KITO ER2 Owner's Manual Supplement
Cylinder control electric chain hoist 125 kg & 250 kg / hook suspension er2c / with plain trolley er2csp
Hide thumbs
Also See for ER2:
- Owner's manual (164 pages) ,
- Disassembly and reassembly manual (52 pages) ,
- Owner's manual supplement (12 pages)
Subscribe to Our Youtube Channel
Related Manuals for KITO ER2
Summary of Contents for KITO ER2
- Page 1 OM-ER2CZZ-MGE-00 ER2 Cylinder Control Electric Chain Hoist (125 ㎏ & 250 ㎏) SUPPLEMENTARY OWNER'S MANUAL Hook Suspension: ER2C With Plain Trolley: ER2CSP...
-
Page 2: Safety Precautions
"Product Specifications" in "ER2 Series Electric Chain Hoist (125kg to 5t) Owner's Manual" (separate volume). For the operating conditions, please also refer to the ER2 Series Electric Chain Hoist (125kg to 5t) Owner's Manual, and for the dimensions, refer to the Appendix in this manual. - Page 3 Rated load Hoist Dual speed Dual speed body Single speed Single speed inverter inverter 125 ㎏ ER2C001H ER2C001IH ER2CSP001H ER2CSP001IH ER2-B 250 ㎏ ER2C003S ER2C003IS ER2CSP003IS ER2CSP003IS Configurations & Name Hook suspension Plain trolley Cable support Curl cord Load chain Emergency...
- Page 4 Assembly When some parts may not be pre-installed depending on the specifications of your order, please properly attach them in accordance with the following instructions. Attachment of Top Hook (or Suspender) 1) Remove the Shaft Retainer Clip using plier. 2) Remove Socket Bolt from the Shaft Retainer, and remove the Shaft Retainer.
-
Page 5: Emergency Stop
DANGER Make sure that the split pin is securely bent. Make sure that the stopper and cushion rubber are attached to the correct chain link. Failure to follow these precautions may cause serious accidents leading to serious or even fatal injury. Operations ... - Page 6 In the dual-speed inverter, the low and high speeds can be adjustable by changing the inverter parameters. Make sure that these parameters are properly set in accordance with the KITO ER2 Series Electric Chain Hoist (125kg to 5t) Owner's Manual as well as the KITO ER2 Series Electric Chain Hoist (125kg to 5t) Inverter Manual.
-
Page 7: Daily Inspection
Failure to perform daily inspection may cause serious accidents leading to serious or even fatal injury. For the inspection items other than the followings, refer to the KITO ER2 Series Electric Chain Hoist (125kg to 5t) Owner's Manual. Item... -
Page 8: Troubleshooting
At the time of monthly or annual inspection, also perform daily inspection. For the inspection items other than the followings, refer to the KITO ER2 Series Electric Chain Hoist (125kg to 5t) Owner's Manual for the items corresponding to your hoist capacity. - Page 9 Appendix Technical Data Hook Suspension [Specifications] Load Lifting motor Lifting speed (m/s) Additional chain Standard weight Capacity Product Hoist *Weight Diameter lift Class (kg) code body (kg) Output Rating (mm) 1m lift 50Hz 60Hz （kW） (kg) Chain falls ER2C001H 0.235 0.282...
- Page 10 With Plain Trolley Suspension [Specifications] Load Lifting motor Lifting speed (m/s) chain Applicable Additional Min. Standard beam Diameter weight radius Capacity Product Hoist *Weight lift width (mm) Class curve (kg) code body Output (kg) Rating 50Hz 60Hz 1m lift （kW）...
-
Page 11: Wiring Diagrams
Wiring Diagrams Single speed - ER2C001H/003S, ER2CSP001H/003IS Emer- gency stop... - Page 12 Dual-speed Inverter - ER2C001IH/003IS, ER2CSP001IH/003IS...
- Page 13 《MEMO》...
- Page 14 Global Website：kito.com...
