Worx Landroid L WG792E Programming Manual page 3

Function messages
Error messages
Notes
If the above error messages appear on the display, correct the problems first, then press "
•
• Before turning power on, always check the Landroid
displayed also when the Landroid
• If for any reason—i.e. a party, children playing...—you want to park your Landroid
Landroid L will go to its base and stay there. Please note the Landroid
®
turn power on. Landroid L will now resume its scheduled mowing session
®
• If an error repeatedly occurs in the same area of your lawn, you might have a problem with the boundary wire so please refer to the previous installation
instructions and check your set up with its help.
• If your lawn is divided in two separated areas, connected by a corridor less than 1 m, one of which is not provided with the charging base: when the
Landroid L runs out of charge, take it manually to the charging base, turn power on, press the key with the home symbol and the charge process will start.
®
• If the Landroid L runs abnormally once in a while, please try to restart it. If the problem cannot be solved, please contact WORX Service Agent for help.
®
• Do not wash the machine with a high pressure washer. This could cause damage to the battery or the machine.
• Your Landroid L software can be updated when new versions become available. The software version will be displayed in the bottom right hand corner of the
®
display. The manual in box is based on the default software in the mass production .Some new features/functions in the new version may not exist in the manua. If
you found some settings not in the manual, please visit www.worxlandroid.com to download the latest manual. You can check the software version installed
on your machine by pressing the ON/OFF button.
Cutting grass according to the program set.
When it senses rain, the Landroid
programmed it to do so. When dry, the Landroid
then return to mowing. If you want Landroid
when the rain sensor is dry or you can set the delay time to 0 min.
Needs a recharge - during the journey to the base, the cutting blade is stopped in order to save energy.
Charge is in progress - voltage, current, charge percentage are displayed.
Stand-by, will start according to program set.
1. If the Landroid L is actually outside its territory: open the keypad window, turn power off, take the
®
Landroid L inside its territory. Turn power on and close the keypad window.
®
2. If the Landroid L is inside its territory: check the LED on the charging base is on. If not, check the
®
plug connection to the mains socket. If the LED is still off, check the boundary wire is well connected
to the clamps on the charging base.
3. If the problem persists, check that the boundary wire hasn't been cut.
Refer to the "Programming" section to re-set your PIN
1. Open the keypad window;
2. Turn power off;
3. Turn the Landroid L upside down and check if there is anything preventing the blade disc to rotate.
®
4. Remove any possible obstruction.
5. Turn the Landroid L upright and take it to an area with short grass;
®
6. turn power on and close the keypad window.
1. Open the sliding keypad window;
2. turn power off: take the Landroid
3. turn power on and close the keypad window.
4. If the error message is still displayed, open the keypad window again; turn power off; turn the Landroid
upside-down and check if there is anything preventing the wheels from rotating.
5. Remove any possible obstruction, turn the Landroid
1. Open the sliding keypad window.
2. Turn power off.
3. Take the Landroid L in an area free from obstacles.
®
4. Turn power on and close the keypad window.
5. If the error message is still displayed, open the keypad window again; turn power off; turn the Landroid
upside-down and check if there's anything preventing the wheels from rotating.
6. Remove any possible obstruction, turn the Landroid
1. Open the keypad window, turn power off.
2. Take the Landroid L to an area clear of obstacles, turn power on and close the keypad window.
®
3. If the error message is still displayed: open the keypad window, turn power off, turn the Landroid
down and check there is nothing trapped.
4. Remove any possible object, turn the Landroid
Turn the Landroid L upright. Open the keypad window then close it.
®
1. The contact between the Charging and Contact Strips may be obstructed in some way.
2. Wipe off the Charging and Contact Strips, making sure there is not an object obstructing them, then place
your Landroid L in the charging base and check that the strips make good connection.
®
1. This means that there is low battery voltage
2. In this case you must place the mower in the Charging Base with the Landroid
press the ON/OFF button before the light turns green, and close the Keypad Window to start charging.
L is inside its territory. If not, the message "outside working area" will be displayed. This message is
®
L is sitting over the boundary wire when turned on.
®
L will return to the Charging Base and stay there for the time you have
®
L CPU will automatically begin the delay and countdown and
®
L to mow before this, simply turn it off then on again, but only
®
L in an area free from obstacles;
®
L upright, turn power on and close the keypad window.
®
L upright, turn power on and close the keypad window.
®
L upright, turn power on and close the keypad window.
®
L in the charging base: press the key with the home symbol
®
L will now wait until the next scheduled mowing session. If you want to re-start it:
®
L is powered off. Then
®
" to reset.
. The
L
®
L
®
L upside-
®
