Vinotemp VC7S Service Manual
  1. Manuals
  2. Brands
  3. Vinotemp Manuals
  4. Wine Cooler
  5. VC7S
  6. Service manual

Vinotemp VC7S Service Manual

Hide thumbs

Advertisement

Quick Links

Can help service:
24PR125
15PR28
18PR28
24PR46
VT-OUTDOORREF
VT-FZR24OI
VT-50FDHT
vt-outdoor15gd
vt-outdoor24gd
W
C
INE
ABINETS
S
ERVICE
(C
R
. B V20140828)
ODE
EV
CONTENT
1. SAFETY PRECUATIONS
9. EXPLODED VIEW & PARTS LIST
M
ANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the VC7S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vinotemp VC7S

Summary of Contents for Vinotemp VC7S

  • Page 1: Table Of Contents

    Can help service: 24PR125 15PR28 18PR28 24PR46 VT-OUTDOORREF VT-FZR24OI VT-50FDHT vt-outdoor15gd vt-outdoor24gd ABINETS ERVICE ANUAL . B V20140828) CONTENT 1. SAFETY PRECUATIONS 2. SPECIFICATIONS 3. REFRIGERATING COOLING SYSTEM 4. ELECTRICAL AND CONTROL SYSTEM 5. COMPRESSOR ROOM VIEW AND PARTS LIST 6.
  • Page 2  WARNING   Before servicing, make sure to unplug the appliance.  Replace all parts before operating the appliance after service.  Failure to do so could result in death, electrical shock or personal injury.  All servicing must be carried out by the qualified technicians. Repairs undertaken incorrectly may cause the considerable risk to the user.

  • Page 3: Specifications

    2. SPECIFICATIONS VC7S Model No. Built-in or Free Standing Installation Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 16 ~ 38 / 60 ~100 Setting Temp. Range °C/°F...
  • Page 4 VC20S VC20D Model No. Built-in or Free Standing Installation Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 16 ~ 38 / 60 ~100 0 ~ 38 / 32 ~100 Setting Temp.
  • Page 5 VC33S VC33D Model No. Built-in or Free Standing Installation Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 16 ~ 38 / 60 ~100 0 ~ 38 / 32 ~100 Setting Temp.
  • Page 6 VC54S VC54D Model No. Built-in or Free Standing Installation Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 0 ~ 38 / 32 ~100 0 ~ 38 / 32 ~100 Setting Temp.
  • Page 7 VC54SB VC54DB Model No. Built-in or Free Standing Installation Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 0 ~ 38 / 32 ~100 0 ~ 38 / 32 ~100 Setting Temp.
  • Page 8 VC100S VC100D Model No. Built-in or Free Standing Installation Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 0 ~ 38 / 32 ~100 0 ~ 38 / 32 ~100 Setting Temp.
  • Page 9 VC125S VC125D Model No. Built-in or Free Standing Installation Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 0 ~ 38 / 32 ~100 0 ~ 38 / 32 ~100 Setting Temp.
  • Page 10 VC170S VC170D Model No. Built-in or Free Standing Installation Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 0 ~ 38 / 32 ~100 0 ~ 38 / 32 ~100 Setting Temp.
  • Page 11 VC118D VC118T Model No. Built-in or Free Standing Installation Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 0 ~ 38 / 32 ~100 0 ~ 38 / 32 ~100 Setting Temp.
  • Page 12 VC28S Model No. Built-in in-column Installation (Fully Integrated) Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 16 ~ 33 / 60 ~90 Setting Temp. Range °C/°F 5 ~ 22 / 40 ~ 72 Power Source...
  • Page 13 VC55S VC55D Model No. Built-in in-column Installation (Fully Integrated) Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 0 ~ 38 / 32 ~100 0 ~ 38 / 32 ~100 Setting Temp.
  • Page 14 VC90S VC90D Model No. Built-in in-column Installation (Fully Integrated) Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 0 ~ 38 / 32 ~100 0 ~ 38 / 32 ~100 Setting Temp.
  • Page 15 VC80T Model No. Built-in in-column Installation (Fully Integrated) Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 0 ~ 38 / 32 ~100 Setting Temp. Range °C/°F 5 ~ 22 / 40 ~ 72 Power Source...
  • Page 16 VC20DA VC54DA Model No. Built-in or Free Standing Installation Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 0 ~ 38 / 32 ~100 0 ~ 38 / 32 ~100 Setting Temp.
  • Page 17 VC100DA Model No. Built-in or Free Standing Installation Type Capacity Total Storage Volume - L Wine Storage Bottles Zone One Zone Two Zone Three Performance & Features Ambient Temp. Range °C/°F 0 ~ 38 / 32 ~100 Setting Temp. Range °C/°F 5 ~ 22 / 40 ~ 72 Power Source...

