Inverter MINI SPLIT Owner's Manual And Installation Manual page 8

Precautions
For the air conditioner with plug, the plug should be reachable after
finishing installation.
For the air conditioner without plug, an circuit break must be
installed in the line.
If you need to relocate the air conditioner to another place, only the
qualified person can perform the work. Otherwise, it may cause
personal injury or damage.
Select a location which is out of reach for children and far away from
animals or plants.If it is unavoidable, please add the fence for safety
purpose.
The indoor unit should be installed close to the wall.
Instructions for installation and use of this product are
provided by the manufacturer.
Working temperature range
For model: 9000 BTU + 12000 BTU -
Maximum cooling
Maximum heating
NOTICE:
The operating temperature range (outdoor temperature) for cooling only unit is
64.4°F(18°C) ~ 109.4°F(43°C) ; for heat pump unit is 19.4 °F(-7 °C) ~ 109.4°F(43°C) .
For model: 9000 + 12000 BTU -
Maximum cooling
Maximum heating
NOTICE:
The operating temperature range (outdoor temperature) for cooling only unit is 5°F(-15°C)
~ 109.4°F(43°C) ; for heat pump unit is 5°F(-15°C) ~ 109.4°F(43°C) .
For model: 18000 + 24000 BTU -
Maximum cooling
Maximum heating
NOTICE:
The operating temperature range (outdoor temperature) for cooling only unit is 5°F(-15°C)
~ 115°F(46°C) ; for heat pump unit is 5°F(-15°C) ~ 115°F(46°C) .
WARNING
110~115V, 60Hz
Indoor side DB/WB(°F/°C ) Outdoor side DB/WB(°F/°C)
89.6/73.4(32/23)
80.6/-(27/-)
220~230V, 60Hz
Indoor side DB/WB(°F/°C ) Outdoor side DB/WB(°F/°C)
89.6/73.4(32/23)
80.6/-(27/-)
220~230V, 60Hz
Indoor side DB/WB(°F/°C ) Outdoor side DB/WB(°F/°C )
89.6/73.4( 32/23)
80.6/-( 27/-)
5
109.4/78.8(43/26)
75.2/64.4(24/18)
109.4/78.8(43/26)
75.2/64.4(24/18)
115/78.8( 46/26)
75.2/64.4( 24/18)
