Adjustment
The set point may be changed
by turning the adjustment screw
until pointer is opposite the
desired cutout point. The
adjustment screw is accessible
at the bottom of the control or at
the top when the cover is
removed.
Checkout Procedure
Before leaving the installation
observe at least three complete
operating cycles to be sure that
all components are functioning
correctly. When used as a low
temperature cutout control,
simulate operation by actuating
contacts to confirm that electrical
connections are correct.
Controls Group
507 E. Michigan Street
P.O. Box 423
Milwaukee, WI 53202
2 A11 Technical Bulletin
Repairs and Replacement
Field repairs must not be made.
For a replacement control,
contact the nearest Johnson
Controls wholesaler.