  • Page 18: Refrigerating Cooling System

    3. REFRIGERATING COOLING SYSTEM 3.1 REFRIGERANT CYCLE DIAGRAM 3.1.1 For models with Without Solenoid Valve 1. Compressor 7. Filter Drier 2. Spiral Tube (Not available for some 8. Capillary models) 9. Evaporator Fan 3. Condenser Fan (Not available for 10. Accumulator some models) 11.
  • Page 19 3.1.2 For models with Solenoid Valve 1. Compressor 8. Solenoid Valve 2. Spiral Tube 9. Capillary 3. Condenser Fan 10. Evaporator Fan 4. Condenser 11. Accumulator 5. Hot Pipe 12. Evaporator 6. Process Tube 13. Suction Tube 7. Filter Drier 14.
  • Page 20 3.2 REFRIGERATION SYSTEM All refrigeration units cool by removing heat from the cabinet rather than pumping in cool air. In a conventional refrigeration unit, liquid refrigerant enters the evaporator and vaporizes (boils) due to the low pressure, creating a very cold surface which removes heat from inside the cabinet. This causes the refrigerant to boil (evaporate) into a vapor state and be drawn into the compressor.
  • Page 21 3.3 REFRIGERATION SYSTEM COMPONENTS Compressor The compressor is the "heart" of the refrigeration unit, consisting of an electrical motor and a "pump" sealed inside a steel case. The compressor used on R134A refrigerant systems is virtually the same in external appearance as the compressor used with R600a refrigerants. However, due to changes in lubricants and other internal differences, the compressors are not to be interchanged, otherwise system failure will result.
  • Page 22 3.4 SERVICE PRECAUTIONS FOR R600A SYSTEM Features of refrigerant (R600a)  Achromatic and odor less gas.  Flammable gas and the ignition (explosion) at 494°C.  Upper/lower explosion limit: 1.8%~8.4%/Vol. Features of the R600a refrigeration unit  Charging of around 60% refrigerant compared with a R134a model ...
  • Page 23 that is connected to the discharging hose leading to the outside. When discharging the residual refrigerant, repeat 3 cycles that includes 3min of the pump running->pump off->30sec of the compressor running. After the refrigerant (R600a) is completely discharged, repair any defective parts and replace the filter dryer.
  • Page 24 3.5 SERVICE PRECAUTIONS FOR R134A SYSTEM LIMIT TIME OF EXPOSURE TO THE ATMOSPHERE Whenever a sealed system is repaired, do not expose an open line to the atmosphere for more than 15 minutes. Replacement components will come sealed by either brazing (filter drier) or plugs (compressor).
  • Page 25 too far into the drier and contacting the screen. To facilitate the installation, place a slight bend in the capillary tube about 3/4inch from the end and insert into the drier. Remove the process tube adapter from the condenser outlet and prepare the tube for connection to the drier inlet. The drier inlet joint will be the only copper-to-steel connection which will require the silver solder and flux.
  • Page 26 remain open throughout sweep procedure), open valve A to allow three (3) ounces of refrigerant into the system. Close valve A. Check low side for leaks. After system has equalized (about 3 to 5 minutes), start system compressor, check for high side leaks and allow refrigerant to circulate in the system about 5 minutes.
  • Page 27 accumulation of frost. Where possible, check the capillary tube and straighten any kinks to relieve the restrictions. Check the unit operation. If the condition persists, replace the defective part. If the freeze-up condition does not exist and there is not a kink, you can assume that a foreign particle is causing the restrictions.

