- Page 1 Active Studio Monitor O 200 Installation Operation 058-E0011 Version 01/2003 Tel.: + 49 - (0)711 - 45893 - 0 KLEIN + HUMMEL GmbH Fax: + 49 - (0)711 - 45893 - 35 e-Mail:info@klein-hummel.de Zeppelinstr. 12 73760 Ostfildern/Germany Internet:www.klein-hummel.de...
-
Page 2: Safety Instructions
• To protect this product from lightning damage during a thunderstorm or from power surges during an extended absence, disconnect the power cable from the wall outlet. Page 2 Active Studio Monitor O 200... -
Page 3: Table Of Contents
Active Studio Monitor KLEIN + HUMMEL O 200 Installation - Operation Figure 1: Front view of the O 200 Figure 2: Rear panel of the O 200 Table of Contents: 1.6.1 Input SENSIVITY, ATTENUATOR .. 4 Safety Instructions ......2 1.6.2 Location EQUALIZATION .... -
Page 4: Installation And Operation
1. Installation and Operation When power on the O 200 is turned off, on the other hand, or if there is a general power failure, the signal It is absolutely essential that you read and observe... -
Page 5: Ground Lift
1.9 Care of the cabinet may experience some air noise and possibly some degradation in low-frequency response. The cabinet housing of the K+H O 200 active studio monitor comes standard with a charcoal - grey (RAL 1.7 Front grille color 7021) colored enamel finish. Handle the cabinet with care to avoid damaging the finish. - Page 6 Figure 5: Vertical Directivity Figure 6: Frequency Response (free field) Figure 7: THD, 2nd and 3rd order distortion @ 95 dB/SPL and 1 m distance Figure 8: Group Delay Page 6 Active Studio Monitor O 200...
-
Page 7: Warranty Information
In the event warranty service is required, presentation Zeppelinstrasse 12 of a warranty card will not be necessary. Proof of 73760 Ostfildern / Germany purchase date can be made by filing copies of appropriate documents (invoice, delivery note). Active Studio Monitor O 200 Page 7... -
Page 8: Technical Specifications
LH 26 mounting bracket LH 28 tripod bushing (LH 26 mounting bracket required) LH 29 TV - spigot (LH 26 mounting bracket required) LH 27 ball clamp mount (LH 26 mounting bracket required) C 15 eyebolt Page 8 Active Studio Monitor O 200...
