SelectBlinds Cordless Roller Shades Installation Instructions

BASICS
Please take a moment to identify which headrail version you have and
then follow the appropriate instructions.
A few simple tools are required:
- Measuring tape
- Carpenters Level
- Power drill with Phillips driver bit or Phillips head
Screwdriver
- Flat Head Screwdriver
Additional fasteners other than those sent with your shading may be
required depending on the mounting surface. Wallboard and plaster require
the use of anchors such as expansion or toggle bolts. Brick, tile or stone
need special plugs and drill bits. Remember to always pre-drill holes in
wood to avoid splitting.
Mounting
Cassette
Bracket -
Mounting
Mounting Bracket -
Ultra Sleek Plus
Bracket
No Headrail
Headrail
Headrail Extension &
Hold Down Bracket Hold Down
Side mount Bracket
(optional) Bracket Screw
If the headrail or roller does not sit level, the fabric will not roll up
evenly which could damage the edges of the shading fabric.
Step 1. BRACKET INSTALLATION
The end brackets should be located with
centerlines as noted in the illustrations.
Depending on the width of the shading,
necessary additional brackets may be evenly
spaced between the two end brackets.
Inside Mount
The plastic
tab should
face toward
the window
No headrail version: Make sure that
the screw head is fully recessed inside the clear plastic part of
the mounting bracket.
Outside/Wall Mount
3/8" min.
1 1/4" Hex
Head The plastic
Bracket
tab should
Screw
face up.
No Headrail Version
Side Mount
Measure from window sill up to desired mounting position on each
Nut &
side of the window frame. Mark position. Mount Side Mount Brackets
Bolt
on each side of window frame as shown. Make sure to confirm that
headrail will sit perfectly level. Once Side Mount Brackets are
installed and properly positioned, attach the Standard Mounting
Brackets using the nuts and bolts provided
Extension Brackets
Optional Extension Brackets are used to project the back of the
shading up to 2 1/2" from the mounting surface. Attach the Standard
Mounting Bracket to the Extension Bracket with the nut and bolt
Shade width # Brackets
provided.
Up to 40" 2
>40" - 72" 3
>72" - 84" 4
>84" - 96" 5
2" minimum surface required
Ultra Sleek Plus
2"
1 1/4"
2"
3/4" minimum for shallow mount
No Headrail Version 3 3/4" minimum for flush inside mount
Headrail Version
3/4" min.
Cassette
Ultra Sleek Plus
Headrail Version
(optional)
No Headrail
Ultra Sleek Plus Cassette
(optional)
2 1/2"
Cassette
Step 2. HANGING THE SHADE
No Headrail Version
3"
Inside Mount or Extension Bracket
Hook the rail onto
the front of the
bracket and rotate it
until the back of the
rail securely snaps
into place.
Outside/Wall Mount
Hook the rail onto
the bottom of the
bracket and
rotate it until the
back of the rail
securely snaps
3/4" min.
into place.
Headrail Version
Ultra Sleek Plus
Push the rail back until it is fully engaged.
Un-Install Shade - No headrail
Inside Mount
To remove the shade, partially
lower the shading and use a
flat head screwdriver to press
the clear tab on the mounting
bracket. Rotate the shade to
remove.
Outside/Wall Mount
Press down on clear
tab and then rotate
shade to release.
Un-Install Headrail
To remove the shade, partially lower
the shade and insert a flat head
screwdriver as shown. Twist the
screwdriver until
disengages from the bracket.
Cassette
Ultra Sleek Plus
Cassette
the headrail