  • Page 28: Electrical And Control System

    4. ELECTRICAL AND CONTROL SYSTEM 4.1 CONTROL DESCRIPTION 4.1.1 FUNCTIONS Cooling mode: When the set temperature is lower than the storage temperature, the unit operates in cooling mode. Heating mode: When the set temperature is higher than the storage temperature, the unit operates in heating mode.
  • Page 29 the range from -9 to 37ºC for Celsius degree and from 16 to 99ºF for Fahrenheit degree. That is normal. Temperature Alarm An alarm will sound if the temperature in one of the zones rises or falls outside the temperature range.
  • Page 30 without pressing any key, the key lock will be activated automatically. To remove the lock, press the UP and DOWN keys at the same time for at least 5 seconds and the indicator light will flash three times to confirm the input. ºF/ºC Selector Select the temperature display setting in Fahrenheit or Celsius degree.
  • Page 31 4.1.5 SELF-CHECK OF CONTROL SYSTEM The Display/Control PCB has the self-check function. Press and hold the “LIGHT” and “DOWN” keys at the same time for 5 seconds, the indicator light will flash once to confirm the input and the unit will activate the self-check program. Below symptoms can be seen, otherwise replace the PCBs: ...
  • Page 32 4.2.2 For freezer models DOOR SWITCH/N.A TCD-S0 BN(BK) YE/GN YE/GN BL(WH) LAMP STARTER YE/GN TCJ-POWER(D)(XH) HEATER1 COMPRESSOR 4.2.3 For dual zone models without solenoid valve For control panel inside the cabinet TCJ-FM TCJ-D1(XH) Air Door DOOR SWITCH/N.A BN(BK) YE/GN YE/GN BL(WH) LAMP STARTER...
  • Page 33 For control panel on the top of cabinet TCJ-D1(XH) DOOR SWITCH/N.A BN(BK) TCJ-FM Air Door YE/GN YE/GN BL(WH) LAMP STARTER YE/GN TCJ-POWER(D)(XH) COMPRESSOR HEATER2 4.2.4 For dual zone models with solenoid valve TCJ-D0(XH) DOOR SWITCH/N.A BN(BK) YE/GN YE/GN BL(WH) LAMP STARTER YE/GN TCJ-POWER(D)(XH)
  • Page 34 4.2.5 For three zone models TCJ-T1(A)(XH) TCJ-T1(B)(XH) DOOR SWITCH/N.A BN(BK) YE/GN YE/GN BL(WH) LAMP STARTER F1H/N.A YE/GN TCJ-POWER(D)(XH) COMPRESSOR HEATER1 HEATER2 4.3 SCHEMATIC DIAGRAM FOR PCB 4.3.1 Power PCB...
  • Page 35 4.3.2 Control PCB for Dual Zone & Upper Control Unit of Three Zone...
  • Page 36 4.3.3 Control PCB for Single Zone & Lower Control Unit of Three Zone...
  • Page 37 4.4 SENSOR RESISTANCE CHARACTERISTICS TABLE MEASURED TEMPERATURE RESISTANCE OF SENSOR (°C) (kΩ) 116.55 104.97 94.67 85.49 77.30 69.99 63.44 57.58 53.32 47.60 43.35 39.53 36.08 32.97 30.16 27.62 25.32 23.24 21.35 19.63 18.07 16.65 15.35 14.17 13.10 12.11 11.21 10.39 10.00 9.63 8.94...

  • Page 38: Compressor Room View And Parts List

    5. COMPRESSOR ROOM VIEW AND PARTS LIST 1. Joint of condenser outlet tubing and hot pipe inlet tubing 2. Electrical Box of Compressor 3. Process Pipe 4. Electrical Box (Power PCB inside) 5. Compressor 6. Suction Pipe 7. Discharge Pipe 8.

  • Page 39: How To Reverse The Door Swing

    6. HOW TO REVERSE THE DOOR SWING This wine cellar has the capability of the door opening from either the left or right side. The unit is delivered to you with the door opening from the left side. Should you desire to reverse the opening direction, please follow the following reversal instructions: Note: All parts removed must be saved to do the reinstallation of door.
  • Page 40 cabinet. (Fig. 4) ○ 7. Unscrew and transfer the lock bracket 13 to the opposite side of glass door. Then use the ○ crystal cover 12 included in the fittings to cover the three holes left after unscrewing the lock bracket.(Only for models with lock on the ventilation grille) (Fig. 5) 8.
  • Page 41 6.3 DESIGN 3 – For tall models ○ ○ 1. Remove the bottom hinge 1 by unscrewing the four lock screws 2 . Be careful to hold the glass door firmly after removing the screws. (Fig. 1) 2. Gently pull down to remove the glass door from the right top hinge and place it on a padded ○...
  • Page 42 6.4 DESIGN 4 – For double door models ○ ○ 1. Remove the bottom hinge 1 by unscrewing the four screws 2 . Be careful to hold the ○ lower glass door 3 firmly after removing the screws. And then gently pull down to remove the lower glass door from the middle hinge and place it on a padded surface to avoid the risk of damage.

