Uplift Desk UDA118 Instructions

Package contents
Main unit
(qty 1)
CAUTION
!
© UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com
®
Front Clamp Standing Converter Instructions
UDA118
Clamp Keyboard Tray
(qty 1) (qty 1)
DO NOT activate this lever until step 3. Activating the lever
before this step will release the gas-powered cylinder and
cause the unit to rise quickly.
Step 1
Place the Main unit top-down on a flat and stable surface.
Using two people, one person hold the Clamp in place as the
other threads the M6x25 bolts into the Clamp onto the Main unit.
Tighten with the Allen wrench.
Again, don't squeeze the paddle on the Main unit. It will release
the gas-cylinder and cause it to rise quickly, possibly causing injury.
(fig. 1)
Step 2
With a friend's help, flip the assembly over and slide it over the
edge of your desk, so that the Clamp is around the edge of your
desk, with the Main unit on top of your desk. (see figure 1)
The Clamp's plate can be adjusted up and down to accommodate
desks from .78'' to 2.9'' in thickness. Move it up for thinner desktops,
and down for thicker desktops.
Once on the desk, screw the Clamp stoppers tight to secure the unit
to your desk.
Step 3
Keep objects clear of the standing converter for this step.
To raise the converter, squeeze the paddle. It is advised you hold
onto it with two hands as you raise (and lower) the worksurface.
This will allow you to adjust the converter and move it to your
desired positions. Release the paddle to lock into place.
Step 4
Undo the latches on both sides of the Main unit.
When in the unlatched position, slide the Keyboard tray onto the
Main unit.
Flip the latches back up. This will secure and lock the tray onto the unit.
M6x25 bolts Allen wrench
(qty 4)
Tacky friction pads
(optional)
UDA118/R01
