Page 1
A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y W i n e C o o l e r V T - 1 2 T E D S - 2 Z ( 1 2 b o t t l e ) O W N E R ’...
Page 3
Y o u r W i n e C e l l a r This unit can be used for Storage and/or Service. The unit has a glass door and soft interior light that you can leave on to elegantly display your wine. S e r v i n g W i n e s Storing wines at the proper temperature is important.
Upon receipt and inspection of unit, the supply cord must be replaced if it is damaged. Contact our customer service at 1-800-777-8466 or info@vinotemp.com. • Please fully read the instruction manual. Please read and follow all safety rules and operating instructions before using.
Table of Contents Cabinet and Circuit Diagram... 6 Technical Data ... 7 Important Safety Instructions... 8 Installation Instructions ... 9 Installing Your Wine Cellar ... 9 Electrical Connection ... 10 Important Safeguards ... 10 Operating Your Wine Cellar ... 12 Care and Maintenance ...
1. HINGE 2. LIGHT 3. TEMPERATURE CONTROLLER 4. TEMPERATURE DISPLAY 5. FAN MASK Cabinet Diagram 6. SHELF 7. FOOT 8. DOOR FRAME 9. GLASS 10. HANDLE Circuit Diagram W W W . V I N O T E M P . C O M...
Technical Data Model no. Capacity Voltage Current Protection class Frequency Climate class Input power Power Consumption kWh/24h Temperature Control Range Net weight Gross weight Unit size (W×H×D) Packing size (W×H×D) 1 7 6 2 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1 i n f o @ v i n o t e m p .
IMPORTANT SAFETY INSTRUCTIONS • Read all instructions before using the wine cellar. • DANGER or WARNING: Risk of child entrapment. • Junked or abandoned appliances are dangerous …even if they “just sit in the garage a few days.” • Before you throw away your old wine cellar: Take off the door, leave the shelves in place so that children may not easily climb inside.
INSTALLATION INSTRUCTIONS Before using your wine cellar • Remove the exterior and interior packing • Check to be sure the following parts are included: o For VT-12TEDS-2Z, 4 Slide out shelves o 1 Instruction manual o 1 Stainless steel handle o 2 Screws/fasteners •...
ELECTRICAL CONNECTION Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it replaced by an authorized products service center. • This unit should be properly grounded for your safety. •...
Page 11
power board. Please ensure that the appliance is plugged directly into the electrical outlet. • When positioning the wine cooler, ensure that there is at least a 5cm (2 inch) clearance at the sides and a 10cm (4 inch) clearance at the back of the cooler as this is the main outlet for heat.
OPERATING YOUR WINE CELLAR It is recommended that you install the wine cellar in a place where the ambient temperature is between 50°F and 80°F. If the ambient temperature is above or below recommended temperature, the performance of the unit may be affected.
PROBLEMS WITH YOUR WINE CELLAR You can solve many common wine cellar problems easily, saving you the cost of a possible service call. Try the suggestion below to see if you can solve the problem before contacting Vinotemp at info@vinotemp.com TROUBLESHOOTING GUIDE PROBLEM...
TERMS OF SALE AND WARRANTY Vinotemp International (“Seller”) and the person or entity that acquires these goods from Seller (“Purchaser”) hereby fully agree to the following terms and conditions of the sale: Shipping fees are the responsibility of the Purchaser whether freight prepaid or freight collect.
Please do not place the unit within reach of children. For adult use only. Contact info@vinotemp.com with any questions or visit: www.vinotemp.com 1 7 6 2 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1...