  • Page 43: How To Replace The Main Parts

    9. Set the lower glass door to the designated position and reassemble the bottom hinge. ○ ○ Recheck and adjust the lower door alignment by loosening the screws 5 & 6 and ○ ○ ○ ○ moving the door adapter 4 &...
  • Page 44 7.1B REPLACING THE CONTROL PCB (ONLY FOR SINGLE ZONE MODELS WITH CONTROL PCB AFTER THE DOOR) 1. Remove all shelves. ○ ○ ○ 2. Unscrew the four screws 6 that secure the PCB box 4 to the top of cabinet 3.
  • Page 45 ○ 6. Then carefully remove the control PCB 2 from the PCB supporter. Now you can replace the control PCB and Power PCB. 7.2 REPLACING THE CONTROL PCB, FAN MOTOR, AIR DOOR ASSEMBLY AND LED LIGHT IN THE MIDDLE DIVIDER (EXCEPT OF VC20D & VC33D) 1.
  • Page 46 REPLACING THE CONTROL PCB, FAN MOTOR, AIR DOOR ASSEMBLY AND LED LIGHT IN THE MIDDLE DIVIDER (ONLY FOR VC20D & VC33D) 1. Remove all shelves. ○ 2. Remove the two screws 2 that connect the bottom plate and top plate of middle divider. ○...
  • Page 47 7.3 REPLACING THE POWER PCB (EXCEPT OF VC7S, VC20 AND VC33) ○ 1. Remove the five screws 1 that fix the rear grille to the cabinet. ○ ○ 2. Remove the screws 3 and ○ ○ ○ 3. Pull out the electrical box base 4 &...
  • Page 48 7.4 REPLACING THE VENTILATION GRILLE / LOCK ASSEMBLY (FOR VC100, VC125 & VC170 SERIES) ○ ○ 1. With assistance, tilt the unit back and remove the lock screws 1 & 5 holding the bottom ○ ○ hinge 2 and door supporter assembly 4 to the cabinet.
  • Page 49 7.5 REPLACING THE LED LIGHT 1. Remove all shelves. ○ 2. Remove the LED light cover 1 by fingernail. 3. Pull down to remove the LED light PCB and replace it with a new one. IMPORTANT: Pls insert the new LED light PCB with correct polarity! 7.5A REPLACING THE LED LIGHT 1.
  • Page 50 7.6 REPLACING THE EVAPORATOR FAN MOTOR AND TEMPERATURE SENSOR IN THE UPPER ZONE FOR DUAL ZONE MODELS 1. Remove all shelves. ○ ○ 2. Remove the screws 1 that secure the upper air channel cover 4 to the cabinet. 3. Disconnect the evaporator fan motor F1C wires. Then pull out the upper air channel cover. ○...
  • Page 51 7.8 REPLACING THE EVAPORATOR FAN MOTOR, TEMPERATURE SENSOR AND PTC HEATER FOR SINGLE ZONE MODELS 1. Remove all shelves. ○ ○ 2. Remove the screws 2 that secure the air channel cover 1 to the cabinet. 3. Disconnect the evaporator fan motor wires. Then pull out the air channel cover. ○...
  • Page 52 7.10 REPLACING THE EVAPORATOR ASSEMBLY NOTE: Before replacing any component of the refrigeration system, make sure to read the instructions “Service Precautions for R600A System” or “Service Precautions for R134a System”. 1. Disconnect the unit from the power source. 2. Clean and then solder the capillary from the filter drier. 3.
  • Page 53 7.11 REPLACING THE COMPRESSOR, COMPRESSOR PTC STARTER AND OVERLOAD PROTECTOR NOTE: Before replacing any component of the refrigeration system, make sure to read the instructions “Service Precautions for R600A System” or “Service Precautions for R134a System”. All replacement compressors are charged with the correct amount of oil and a holding charge of dry nitrogen.
  • Page 54 7.13 REPLACING THE CONDENSER NOTE: Before replacing any component of the refrigeration system, make sure to read the instructions “Service Precautions for R600A System” or “Service Precautions for R134a System”. 1. Disconnect the unit from the power source. ○ 2. Clean and then solder the inlet and the outlet tube from the old condenser ○...
  • Page 55 7.14 LEVELING THE DOOR / HINGE ADJUSTMENTS ○ With assistance, tilt the unit back and loosen the screws Adjust the glass door to make the door top is parallel with the cabinet top then tighten the screws. Hinge adjustments are necessary when: ...

