Set up your Obsidian
Follow these steps to set up and use your Obsidian. Carefully remove your Obsidian and all the
components from the box before beginning to set up your Obsidian.
NOTE:
Placing the screen on hard surfaces can cause scratches on the screen.
Remove Battery Cover
Press and then pull down on the back of the phone to remove the battery cover.

Insert SIM card

With the gold SIM card contacts facing down, press gently on the SIM card as you slide it into the slot.
NOTE:
If the battery is already inserted, remove it before inserting the SIM card. Also, make sure that
the metal contacts are facing down and the notched corner is in the correct position. If the SIM card is
not correctly inserted in the Obsidian and you turn on the Obsidian, No SIM card installed
in the title bar at the upper-right corner of the screen.
Insert microSD card (optional)
After you have inserted the SIM card, you might want to insert a storage card. A storage card helps you
store more files, such as photos and documents on your Obsidian.
Insert a microSD card into the slot.
NOTE:
A microSD card is not included with your Obsidian and must be purchased separately.
Insert battery
Once you have inserted the SIM card, insert the battery.
1.
With the HP logo facing out, push the top of the battery in first.
2.
Push up on the battery cover to lock it in place.
Replace battery cover
Push up on the battery cover to lock it in place.
appears
