A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y
D u a l Z o n e W i n e &
B e v e r a g e C o o l e r
O W N E R ' S
c
Temp.
F
C/ F
V T - 3 6
M A N U A L
W W W . V I N O T E M P . C O M
c
Temp.
F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VT-36 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vinotemp VT-36

Summary of Contents for Vinotemp VT-36

  • Page 1 A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y Temp. C/ F Temp. D u a l Z o n e W i n e & B e v e r a g e C o o l e r V T - 3 6 O W N E R ’...
  • Page 2 W W W . V I N O T E M P . C O M...
  • Page 3 Y o u r w i n e c e l l a r This unit can be used for storage and/or service. The unit has seamless glass door and soft interior light to elegantly display your wine. S e r v i n g W i n e s Storing wines at the proper temperature is important.
  • Page 4 Upon receipt and inspection of unit, the supply cord must be replaced if it is damaged. Contact our customer service at 1-800-777-8466 or info@vinotemp.com. • Let the unit rest UNPLUGGED for 24 hours once you have it placed in your home.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..........6 ELECTRICAL CONNECTION ............... 7 PARTS & SPECIFICATIONS ............... 8 TECHNICAL DATA ................8 INSTALLATION ................9 OPERATING YOUR WINE COOLER ............ 10 CARE AND MAINTENANCE .............. 11 PROBLEMS WITH YOUR WINE COOLER ..........13 TROUBLESHOOTING ..............

  • Page 6: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electrical shock or injury when using your appliance, follow these basic precautions: • Do not operate this or any other appliance with a damaged cord. • Do not operate if housing is removed or damaged. •...

  • Page 7: Electrical Connection

    ELECTRICAL CONNECTION Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, frayed or shows cracks or abrasions across its length, have it replaced at an authorized service center. For your protection, this unit is equipped with a 3-conductor cord set that has a molded 3-prong grounding-type plug, and should be used in combination with a properly connected grounding-type outlet.

  • Page 8: Parts & Specifications

    PARTS & SPECIFICATIONS TECHNICAL DATA Model no. VT-36 Left Zone: 58 12 oz cans Capacity Right Zone: 19 bottles Voltage 115V AC Current 2A (77˚F) Frequency 60 Hz Input Power 100W (77˚F) Power Consumption (kWh/24h) 1.0 (59˚F) Left Zone: 36°- 43° F Control Temperature Range Right Zone: 40°- 72°...

  • Page 9: Installation

    INSTALLATION BEFORE USING YOUR APPLIANCE • Remove the exterior and interior packaging. • Before connecting the appliance to the power source, let it stand upright for approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation.

  • Page 10: Operating Your Wine Cooler

    INSTALLING THE HANDLES • Pull away the door gasket in the area where the handle is to be installed. The gasket is easily removed by hand, no tools are necessary. • Insert the two (2) Phillips head screws with the lock washers and flat washers through the gasket side of the door frame until the screws pass through the door frame.

  • Page 11: Care And Maintenance

    decrease by 1°C or 1ºF if you touch DOWN once. • To view the set temperature at any time, touch the UP or DOWN marks. The set temperature will temporarily flash in the LED display for 5 seconds. • The internal storage temperature will appear in blue on the temperature display window. NOTE: If the unit is unplugged, power lost, or turned off you must wait 3 to 5 minutes before restarting the unit.
  • Page 12 IMPORTANT : Always unplug the unit before cleaning or performing maintenance. Never use harsh cleansers or scouring pads to clean any part of the unit. • Turn off the power, unplug the appliance, and remove all items including shelves. • Wash the shelves with a mild detergent solution. •...

  • Page 13: Problems With Your Wine Cooler

    PROBLEMS WITH YOUR WINE COOLER Most common problems can be solved easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before contacting Vinotemp at info@vinotemp.com. TROUBLESHOOTING PROBLEM POSSIBLE CAUSE •...

  • Page 14: Terms Of Sale And Warranty

    Note: Unfinished wood is subject to warping; all wood surfaces must be sealed before placing cellar into service. Improper placement of the unit will void the warranty. By Vinotemp in writing, any third party repair facility must be pre-approved before providing parts free of charge. This limited warranty does not cover damage due to such things as accident, misuse, abuse, mishandling, neglect, acts of God, fires, earthquakes, floods, high winds, government, war, riot or labor trouble, strikes, lockouts, delay of carrier, unauthorized repair, or any other cause beyond the control of the Seller, whether similar or dissimilar to the foregoing.
  • Page 15 1 7 6 2 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1 i n f o @ v i n o t e m p .

  • Page 16: Service & Important Notice

    Rancho Dominguez, CA 90221 www.vinotemp.com Vinotemp is a registered trademark of Vinotemp International. All products, features, and services are subject to change without notice. We cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.
