  • Page 1 DOCTRINE TECHNICAL MANUAL...
  • Page 2: Table Of Contents

    INTRODUCTION DOCTRINE INTRODUCTION Geometry .............................2 Congratulations on purchasing a Felt Doctrine. As with all of our Brake Decoupling Bracket ......................3 bikes and components, our aim is to provide the rider with the SETUP best product and riding experience. Read this manual supplement thoroughly, as it’s to help you set your bike up correctly,...
  • Page 3: Geometry

    GEOMETRY BRAKE DECOUPLING BRACKET All doctrine frames include a decoupling bracket. This bracket removes the brake tab from the seat stay improving braking performance. It should be installed as follows: Mount caliper on adapter with 6mm socket head cap screws.
  • Page 4: Caliper Installation

    CABLE GUIDES Install the caliper/adapter assembly on bike There are 3 interchangeable cable guides using included 5mm socket head cap screws, that fit the Doctrine. but do not tighthen them down yet. Install wheel and rotor • Two Hole 5mm x 3mm (CCN098YB)
  • Page 5: Cable Configuration

    CABLE PORT CONFIGURATION CABLE PORT CONFIGURATION MECHANICAL SHIFTING 1X MECHANICAL SHIFTING 2X or DROPPER POST Two Hole Blanking Plate Two Hole 5mm Two Hole 5mm 5mm x 3mm DI2 WIRE DI2 WIRE BRAKE CABLE BRAKE CABLE DERAILLEUR CABLE DERAILLEUR CABLE DROPPER POST CABLE DROPPER POST CABLE / DERAILLEUR CABLE...
  • Page 6: Di2 1X Or 2X

    CABLE PORT CONFIGURATION CONTACT INFORMATION DI2 1X or 2X Felt Racing, LLC Felt GmbH 12 Chrysler Industriestr. 39 Irvine, CA 92618 26188 Edewecht Germany WWW.FELTBICYCLES.COM Two Hole Blanking Plate 5mm x 3mm DI2 WIRE BRAKE CABLE DERAILLEUR CABLE DROPPER POST CABLE...
