5.5.9. Mounting the Noise / Sound Level Sensor and supplying power
Important: The Noise Level Sensor has been designed to be used with the Waspmote Plug & Sense! Smart Cities
PRO and it cannot be used independently. This sensor cannot be used on a Waspmote OEM with a Smart Cities PRO
board, for example.
The Sound Level Sensor consists of the next items shown in the figure below:
5
3
Figure: Noise Level Sensor items: 1 Noise Level Sensor. 2 Noise Level Sensor enclosure. 3 Data cable. 4 Power supply cable. 5 Protection
cover
4
-43-
2
1
Sensors
v7.3
