UPLIFT 3-Leg Desk Instructions for
Laminate, Bamboo, & Rubberwood Desktops
Any user or installer of desk base must study this manual carefully. If this desk is sold,
please provide the manual to the buyer, installers, or support personnel operating the product.
© UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com
90.014.01.0471v.C
(Version v4 Control Box)
pictured: Bamboo top detail
TABLE OF CONTENTS
1
2
3
4
5
6
7
8
SAVE THESE INSTRUCTIONS:
pictured: Laminate top with right hand return
pictured: Rubberwood top detail
PAGE
2
2
3
4
9
9
11
11
®
FRM300-LM/R05
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Uplift Desk Laminate
Summary of Contents for Uplift Desk Laminate
-
Page 1: Table Of Contents
Any user or installer of desk base must study this manual carefully. If this desk is sold, please provide the manual to the buyer, installers, or support personnel operating the product. © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com 90.014.01.0471v.C... -
Page 2: Safety And Warnings
Liability: Under no circumstances does the manufacturer accept warranty claims or liability claims for dam- ages caused from improper use or handling of the desk frame other than that which is described in this operation manual. © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com... -
Page 3: Parts List
You’ll need these tools Return desktop Main desktop Allen wrench Philips Head Screwdriver Tape Measure (included) and/or Power Drill (laminate, bamboo, (laminate, bamboo, or rubberwood) or rubberwood) (qty 1) (qty 1) © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com... -
Page 4: Assembly Instructions
(10) Screws from Step C (22 screws in total). Remove backing from the Adhesive pads (part 10) and position along the brackets and frames as shown. Be sure to not cover any holes for the screws! © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com... - Page 5 On the Return desktop (part 21) carefully align and insert a third Wood screw (part 17a) through a hole, but only partway. This is only to keep the Return desktop from moving around (fig. 2). You will remove this third screw in a later step. © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com...
- Page 6 Place the Keypad (part 12) on the Return desktop assembly and attach using two (2) of the #10x5/8’’ Wood screws (part 17a). Most UPLIFT Desktops include pre-drilled hole locations for the keypad on each end. © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com...
- Page 7 (part 5). Have a second person hold the Return assembly in place to avoid stress- ing the Support brackets, and to keep it still while you lay underneath the desk to finish assembly. Slide the Crossbar rails back into the Corner crossbar end (part 5). © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com...
- Page 8 Your desk has been reset, and is now ready to use. If you have the Advanced 1-touch digtal keypad, the digital display will flash “RST” when you press the DOWN button a second time. For more programming options with the Advanced 1-touch digital keypad, refer to the “Programming” section on page 14. © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com...
-
Page 9: Desk Placement
6. PROGRAMMING (Advanced 1-touch digital keypad only) These UPLIFT Desk programming instructions are compatible only with the Advanced 1-Touch Digital Memory Keypad and control boxes with the following numbers located on the silver sticker: Three-leg frame: 99.046.14.0070... - Page 10 “RST”. Note: While “RST” is still flashing, you can press the “2” button as many times as you’d like to toggle between the two settings. 4. Press the DOWN button until the desktop lowers slightly, then rises slightly and the display changes back to the numeric height setting. © UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com...
-
Page 11: Troubleshooting
Output 24Vdc Copyright Notice: This guide is a component of the UPLIFT Desk™. This guide is a part of the scope of delivery, even if the item is resold. This guide is also available on the UPLIFT © Desk website: upliftdesk.com. Excerpts or copies may not be forwarded to third parties or used in any other published form without the prior written consent of UPLIFT Desk. - Page 12 ® 1-800-349-3839 info@upliftdesk.com www.upliftdesk.com...
