are programmed by action-reaction patterns. These so-called Action Rules are pre-programmed, according to the needs of many applications. However, it is possible to change these action rules (for advanced users only!). -
Page 17: Programming Action Rules
1111 IN1:O1ON • Do not forget the space between CODE and the TRIGGER. • The Mobeye MS100EK will play a short melody to indicate a successful configuration. In case of a wrong command, a long beep will sound. 6.4 TIME-BASED ACTION RULES It is possible to let the action be daily performed at a certain time. -
Page 18: Delete Action Rules
6.6 DELETE ACTION RULES An action rule can be deleted by an SMS by the command below incl. index number. The index number is the sequence number of the action rule as displayed in the ARLREPORT. Example: CODE DELARL:indexnumber 1111 DELARL:1 Remark: a rule will keep its index number, even if a rule with a previous number is deleted. -
Page 19: Complete List Of Settings
7. COMPLETE LIST OF SETTINGS Setting Menu/ Options Factory command default Keypad Installation code 4 digits 1111 INSTCODE: 0, 1, 2, 3, … or 30 Keypad Interval test message (days) TEST: Keypad 0 (off), 1 (on) SMS on/off 1 (ON) SMSALARM: ON, OFF Keypad... - Page 20 201…250 Delete authorised Keypad number DELA:1..DELA:50 Keypad Authorised remote ON, OFF control AUTH: Keypad Identification text NAME: 20 characters Mobeye Keypad Alarm text power Power failure TEXT2: 20 characters failure Keypad Alarm text power Power restored TEXT3: 20 characters restored...
-
Page 21: Reports And Lists
Warning In the event of a weak signal, the Mobeye MS100EK can still be used, but there is a risk that messages cannot be sent or will be received with a delay. In case of no signal, it is advised to try... -
Page 22: Issue Solving And Technical Data
Re-program the telephone number at position ‘01’ the settings. correct. For other questions, please refer to the site www.mobeye.eu Technical data • GSM: Quad Band EGSM 850/900/1800/1900 MHz compatible to the ETSI GSM Phase 2+ standard • Temperature range: -10°C until +55°C •... - Page 23 Declaration of Conformity Herewith we, Mobeye, declare that the product Mobeye XM2 telemetry module And the derived products MS100, MS200, MS300, Call-Key are in compliance with the essential requirements of the following European standards / EU Directives: Directive 73/23/EEC (low voltage directive)