  • Page 56: Troubleshooting

    8. TROUBLESHOOTING 8.1 TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE REMEDY  Appliance is not connected to a  Connect the appliance. power supply. Appliance does not  The appliance is turned off.  Switch on the appliance. operate.  The circuit breaker tripped or a blown ...
  • Page 57 in the evaporator is short circuit.  “E4” indicates that the defrost sensor in the evaporator is open circuit.  “E5” indicates the defrost heater failure.  “E6” indicates the solenoid valve failure.  E7” indicates the door switch failure. ...
  • Page 58 SYMPTOM DIAGNOSIS For models - Single zone with cooling only The displayed temperature is 1. Is the ambient temperature too high more than 35°C? higher than the set temperature. 2. Is he ventilation blocked? 3. Is the fan motors failed? 4.
  • Page 59 temperature in the lower zone is 3. Is the isolation between the upper zone and lower zone not good? lower than the set temperature. For models - Dual zone with two doors The displayed temperature is 1. Is the ambient temperature too high more than 35°C? higher than the set temperature.
  • Page 60 8.4 SPECIAL DETAILED DIAGNOSIS 8.4.1 DETECT THE MAIN PCB & DISPLAY/CONTROL PCB 1. The control system including the MAIN PCB and DISPLAY/CONTROL PCB operates when the unit is powered. If not, the unit is either POWER OFF or Switch OFF. If neither operates, check the control system including the main PCB and Display/Control PCB and connecting wirings.
  • Page 61 the motor is either defective or disconnected. If neither operates, check the main PCB and the cabinet wiring. 2. The evaporator fan motor also operates when the PTC heater operates for single zone models with heat function. 3. To Check The Evaporator Fan Motor, ...
  • Page 62  Remove the air duct cover.  Disconnect the PTC lead connector from the cable.  Connect the PTC heater to a rated power source on the rating label. If the PTC heater fails to operate, it is defective and must be replaced. 8.4.7 OVERLOAD PROTECTOR The overload protector prevents the compressor from burning out its electrical windings in the event the compressor becomes overheated or draws too much current.
  • Page 63 compressor, the PTC device's low resistance shorts out the run capacitor; thus producing adequate motor starting torque. As the compressor motor approaches run-ning speed, the current through the PTC device causes the temperature and resistance of the PTC device to increase to where it appears to be an open circuit.
  • Page 64 8.4.10 ABNORMAL NOISE / NORMAL NOISE Compressor Noise  The working of the electrical motor and the pump inside the compressor will cause noise during the run time. The noise should be stable and not exceed 42 dB(A). If the noise is excessive, the compressor is failed and should be replaced.
  • Page 65  The foams at the two sides of evaporator are lost or damaged. Replace the foams.  The temperature sensor is failed.  The compressor operates continuously & independent from the set temperature. At the same time the condenser fan motor does not operate. The POWER PCB has been failed and replace the POWER PCB.
  • Page 66 “E1” indicates the corresponding air temperature sensor is short circuit. It may be caused by the following reasons: The temperature sensor is failed. – Replace the thermistor. The Power PCB is failed. – Replace the Power PCB. The Control PCB is failed. – Replace the Control PCB. The connecting wire is failed such as the screw has made the wires short circuit.
  • Page 67 Wrong connection of capillary for left/upper zone and right/lower zone. Wrong connection of thermistor for left/upper zone and right/lower zone. 8.4.20 DSIPLAY “E7” “E7” indicates the door switch failure. It may be caused by the following reasons: The door is not closed properly. Pls open and close the door with a little more force. The door switch is defective.
  • Page 68 8.5.7 The appliance never seems to stop: the unit is always on. Make sure the door is closed properly. Add a separate thermometer inside the cellar to see if the cellar thermostat indicates the same temperature. If the results are different, replace the thermistor or Control PCB or Main PCB.
