Uplift Desk UDA110 Instructions

Package contents

UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com
Main unit
®
UPLIFT Adapt X™ Instructions
UDA110
Tray brackets
(qty 2)
Step 1
Unpack the box and verify the contents against the parts
above. Clear off the surface you intend to use the Adapt
X™ on, and ensure there is at least 29''w by 24''d space for
it. Two people should lift the main unit and place it on the
intended surface.
Step 2
Raise the Adapt X™ main unit to a higher position so that you
can easily access the space underneath, to later attach the
keyboard tray. Grip the handles on either side of the upper
worksurface, squeeze, and lift.
Step 3
Attach a hinge cover to each connecting arm as pictured.
Step 4
Using a Phillips head screwdriver, connect the tray
brackets to the keyboard tray using the included screws.
Note: Tighten the screws only until the head is flush with the
!
tray brackets. Going any tighter may strip the screw and damage
the keyboard tray.
Keyboard tray
Hinge cover Screws
(qty 2) (qty 8)
Cable mounts
(qty 4)
