- Page 1 A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y W I N E C E L L A R V T - 4 8 T E D S - 2 Z ( 4 8 b o t t l e s ) O W N E R ’...
- Page 2 Y o u r W i n e C e l l a r This unit can be used for Storage and/or Service. The unit has a glass door and soft interior light to elegantly display your wine. S e r v i n g W i n e s Storing wines at the proper temperature is important.
- Page 3 Upon receipt and inspection of unit, the supply cord must be replaced if it is damaged. Contact our customer service at 1-800-777-8466 or info@vinotemp.com. READ ALL INSTRUCTIONS BEFORE USING THIS WINE COOLER To register your product, visit: http://www.vinotemp.com/Warranty.aspx...
-
Page 4: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..........5 ELECTRICAL CONNECTION ............5 CABINET DIAGRAM ..............6 CIRCUIT DIAGRAM..............6 TECHNICAL DATA ............... 7 INSTALLATION INSTRUCTIONS............. 8 OPERATING YOUR WINE CELLAR ..........8 CARE AND MAINTENANCE ............9 TROUBLESHOOTING ..............10 TERMS OF SALE AND WARRANTY ..........11 SERVICE &... -
Page 5: Important Safety Instructions
ELECTRICAL CONNECTION WARNING: Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, please contact Vinotemp Customer Service at 1-800-777- 8466 or info@vinotemp.com. For your protection, this unit is equipped with a 3-conductor cord set that has a molded 3- prong grounding-type plug, and should be used in combination with a properly connected grounding-type outlet. -
Page 6: Cabinet Diagram
CABINET DIAGRAM Fan Mask Light On/Off Button Shelf Gasket Water Box Door Hinge Cover Door Handle Temperature Control Button Foot CIRCUIT DIAGRAM... -
Page 7: Technical Data
TECHNICAL DATA Model No. VT-48TEDS-2Z Capacity 140L / 48 Bottles Voltage 110V Current 2.2A (@77°F) Protection Class Frequency 60Hz Climate Class SN;N Input Power 180W(@77°F) Power Consumption 2.2 (@59°F) kWh/24h Temperature Range 54-66°F Approx. Net Weight 91.5 Lbs Approx. Gross Weight 98.6 Lbs... -
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS Before Using Your Wine Cellar: • Remove any exterior and interior packing material. • Check to be sure the following parts are included: ♦ 14 slide out shelves (7 for each side) ♦ 1 instruction manual • Before connecting the appliance to the power source, let it stand upright for approximately 2 hours. -
Page 9: Care And Maintenance
CARE AND MAINTENANCE Cleaning Your Wine Cellar • Unplug the wine cellar and remove the bottles. • Wash the inside with a warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda to a quart of water. •... -
Page 10: Troubleshooting
TROUBLESHOOTING You can solve many common wine cellar problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before contacting Vinotemp at info@vinotemp.com. SYMPTOM POSSIBLE CAUSE Door will not close •... -
Page 11: Terms Of Sale And Warranty
Note: Unfinished wood is subject to warping; all wood surfaces must be sealed before placing cellar into service. Improper placement of the unit will void the warranty. By Vinotemp in writing, any third party repair facility must be pre-approved before providing parts free of charge. -
Page 12: Service & Important Notice
